Product Details
Place of Origin: CHINA
Brand Name: NSK / FSK / FAG / TIMKE / KOYO / NTN / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 7603030TN
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: 0.1-100USD
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 3-5Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
7603030TN |
Size: |
30mm × 72mm × 19mm |
Mass: |
0.42KG |
Cage: |
Brass Cage, Steel Cage, Nylon Cage |
Structure: |
Angular Contact |
Other Name: |
7603030-TVP Bearing / 7603030 TVP Bearing |
Model No.: |
7603030TN |
Size: |
30mm × 72mm × 19mm |
Mass: |
0.42KG |
Cage: |
Brass Cage, Steel Cage, Nylon Cage |
Structure: |
Angular Contact |
Other Name: |
7603030-TVP Bearing / 7603030 TVP Bearing |
FAG Precision 7603030TN 760306TN Ball Screw Bearing HIgh Speed
Bearing Specification :
| Model Number | 7603030TN |
| Dimensions(mm)(d*D*b) | 30mm × 72mm × 19mm |
| Weight / Mass ( KG ) | 0.42KG |
| Part Name | Angular Contact Ball Bearing |
| Brand | NSK / FSK / FAG / TIMKE / KOYO / NTN / OEM |
| Precision Rating | ABEC-1, ABEC-3, ABEC-5, ABEC-7, ABEC-9 |
| Material | Gcr15 |
| Number of Row | Single Row |
| Cage | Steel Cage / Brass Cage / Nylon Cage |
| HS Code | 8482103000 |
| Original Country Show | CHINA |
Angular Contact Bearing List:
| Dimensions | Load ratings | Limiting Speeds | Assembly Dimensions | Bearing | |
| d | D B rmin rlmin | Cr Cor | r/min | D1 D2 | Designation |
| 20 | 47 14 1 0.6 | 19.6 36.0 | 3000 5000 | 27.5 39.5 | 760204TN1 |
| 52 15 1 0.6 | 24.5 45.5 | 2800 4600 | 30.5 43.5 | 760304TN1 | |
| 25 | 52 15 1.1 1 | 22.0 44.0 | 2600 4300 | 32 45 | 760205TN1 |
| 62 17 1.1 1 | 28.5 58.5 | 2200 3600 | 38 52 | 760305TN1 | |
| 30 | 62 16 1.1 1 | 26.0 56.0 | 2200 3600 | 39.5 52.5 | 760206TN1 |
| 72 19 1.1 1 | 34.5 78.0 | 1900 3100 | 45 61 | 760306TN1 | |
| 35 | 72 17 1.5 1.1 | 30.5 71.0 | 1900 3100 | 46.5 60.5 | 760207TN1 |
| 80 21 1.5 1.1 | 36.5 86.5 | 1700 2800 | 51 67 | 760307TN1 | |
| 40 | 80 18 1.5 1.1 | 37.5 91.5 | 1600 2600 | 53.5 69.5 | 760208TN1 |
| 90 23 1.5 1.1 | 50.0 118.0 | 1500 250 | 56.5 75.5 | 760308TN1 | |
| 45 | 85 19 1.5 1.1 | 38.0 96.5 | 1500 2500 | 57 73 | 760209TN1 |
| 100 25 1.5 1.1 | 58.5 146.0 | 1300 2100 | 64.5 85.5 | 760309TN1 | |
| 50 | 90 20 1.5 1.1 | 39.0 106.0 | 1400 2300 | 63 79 | 760210TN1 |
| 110 27 1.5 1.1 | 69.5 180.0 | 1200 2000 | 72 94 | 760310TN1 | |
| 55 | 100 21 1.5 1.1 | 40.5 114.0 | 1300 2100 | 69.5 85.5 | 760211TN1 |
| 120 29 1.5 1.1 | 80.0 208.0 | 1100 1800 | 77 101 | 760311TN1 | |
| 60 | 110 22 1.5 1.1 | 56.0 160.0 | 1200 2000 | 77 96 | 760212TN1 |
| 130 31 1.5 1.1 | 88.0 236.0 | 1100 1800 | 82.5 107.5 | 760312TN1 | |
| 65 | 120 23 1.5 1.1 | 57.0 170.0 | 1100 1800 | 84 103 | 760213TN1 |
| 140 33 1.5 1.1 | 100.0 280.0 | 950 1580 | 91.5 118.5 | 760313TN1 | |
| 70 | 125 24 1.5 1.1 | 65.5 193.0 | 1000 1660 | 87 108 | 760214TN1 |
| 150 35 1.5 1.1 | 110.0 310.0 | 900 1500 | 95.5 124.5 | 760314TN1 | |
| 75 | 130 25 1.5 1.1 | 67.0 208.0 | 950 1580 | 93.5 114.5 | 760215TN1 |
| 160 37 1.5 1.1 | 125.0 365.0 | 850 1400 | 105.5 135.5 | 760315TN1 | |
| 80 | 140 26 1.5 1.1 | 76.5 240.0 | 900 1500 | 100 122 | 760216TN1 |
| 170 39 1.5 1.1 | 137.0 405.0 | 800 1300 | 111 143 | 760316TN1 | |
| 85 | 150 28 1.5 1.1 | 88.0 280.0 | 850 1400 | 107 131 | 760217TN1 |
| 180 41 1.5 1.1 | 160.0 465.0 | 750 1250 | 116 151 | 760317TN1 | |
| 90 | 160 30 1.5 1.1 | 98.0 315.0 | 800 1300 | 113.5 138.5 | 760218TN1 |
| 190 43 1.5 1.1 | 163.0 490.0 | 700 1160 | 122.5 157.5 | 760318TN1 | |
| 95 | 170 32 1.5 1.1 | 110.0 355.0 | 750 1250 | 119.5 146.5 | 760219TN1 |
| 200 45 1.5 1.1 | 163.0 510.0 | 670 1100 | 130 165 | 760319TN1 | |
| 100 | 180 34 1.5 1.1 | 122.0 400.0 | 700 1160 | 125.5 154.5 | 760220TN1 |
| 215 47 1.5 1.1 | 193.0 610.0 | 630 1050 | 140 178 | 760320TN1 | |
Bearings Detailed Pictures :
FAG Precision 7603030TN 760306TN Ball Screw Bearing HIgh Speed, Get Cheap Price from China Angular Contact Ball Bearing Factory Now !
