Product Details
Place of Origin: JAPAN
Brand Name: INA / IKO / FAG / NSK / FSK / FAG / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: ZKLF2068 2RS
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: 0.1-100USD
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 3-5Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
ZKLF2068 2RS |
Using: |
20mm × 68mm × 28mm |
Noise Level: |
Z1,Z2,Z3,Z4 |
Weight: |
0.61 |
Type: |
Angular Contact Ball Bearings |
Seal Type: |
2RS |
Model No.: |
ZKLF2068 2RS |
Using: |
20mm × 68mm × 28mm |
Noise Level: |
Z1,Z2,Z3,Z4 |
Weight: |
0.61 |
Type: |
Angular Contact Ball Bearings |
Seal Type: |
2RS |
ZKLF Series ZKLF2068 2RS Double Row Ball Screws Support Bearing
Bearing Specification :
|
Model Number |
ZKLF2068 2RS |
|
Part Name |
Angular Contact Ball Bearing |
|
Brand |
INA / IKO / FAG / NSK / FSK / FAG / OEM |
|
Precision Rating |
P1 to P9 |
| Material | Gcr15 |
| Number of Row | Double Row |
| Cage | Steel Cage / Brass Cage |
|
Dimensions(mm)(d*D*b) |
20mm × 68mm × 28mm |
|
Weight / Mass ( KG ) |
0.61kg |
|
HS Code |
8482103000 |
| Original Country Show | JAPAN |
Angular Contact Bearing List:
| Designation | Mass | Dimensions | Dimensions | Setscrew | Basic Load Ratings | ||||||||||
| d | D | B | d1 | D1 | r | r1 | J | d2 | b | l | Cr | Cor | |||
| -0.25 | min. | min. | min. | min. | min. | spec | Dynamic | Static | |||||||
| UBM | Kg | mm | mm | kN | |||||||||||
| ZKLF 1255.2RS | 0.37 | 12 | 55 | 25 | 25 | 33.5 | 0.3 | 0.6 | 42 | 6.5 | 3 | 17 | M6 | 17 | 24.7 |
| ZKLF 1255.2Z | 0.37 | 12 | 55 | 25 | 25 | 33.5 | 0.3 | 0.6 | 42 | 6.5 | 3 | 17 | M6 | 17 | 24.7 |
| ZKLF 1560.2RS | 0.43 | 15 | 60 | 25 | 28 | 36 | 0.3 | 0.6 | 46 | 6.5 | 3 | 17 | M6 | 17.9 | 28 |
| ZKLF 1560.2Z | 0.43 | 15 | 60 | 25 | 23 | 12 | 0.3 | 0.6 | 46 | 6.5 | 3 | 17 | M6 | 17.9 | 28 |
| ZKLF 1762.2RS | 0.45 | 17 | 62 | 25 | 23 | 12 | 0.3 | 0.6 | 48 | 6.5 | 3 | 17 | M6 | 18.8 | 31 |
| ZKLF 1762.2Z | 0.45 | 17 | 62 | 25 | 25 | 14 | 0.3 | 0.6 | 48 | 6.5 | 3 | 17 | M6 | 18.8 | 31 |
| ZKLF 2068.2RS | 0.61 | 20 | 68 | 28 | 25 | 14 | 0.3 | 0.6 | 53 | 6.5 | 3 | 19 | M6 | 26 | 47 |
| ZKLF 2068.2Z | 0.61 | 20 | 68 | 28 | 30 | 16 | 0.3 | 0.6 | 53 | 6.5 | 3 | 19 | M6 | 26 | 47 |
| ZKLF 2575.2RS | 0.72 | 25 | 75 | 28 | 30 | 16 | 0.3 | 0.6 | 58 | 6.5 | 3 | 19 | M6 | 27.5 | 55 |
| ZKLF 2575.2Z | 0.72 | 25 | 75 | 28 | 32 | 20 | 0.3 | 0.6 | 58 | 6.5 | 3 | 19 | M6 | 27.5 | 55 |
| ZKLF 3080.2RS | 0.78 | 30 | 80 | 28 | 32 | 20 | 0.3 | 0.6 | 63 | 6.5 | 3 | 19 | M6 | 29 | 64 |
| ZKLF 3080.2Z | 0.78 | 30 | 80 | 28 | 34 | 23 | 0.3 | 0.6 | 63 | 6.5 | 3 | 19 | M6 | 29 | 64 |
| ZKLF 3590.2RS | 1.13 | 35 | 90 | 34 | 34 | 23 | 0.3 | 0.6 | 75 | 8.5 | 3 | 25 | M8 | 41 | 89 |
| ZKLF 3590.2Z | 1.13 | 35 | 90 | 34 | 40 | 25 | 0.3 | 0.6 | 75 | 8.5 | 3 | 25 | M8 | 41 | 89 |
| ZKLF 40100.2RS | 1.46 | 40 | 100 | 34 | 40 | 25 | 0.3 | 0.6 | 80 | 8.5 | 3 | 25 | M8 | 43 | 101 |
| ZKLF 40100.2Z | 1.46 | 40 | 100 | 34 | 45 | 32 | 0.3 | 0.6 | 80 | 8.5 | 3 | 25 | M8 | 43 | 101 |
| ZKLF 50115.2RS | 1.86 | 50 | 115 | 34 | 45 | 32 | 0.3 | 0.6 | 94 | 8.5 | 3 | 25 | M8 | 46.5 | 126 |
| ZKLF 50115.2Z | 1.86 | 50 | 115 | 34 | 50 | 40 | 0.3 | 0.6 | 94 | 8.5 | 3 | 25 | M8 | 46.5 | 126 |
| ZKLF 60145.2Z | 4.3 | 60 | 145 | 45 | 50 | 40 | 0.3 | 0.6 | 120 | 8.5 | 3 | 35 | M8 | 84 | 214 |
| ZKLF 70155.2Z | 4.9 | 70 | 155 | 45 | 59 | 45 | 0.3 | 0.6 | 130 | 8.5 | 3 | 35 | M8 | 88 | 241 |
| ZKLF 80165.2Z | 5.3 | 80 | 165 | 45 | 59 | 45 | 0.3 | 0.6 | 140 | 8.5 | 3 | 35 | M8 | 91 | 265 |
| ZKLF 90190.2Z | 8.7 | 90 | 190 | 55 | 64 | 50 | 0.3 | 0.6 | 165 | 10.5 | 3 | 45 | M10 | 135 | 395 |
| ZKLF 100200.2Z | 9.3 | 100 | 200 | 55 | 64 | 50 | 0.3 | 0.6 | 175 | 10.5 | 3 | 45 | M10 | 140 | 435 |
Bearings Detailed Pictures :
ZKLF Series ZKLF2068 2RS Double Row Ball Screws Support Bearing, Get Cheap Price from China Angular Contact Ball Bearing Factory Now !
