Home > products > Needle Roller Bearings > NUTR 40 Full Complement Cylindrical Roller Set With Axial Guidance

NUTR 40 Full Complement Cylindrical Roller Set With Axial Guidance

Product Details

Place of Origin: CHINA

Brand Name: INA / IKO / FSK / OEM

Certification: ISO9001-2000 / CE / ROHS / UL

Model Number: NUTR 40

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Talk in the letter

Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING

Delivery Time: 5-7Days After Details Confirmed

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 100000pcs/month

Get Best Price
High Light:

Full Complement Cylindrical Roller Set

,

NUTR 40 Cylindrical Roller Set

Model No.:
NUTR 40
Size:
40 × 80 × 32mm
Weight:
0.816kg
Seal:
Double Seal
Part Name:
China Track Roller Bearing
Character:
Full Complement , Double Seal
Model No.:
NUTR 40
Size:
40 × 80 × 32mm
Weight:
0.816kg
Seal:
Double Seal
Part Name:
China Track Roller Bearing
Character:
Full Complement , Double Seal
NUTR 40 Full Complement Cylindrical Roller Set With Axial Guidance

NUTR 40 Full Complement Cylindrical Roller Set With Axial Guidance



Bearing Specification :

Model Number

NUTR 40

Part Name

Track Roller Bearing

Brand

INA / IKO / McGill / FSK / OEM

Precision Rating

ABEC-1 to ABEC-9

Vibration and Noise Z0V0 / Z1V1 / Z2V2 / Z3V3
Material Gcr15 Chrome Steel
Number of Row Double Row
Cage without Cage

Dimensions(mm)(d*D*b)

40 × 80 × 32mm

Weight / Mass ( KG )

0.816kg

HS Code

8482800000

Original Country Show CHINA



Bearing Drawing :

NUTR 40 Full Complement Cylindrical Roller Set With Axial Guidance 0

NUTR 40 Full Complement Cylindrical Roller Set With Axial Guidance 1



Truck Roller Bearing List:

Bearing No. and weight Specification Basic Loading  Limiting Speed
with Inner Ring Weight d D B C d1 Dynamic Static Grease
g mm mm rpm
NUTR15 99 15 35 19 18 20 20500 24500 6500
NUTR17 147 17 40 21 20 22 21800 28500 5500
NUTR15 42 158 15 42 19 18 20 20500 24500 6500
NUTR17 47 220 17 47 21 20 20 21800 28500 5500
NUTR20 245 20 47 25 24 27 36900 48900 4200
NUTR20 52 321 20 52 25 24 27 36900 48900 4200
NUTR25 281 25 52 25 24 31 40800 58500 3400
NUTR25 62 450 25 62 25 24 31 40800 58500 3400
NUTR30 465 30 62 29 28 38 56800 77500 2600
NUTR30 72 697 30 72 29 28 38 56800 77500 2600
NUTR35 630 35 72 29 28 44 63000 91000 2100
NUTR35 80 836 35 80 29 28 44 63000 91000 2100
NUTR40 816 40 80 32 30 51 87900 108000 1600
NUTR45 883 45 85 32 30 55 93600 119000 1400
NUTR40 90 1129 40 90 32 30 51 87900 108000 1600
NUTR50 950 50 90 32 30 60 98900 140000 1300
NUTR45 100 1396 45 100 32 30 55 93600 119000 1400
NUTR50 110 1690 50 110 32 30 60 98900 140000 1300



Our Bearing Production Range:



Ball Bearing Deep Groove Ball Bearing 60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **,
160 **(70001 )
Thrust Ball Bearing 511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series
Angular Contact Ball bearing SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series
Roller Bearing Spherical Roller bearing 239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on
Taper Roller Bearing 329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings suchas 938/932 single and double row i.e M255410CD etc.
Thrust Roller Bearing 292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series.
Cylindrical Roller Bearing NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used in Steel Industry.



NUTR 40 Full Complement Cylindrical Roller Set With Axial Guidance 2



About Our Factory :

NUTR 40 Full Complement Cylindrical Roller Set With Axial Guidance 3

       NUTR 40 Full Complement Cylindrical Roller Set With Axial Guidance 4



NUTR 40 Full Complement Cylindrical Roller Set With Axial Guidance, Get Cheap Price from China Roller Bearing Factory Now !
