| Place of Origin: | CHINA |
|---|---|
| Brand Name: | IKO / THK / NSK / TIMKEN / FAG / NTN / KOYO |
| Certification: | ISO9001-2000 / CE / ROHS / UL |
| Model Number: | LM20 OPUU |
| Minimum Order Quantity: | 1 pcs |
| Price: | Talk in the letter |
| Packaging Details: | 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING |
| Delivery Time: | 5-7Days After Details Confirmed |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000pcs/month |
| Part Name: | Linear Motion Bearing | Material: | Gcr15 Chrome Steel |
|---|---|---|---|
| Type: | Open Type | Size: | 20mm X 32mm X 42mm |
| Weight: | 0.069KG | Model NO: | LM20 OPUU |
| Highlight: | linear motion ball bearing,bearing bushing |
||
LM20 OPUU Shaft Liner Bearing Sizes 20mm x 32mm x 42mm International Standard
Bearing Specification :
|
Model Number |
LM20 OPUU |
|
Part Name |
Linear Motion Bearing |
| Structure | Linear Ball Bearings |
|
Brand |
IKO / THK / NSK / TIMKEN / FAG / NTN / KOYO |
|
Material |
Gcr15 Chrome Steel |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Package | Single Carton Box / Pallet / Wooden case |
| Weight | 0.069kg |
| Dimension | 20mm x 32mm x 42mm |
| HS Code | 8482990000 |
| Original Country Show | CHINA |
The List Of This Series
| LM Series | Basic Load | ID | |||||||
| Standard | Open Type | Adjustable Type | Dynamic | Static | |||||
| Bearing No. | Balls | Bearing No. | Balls | Bearing No. | Balls | C(N) | C.(N) | dr | Tolerance(µm) |
| (mm) | |||||||||
| LM5UU | 4 | - | - | - | - | 167 | 206 | 5 | 0 |
| -8 | |||||||||
| LM6UU | 4 | - | - | LM6UUAJ | 4 | 200 | 260 | 6 | 0 |
| LM8SUU | 4 | - | - | LM8SUUAJ | 4 | 170 | 220 | 8 | |
| LM8UU | 4 | - | - | LM8UUAJ | 4 | 260 | 400 | 8 | -9 |
| LM10UU | 4 | - | - | LM10UUAJ | 4 | 370 | 540 | 10 | |
| LM12UU | 4 | LM12UUOP | 3 | LM12UUAJ | 4 | 410 | 590 | 12 | |
| LM13UU | 4 | LM13UUOP | 3 | LM13UUAJ | 4 | 500 | 770 | 13 | |
| LM16UU | 5 | LM16UUOP | 4 | LM16UUAJ | 5 | 770 | 1170 | 16 | |
| LM20UU | 5 | LM20UUOP | 4 | LM20UUAJ | 5 | 860 | 1370 | 20 | 0 |
| LM25UU | 6 | LM25UUOP | 5 | LM25UUAJ | 6 | 980 | 1560 | 25 | |
| LM30UU | 6 | LM30UUOP | 5 | LM30UUAJ | 6 | 1560 | 2740 | 30 | -10 |
| LM35UU | 6 | LM35UUOP | 5 | LM35UUAJ | 6 | 1660 | 3130 | 35 | 0 |
| LM40UU | 6 | LM40UUOP | 5 | LM40UUAJ | 6 | 2150 | 4010 | 40 | |
| LM50UU | 6 | LM50UUOP | 5 | LM50UUAJ | 6 | 3820 | 7930 | 50 | -12 |
| LM60UU | 6 | LM60UUOP | 5 | LM60UUAJ | 6 | 4700 | 9990 | 60 | 0 |
| -15 | |||||||||
Other Models We Can Offer
LM SERIES
LM3UU,LM4UU,LM5UU,LM6UU,LM8UU,LM8S,LM10UU,LM12UU,LM13UU,LM16UU,LM20UU,
LM25UU,LM30UU,LM35UU,LM40UU,LM50UU,LM60UU, LM80UU,LM100UU,LM120UU, LM150UU
LM10OPUU,LM12OPUU,LM13OPUU,LM16OPUU,LM20OPUU,LM25OPUU, LM3OOPU,LM35OPUU,LM40OPUU,LM50OPUU,LM60OPUU,LM80OPUU,LM100OPUU
LM8GA,LM10GA,LM12GA,LM16GA,LM20GA,LM25GA,LM30GA,LM35GA,LM40GA,LM50GA,
LM60GA
Type LME-UU: This is the metric dimension series with seal used most frequently in Europe.
LMB SERIES
LMB3UU, LMB4UU, LMB6UU, LMB8UU, LMB10UU,LMB12UU,LMB16UU,LMB24UU,LMB32UU, LMB40UU, LMB48UU, LMB64UU
LMBS4UU LMBS6UU LMBS8UU LMBS10UU LMBS12UU LMBS16UU LMBS20UU LMBS24UULMBS32UU LMBS8UUOP LMBS10UUOP LMBS12UUOP LMBS16UUOP LMBS20UUOP
SBR SERIES
SBR10UU,SBR12UU,SBR13UU,SBR16UU,SBR20UU,SBR25UU,SBR30UU,SBR35UU, SBR40UU,SBR50UU, SBR10LUU,SBR12LUU,SBR13LUU,SBR16LUU,SBR20LUU,SBR25LUU,
SBR30LUU, SBR35LUU,SBR40LUU,SBR50LUU
SC series
SC8UU,SC10UU,SC12UU,SC13UU,SC16UU,SC20UU,SC25UU,SC30UU,SC35UU,SC40UU, SC50UU,SC60UU,SC8WUU,SC10WUU,SC12WUU,SC13WUU,SC16WUU,SC20WUU,SC252UU,
SC30WUU,SC35WUU,SC40WUU,SC50WUU,SC8VUU,SC10VUU,SC12VUU,SC13VUU,
SC16VUU,SC20VUU,SC25VUU,SC30VUU,SC35VUU, SC40VUU,SC50VUU
Bearings Detailed Pictures :
LM20 OPUU Shaft Liner Bearing Sizes 20mm x 32mm x 42mm International Standard, Get Cheap Price from China Steering Bearing Factory Now !
