Product Details
Place of Origin: JAPAN
Brand Name: FSK / NSK / NACHI / KOYO / NTN / FAG / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 6203-2Z
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model No.: |
6203-2Z |
Size: |
17mm × 40mm × 12mm |
Weight: |
0.065kg |
Seal Type: |
Metal Shield |
Part Name: |
China Deep Groove Ball Bearings |
Material: |
Chrome Steel |
Model No.: |
6203-2Z |
Size: |
17mm × 40mm × 12mm |
Weight: |
0.065kg |
Seal Type: |
Metal Shield |
Part Name: |
China Deep Groove Ball Bearings |
Material: |
Chrome Steel |
Z2V2 Z3V3 6203-2Z Ball Bearing Japan NSK 6203zz Metal Shield
Bearing Specification :
Model Number | 6203-2Z |
Part Name | Deep Groove Ball Bearings |
Brand | FSK / NSK / NACHI / KOYO / NTN / FAG / OEM |
Precision Rating | ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Material | Gcr15 Chrome, Steel Carbon steel, Stainless steel |
| Number of Row | Single Row |
| Cage | Steel Cage / Nylon Cage |
Dimensions(mm)(d*D*b) | 17mm × 40mm × 12mm |
Weight / Mass ( KG ) | 0.065kg |
HS Code | 8482102000 |
| Original Country Show | JAPNA |
Bearings Detailed Pictures :
Deep Groove Ball Bearings List:
| Bearing No. | inner diameter | Outside diameter | High | Dime | Max Speed | |||||||
| OPEN | Z | 2Z | RZ | 2RZ | RS | 2RS | d | D | B | Rsmin | Oil | Weight |
| 6201 | 6201-Z | 6201-2Z | 6201-RZ | 6201-2RZ | 6201-RS | 6201- | 12 | 32 | 10 | 0.6 | 24000 | 0.034 |
| 6202 | 6202-Z | 6202-2Z | 6202-RZ | 6202-2RZ | 6202-RS | 6202- | 15 | 35 | 11 | 0.6 | 22000 | 0.043 |
| 6203 | 6203-Z | 6203-2Z | 6203-RZ | 6203-2RZ | 6203-RS | 6203- | 17 | 40 | 12 | 0.6 | 20000 | 0.062 |
| 6204 | 6204-Z | 6204-2Z | 6204-RZ | 6204-2RZ | 6204-RS | 6204- | 20 | 47 | 14 | 1.0 | 18000 | 0.102 |
| 6205 | 6205-Z | 6205-2Z | 6205-RZ | 6205-2RZ | 6205-RS | 6205- | 25 | 52 | 13 | 1.0 | 16000 | 0.120 |
| 6206 | 6206-Z | 6206-2Z | 6206-RZ | 6206-2RZ | 6206-RS | 6206- | 30 | 62 | 14 | 1.0 | 13000 | 0.190 |
| 6207 | 6207-Z | 6207-2Z | 6207-RZ | 6207-2RZ | 6207-RS | 6207- | 35 | 72 | 15 | 1.1 | 11000 | 0.270 |
| 6208 | 6208-Z | 6208-2Z | 6208-RZ | 6208-2RZ | 6208-RS | 6208- | 40 | 80 | 16 | 1.1 | 10000 | 0.370 |
| 6209 | 6209-Z | 6209-2Z | 6209-RZ | 6209-2RZ | 6209-RS | 6209- | 45 | 85 | 16 | 1.1 | 9000 | 0.380 |
| 6210 | 6210-Z | 6210-2Z | 6210-RZ | 6210-2RZ | 6210-RS | 6210- | 50 | 90 | 18 | 1.1 | 8500 | 0.450 |
| 6211 | 6211-Z | 6211-2Z | 6211-RZ | 6211-RZ | 6211-RS | 6211- | 55 | 100 | 21 | 1.5 | 7500 | 0.603 |
Z2V2 Z3V3 6203-2Z Ball Bearing Japan NSK 6203zz Metal Shield, Get Cheap Price from China Ball Bearing Factory Now !
