Nylon Cage 7603025 TVP Thrust Angular Contact Ball Bearing Single Row High Speed

Nylon Cage 7603025 TVP Thrust Angular Contact Ball Bearing Single Row High Speed

7603025 TVP Bearing Specification :

Drawing and Data of 7603025 TVP Bearing:

					d	25 mm
					D	62 mm
					B	17 mm
					a	48 mm
					Da H12	52 mm
					da h12	38 mm
					ra max	1 mm
					rmin	1,1 mm
					m	0,275 kg
					Ca	29500 N
					C0a	68000 N
					Fa max	18000 N
					nG Fett	3800 1/min
					nG Oel	5000 1/min
					Fv	3300 N
					Mr	85 Nmm
					Cua	6100 N

Bearings Detailed Pictures :

Other Screw bearing Bearings We Offer:

1) B71804E,B71805E,B71806E,
B71807E,B71808E,B71809E.B71810E.B71811E,B71812E,B71813E,B71814E,B71815E,
B71816E,B71817E,B71818E,B71819E,B71820E,B71821E,B71822E,B71824E,
B71826E,B71828E,B71830E,B71832E,B71834E,B71836E,
B71838E,B71840E,B71844E,B71848E,
B71904E,B71905E,B71906E,B71907E,B71908E,
B71909E,B71910E,B71911E,B71912E,B71913E,B71914E,B71915E,B71916E,B71917E,
B71918E,B71919E,B71920E,B71921E,B71922E,B71924E,B71925E,B71926E,
B71928E,B71930E,B71932E,B71934E,B71936E,B71938E,B71940E,
2) B71804C,B71805C,B71806C.
B71807C,B71808C,B71809C,B71810C,B71811C,B71812C,B71813C,B71814C,B71815C,
B71816C,B71817C,B71818C,B71819C,B71820C,B71821C,B71822C,B71824C,
,B71826C,B71828C,B71830C,B71832C,B71834C,B71836C,
B71838C,B71840C,B71844C,B71848C, B71904C,B71905C,B71906C,B71907,.B71908C,
B71909C,B71910C,B71911C,B71912C,B71913C,B71914C,B71915C,B71916C,B71917C,
B71918C,B71919C,B71920C,B71921C,B71922C,B71924C,B71926C,B71928C,B71930C,B71932C,B71934C,B71936C,B71938C,B71940C,
B71942C,B71944C,B71948C;
3)71804C,71805C,71806C,71807C,71808C,71809C,71810C,71811C,71812C,71813C,71814C,71815C,71816C,71818C,71819C,71820C,71821C,71822C,71824C,71826C,71828C,71830C,71832C,71834C,71836C,71838C,71840C,71904C,71905C,71906C,71907C,71908C,71909C,71910C,71911C,71912C,71913C,71914C,71915C,71916C,71917C,71918C,71919C,71920C,71921C,71922C,71924C,71926C,71928C,71930C,71932C,71934C,71936C,71938C,71940C,71944C,71948C,
4)71804AC,71805AC,71806AC,71807AC,71808AC,71809AC,71810AC,71811AC,71812AC,71813AC,71814AC,71815AC,71816AC,71817AC,71818AC,71818AC,71819AC,71820AC,71822AC,71824AC,71826AC,71828AC,71830AC,71832AC,71834AC,71836AC,71838AC,71840AC,71844AC,71848AC,71904AC,71905AC,71906AC,71907AC,71908AC,71909AC,71910AC,71911AC,71912AC,71913AC,71914AC,71915AC,71916AC,71917AC,71918AC,71818AC,71919AC,71920AC,71922AC,71924AC,71926AC,71928AC,71930AC,71932AC,71934AC,71936AC,71938AC,71940AC,71944AC,71948AC,
5) 71804CTA/P4,71805CTA/P4,71806CTA/P4,71807CTA/P4,71808CTA/P4,71809CTA/P4,71810CTA/P4,71811CTA/P4,71812CTA/P4

About Us:

1.Direct China factory/Manufactur with strong Capability
We are direct bearing factory on Jiangsu, China for more than 10 years.300 bearing types,15 million sets items ar produced yearly and the output value more than 15 million US dollars last year.
We could complete all ordere items excellently with over one hundred of advanced equipments running in 6 plants in China.
2.Large ready stock&Fast Delivery Time
Rich in stock throughout the year for general bearing types,sush as Deep groove ball bearing,Tapered Roller Bearing,Thrust Ball Bearing,etc.
Based on above advantages,we delivery goods timely&fastly as your requests.Warehouse items would deliveried within 1-2 days.
By courier/air or by cargo/sea
3.Competitive price
Large stock and strong Capability enables us to offer more reasonable price all over the world. Customers could receive good quality bearings with attrative price at the same time from us.
4.Non-standard Customized Service
We could customize many non-standard bearings and workpiece as your drawing requests and offer in-house test report by professional engineers.All customized goods are made to order as requests.
5.Perfect Quality Control System
We have perfect quality control systems and testing equipments and experienced engineers for more than 10 years.We test bearings one by one assuring all bearings with high proformance.
6.Best After-sale service
Experienced different after-sale workers are online for more than 12hours a day, 7 days a week offering you different bearing solutions for you.
We are glad to receive any comments from all the world by email,by call/message or by Skype/wechat/whatsapp/Viber/QQ..etc.
8. Multi-language communications
