Product Details
Place of Origin: JAPAN
Brand Name: THK / HIWIN / INA / IKO / FSK
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: CFN5R-A
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Material: |
Gcr15 Chrome Steel |
Size: |
5 × 13 × 9mm |
Weight: |
0.5KG |
Quality: |
ABEC-1 To ABEC-9 |
Certificate: |
ISO9001-2000 / CE / ROHS / UL |
Availability: |
Have Stocks |
Material: |
Gcr15 Chrome Steel |
Size: |
5 × 13 × 9mm |
Weight: |
0.5KG |
Quality: |
ABEC-1 To ABEC-9 |
Certificate: |
ISO9001-2000 / CE / ROHS / UL |
Availability: |
Have Stocks |
Track Roller Bearings CFN5R-A CFN6R-N CFN8R-N Cam Follower Bearings
Specifications
|
FSK BEARING Model Number |
CFN5R-A |
|
Part Name |
Track Roller Bearings |
|
Brand |
THK / HIWIN / INA / IKO / FSK |
|
Seal Type |
Open |
|
Material |
Gcr15 Chrome Steel |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
|
Dimensions(mm)(d*D*b) |
5*13*9 |
|
Weight / Mass ( KG ) |
0.5kg |
|
HS Code |
8482800000 |
Bearings Detailed Pictures
Same Series Bearing We Do
| Stud diameter | Model No. | Main dimensions(mm) | Mass | ||||||||||
| Outer diameter | Outer ring width | Threaded | Overall length | ||||||||||
| d | D | C | G | G1 | Bi | B1 | B2 | B3 | C1 | H | rsmin | g | |
| 5 | CFN5R-A | 13 | 9 | M5×0.8 | 7.5 | 10 | 23 | 13 | — | 0.5 | 3 | 0.3 | 10.5 |
| 6 | CFN6R-A | 16 | 11 | M6×1 | 8 | 12 | 28 | 16 | — | 0.6 | 3 | 0.3 | 18.5 |
| 8 | CFN8R-A | 19 | 11 | M8×1.25 | 10 | 12 | 32 | 20 | — | 0.6 | 4 | 0.3 | 28.5 |
| 10 | CFN10R-A | 22 | 12 | M10×1.25 | 12 | 13 | 36 | 23 | — | 0.6 | 5 | 0.3 | 45 |
| 12 | CFN12R-A | 30 | 14 | M12×1.5 | 13 | 15 | 40 | 25 | 6 | 0.6 | 6 | 0.6 | 105 |
Application of THK THK CFN5R-A
1.CFN5R-A THK’s linear motion system helps to provide a guide device that enables this precision and speed to be realized.
2. CFN5R-A In order to repeat the production of this advanced product, the LM guide and ball screw in the milling machine guide system which don’t waste of action
3. The LM guide and ball screw are indispensable for the movement of the tool section of the lathe because of its high rigidity and high precision.
4. By combining LM guides and ball screws with lubrication parts, we can reduce system design work and assembly steps, and extend the interval needed for maintenance.
5. Frequent earthquakes have made great concern among residents in some regions. The vibration control system of THK THK CFN5R-A can help solve the problem.
The system is based on the application technology of LM guide ball screw. It can provide protection to people's life and life in earthquake. The system can not only prevent the damage caused by the earthquake, but also reduce people's panic because of its omnipresent, reliable And durable.
FSK Advantage
Established in 2005, FSK has grown to be one of the main professional providers for bearings all over the world . We take pride in every single product that we sell .Our bearings are in hot sale with better quality and low pricing. You can be relieved and trusting us for our professional bearing technology and service , our friendly English-speaking team is always ready to help you out with importing procedures, product questions and technical support. And we promise to make you or your client proud with our products and services.
Below are some detailed pictures for your reference
