Product Details
Place of Origin: CHINA
Brand Name: IKO / THK / NSK / TIMKEN / FAG / NTN / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: LM25 UU
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model: |
LM25 UU |
Dimension: |
25mm × 40mm × 59mm |
Number Of Row: |
Six Row |
Structure: |
Linear Motion Bearing |
Material: |
Gcr15 Chrome Steel |
Nut Type: |
SFU, SFT, SFE, DFU, DFI |
Model: |
LM25 UU |
Dimension: |
25mm × 40mm × 59mm |
Number Of Row: |
Six Row |
Structure: |
Linear Motion Bearing |
Material: |
Gcr15 Chrome Steel |
Nut Type: |
SFU, SFT, SFE, DFU, DFI |
LM25 UU Linear Bearing Shafting and Shaft Supports 25mm × 40mm × 59mm
Bearing Specification :
|
FSK Bearing Model Number |
LM25 UU |
|
Part Name |
Linear Motion Bearing |
| Structure | Linear Ball Bearings |
|
Brand |
IKO / THK / NSK / TIMKEN / FAG / NTN / KOYO / OEM |
|
Number of Row |
Six Row |
|
Material |
Gcr15 Chrome Steel |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Cage | Steel Cage / Nylon Cage / Light Alloy Cage |
| Weight | 0.22kg |
| Dimension | 25mm × 40mm × 59mm |
| HS Code | 8482800000 |
| Original Country Show | CHINA |
Description:
LM linear bearing:
| LM 3UU | LME8S | LME20UU | LME50UU |
| LME4UU | LME10UU | LME25UU | LME60UU |
| LME5UU | LME12UU | LME30UU | LME80UU |
| LME6UU | LME13UU | LME35UU | LME100UU |
| LME8UU | LME16UU | LME40UU |
Other Models We Can Offer
| Model No. | Main dimensions | Basic load rating | ||||
| Inscribed bore diameter | Outer diameter | Length | Dynamic rating | Static rating | Mass | |
| dr | D | L | C | C0 | ||
| mm | mm | mm | N | N | G | |
| LM 3 | 3 | 7 | 10 | 88.2 | 108 | 1.4 |
| LM 4 | 4 | 8 | 12 | 88.2 | 127 | 1.9 |
| LM 5 | 5 | 10 | 15 | 167 | 206 | 4 |
| LM 6 | 6 | 12 | 19 | 206 | 265 | 8 |
| LM 8S | 8 | 15 | 17 | 176 | 225 | 11 |
| LM 8 | 8 | 15 | 24 | 265 | 402 | 16 |
| LM 10 | 10 | 19 | 29 | 373 | 549 | 30 |
| LM 12 | 12 | 21 | 30 | 412 | 598 | 31.5 |
| LM 13 | 13 | 23 | 32 | 510 | 775 | 43 |
| LM 16 | 16 | 28 | 37 | 775 | 1180 | 69 |
| LM 20 | 20 | 32 | 42 | 863 | 1370 | 87 |
| LM 25 | 25 | 40 | 59 | 980 | 1570 | 220 |
| LM 30 | 30 | 45 | 64 | 1570 | 2750 | 250 |
| LM 35 | 35 | 52 | 70 | 1670 | 3140 | 390 |
| LM 40 | 40 | 60 | 80 | 2160 | 4020 | 585 |
| LM 50 | 50 | 80 | 100 | 3820 | 7940 | 1580 |
Bearings Detailed Pictures :
LM25 UU Linear Bearing Shafting and Shaft Supports 25mm × 40mm × 59mm, Get Cheap Price from China Steering Bearing Factory Now !
