Home > products > Linear Motion Bearings > LM60UU OP Linear Ball Bearing Shaft Guiding Ball Bushing 60mm × 90mm × 110mm

LM60UU OP Linear Ball Bearing Shaft Guiding Ball Bushing 60mm × 90mm × 110mm

Product Details

Place of Origin: CHINA

Brand Name: FSK / IKO / THK / NSK / FAG / NTN / KOYO

Certification: ISO9001-2000 / CE / ROHS / UL

Model Number: LM60UU OP

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Talk in the letter

Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING

Delivery Time: 5-7Days After Details Confirmed

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 100000pcs/month

Get Best Price
Highlight:

linear motion bearing

,

bearing bushing

Model:
LM60UU OP
Weight:
2kg
Dimensions:
60mm × 90mm × 110mm
Vibration And Noise:
Z0V0 / Z1V1 / Z2V2 / Z3V3
Cage:
Steel Cage / Nylon Cage / Light Alloy Cage
Material:
GCr15
Model:
LM60UU OP
Weight:
2kg
Dimensions:
60mm × 90mm × 110mm
Vibration And Noise:
Z0V0 / Z1V1 / Z2V2 / Z3V3
Cage:
Steel Cage / Nylon Cage / Light Alloy Cage
Material:
GCr15
LM60UU OP Linear Ball Bearing Shaft Guiding Ball Bushing 60mm × 90mm × 110mm

LM60UU OP Linear Ball Bearing Shaft Guiding Ball Bushing 60mm × 90mm × 110mm



Bearing Specification :

FSK Bearing Model Number

LM60UU OP

Part Name

Linear Motion Bearing

Structure Linear Ball Bearings

Brand

FSK / IKO / THK / NSK / FAG / NTN / KOYO

Number of Row

Five Row

Material

Gcr15 Chrome Steel

Precision Rating

ABEC-1 to ABEC-9

Vibration and Noise Z0V0 / Z1V1 / Z2V2 / Z3V3
Cage Steel Cage / Nylon Cage / Light Alloy Cage
Seal Type Open
Package Single Carton Box / Pallet / Wooden case
Weight 2kg
Dimension 60mm × 90mm × 110mm
HS Code  8482800000
Original Country Show CHINA



Description:

LM60UU OP Linear Ball Bearing Shaft Guiding Ball Bushing 60mm × 90mm × 110mm 0LM60UU OP Linear Ball Bearing Shaft Guiding Ball Bushing 60mm × 90mm × 110mm 1



Other Models We Can Offer

 Designation  Major dimensions(mm) Ratings load
LM-OP Number of ball rows   dr D L Dynamic CN Static CoN
Weight
(g)

LM10-OP 4 30 10 19 29 372 549
LM12-OP 5 31.5 12 21 30 510 784
LM13-OP 5 43 13 23 32 510 784
LM16-OP 5 69 16 28 37 774 1180
LM20-OP 6 87 20 32 42 882 1370
LM25-OP 6 220 25 40 59 980 1570
LM30-OP 6 250 30 45 64 1570 2740
LM35-OP 6 390 35 52 70 1670 3140
LM40-OP 6 585 40 60 80 2160 4020
LM50-OP 6 1580 50 80 100 3820 7940
LM60-OP 6 2000 60 90 110 4700 10000
LM80-OP 6 4420 80 120 140 7350 16000
LM100-OP 6 8600 100 150 175 14120 34800
LM120-OP 8 14900 120 180 200 16400 40000
LM150-OP 8 20150 150 210 240 21100 54300


Bearings Detailed Pictures :

LM60UU OP Linear Ball Bearing Shaft Guiding Ball Bushing 60mm × 90mm × 110mm 2LM60UU OP Linear Ball Bearing Shaft Guiding Ball Bushing 60mm × 90mm × 110mm 3LM60UU OP Linear Ball Bearing Shaft Guiding Ball Bushing 60mm × 90mm × 110mm 4LM60UU OP Linear Ball Bearing Shaft Guiding Ball Bushing 60mm × 90mm × 110mm 5



Advantage :
1. Low friction
2. Wear resistant
3. Easy replacement
4. Minimum lubrication
5. Requires little attention
6. Running in not required
7. Dimensions relatively small
8. No scraping required tofit shaft
