Sealed LM40 UU Linear Motion Bearings LM20 UU LM25 UU LM30 UU LM40 UU

Basic Information
Place of Origin: CHINA
Brand Name: IKO / THK / NSK / TIMKEN / FAG / NTN / KOYO
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: LM40 UU
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model: LM40 UU Weight: 0.585kg
Material: Gcr15 Chrome Steel Type: Open , Flange , Rectangle
Application: 3D Printer, Industry Service: OEM
Highlight:

linear motion bearing

,

bearing bushing



Sealed Lm40 Uu Linear Motion Bearings Lm20 Uulm25 Uu Lm30 Uu Lm40 Uu



Bearing Specification :

Model Number

LM40 UU

Part Name

Linear Motion Bearing

Structure Linear Ball Bearings

Brand

IKO / THK / NSK / TIMKEN / FAG / NTN / KOYO

Number of Row

Six Row

Material

Gcr15 Chrome Steel

Precision Rating

ABEC-1 to ABEC-9

Vibration and Noise Z0V0 / Z1V1 / Z2V2 / Z3V3
Cage Steel Cage / Nylon Cage / Light Alloy Cage
Weight 0.585kg
Dimension 40mm × 60mm × 80mm
HS Code  8482990000
Original Country Show CHINA

Contact Person

Ms. Ellie Liao

Skype fskbearing1
Mail fsk_bearing@yahoo.com



Other Models We Can Offer

Model No. Main dimensions Basic load rating
Inscribed bore diameter  Outer diameter Length Dynamic rating Static rating Mass
dr D L C C0
mm mm mm N N G
LM 3 3 7 10 88.2 108 1.4
LM 4 4 8 12 88.2 127 1.9
LM 5 5 10 15 167 206 4
LM 6 6 12 19 206 265 8
LM 8S 8 15 17 176 225 11
LM 8 8 15 24 265 402 16
LM 10 10 19 29 373 549 30
LM 12 12 21 30 412 598 31.5
LM 13 13 23 32 510 775 43
LM 16 16 28 37 775 1180 69
LM 20 20 32 42 863 1370 87
LM 25 25 40 59 980 1570 220
LM 30 30 45 64 1570 2750 250
LM 35 35 52 70 1670 3140 390
LM 40 40 60 80 2160 4020 585
LM 50 50 80 100 3820 7940 1580


Bearings Detailed Pictures :

Sealed LM40 UU Linear Motion Bearings LM20 UU LM25 UU LM30 UU LM40 UU 0Sealed LM40 UU Linear Motion Bearings LM20 UU LM25 UU LM30 UU LM40 UU 1



LM40 UU Linear Motion Bearings LM20 UULM25 UU LM30 UU LM40 UU Sealed Linear Bearing, Get Cheap Price from China Steering Bearing Factory Now !
