Lm5uu Linear Motion Bearings Linear Ball Bearings 5mm × 10mm × 15mm

Product Details

Place of Origin: CHINA

Brand Name: FSK / THK / IKO / NSK / OEM

Certification: ISO9001-2000 / CE / ROHS / UL

Model Number: LM5UU

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Talk in the letter

Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING

Delivery Time: 5-7Days After Details Confirmed

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 100000pcs/month

Get Best Price
Highlight:

linear motion ball bearing

,

bearing bushing

Model:
LM5UU
Structure:
Ball Bearings
Size:
5mm ×10mm × 15mm
Number Of Row:
Four
Flange Types:
F,K,FM,KM,H,HM,FP,KP,HP
Weight:
0.004kg
Model:
LM5UU
Structure:
Ball Bearings
Size:
5mm ×10mm × 15mm
Number Of Row:
Four
Flange Types:
F,K,FM,KM,H,HM,FP,KP,HP
Weight:
0.004kg
Lm5uu Linear Motion Bearings Linear Ball Bearings 5mm × 10mm × 15mm



LM5UU Linear Motion Bearings Linear Ball Bearings 5mm × 10mm × 15mm



Bearing Specification :

Model Number

LM5UU

Part Name

Linear Motion Bearing

Structure Linear Ball Bearings

Brand

FSK / THK / IKO / NSK / OEM

Number of Row

Four Row

Material

Gcr15 Chrome Steel

Precision Rating

P0 P6 P5 P4 P2

Vibration and Noise Z0V0 / Z1V1 / Z2V2 / Z3V3
Cage Steel Cage / Nylon Cage / Light Alloy Cage
Dimension 5mm × 10mm × 15mm
Weight 0.004kg
HS Code  8482800000
Original Country Show CHINA



Description:

LM linear bearing:

LM3UU LM8S LM20UU LM50UU
LM4UU LM10UU LM25UU LM60UU
LM5UU LM12UU LM30UU LM80UU
LM6UU LM13UU LM35UU LM100UU
LM8UU LM16UU LM40UU



LME linear bearing:

LME3UU LME8S LME20UU LME50UU
LME4UU LME10UU LME25UU LME60UU
LME5UU LME12UU LME30UU LME80UU
LME6UU LME13UU LME35UU LME100UU
LME8UU LME16UU LME40UU

LMB linear bearing:

LMB4UU LMB24UU LM16OPUU LM40OPUU
LMB6UU LMB32UU LM20OPUU LM50OPUU
LMB8UU LM10OPUU LM25OPUU LM60OPUU
LMB10UU LM12OPUU LM3OOPU LM80OPUU
LMB12UU LM13OPUU LM35OPUU LM100OPUU
LMB16UU

Applications:



Linear bearings are widely used in electronic equipment, pull tester and the digital three-dimensional coordinate measuring device, such as precision equipment, as well as multi-axis machine tools, press, tool grinder, automatic gas cutting machine, printer, card sorting machine, food packaging machines and other industrial machinery sliding components



Other Models We Can Offer

Model No. Main dimensions Basic load rating
Inscribed bore diameter  Outer diameter Length Dynamic rating Static rating Mass
dr D L C C0
mm mm mm N N G
LM 3 3 7 10 88.2 108 1.4
LM 4 4 8 12 88.2 127 1.9
LM 5 5 10 15 167 206 4
LM 6 6 12 19 206 265 8
LM 8S 8 15 17 176 225 11
LM 8 8 15 24 265 402 16
LM 10 10 19 29 373 549 30
LM 12 12 21 30 412 598 31.5
LM 13 13 23 32 510 775 43
LM 16 16 28 37 775 1180 69
LM 20 20 32 42 863 1370 87
LM 25 25 40 59 980 1570 220
LM 30 30 45 64 1570 2750 250
LM 35 35 52 70 1670 3140 390
LM 40 40 60 80 2160 4020 585
LM 50 50 80 100 3820 7940 1580


Bearings Detailed Pictures :

Lm5uu Linear Motion Bearings Linear Ball Bearings 5mm × 10mm × 15mm 0



LM , LME , LMB Series LM5UU Linear Motion Bearing 5mm × 10mm × 15mm Miniature Ball Bearing, Get Cheap Price from China Steering Bearing Factory Now !
