Product Details
Place of Origin: JAPAN
Brand Name: FSK / TR / ASAHI / FYH / NSK / NTN / OEM
Certification: ISO9001-2000 / ROHS / UL / CE
Model Number: UCT206
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Low Price
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) PLASTIC TUBE PACKING / KRAFT PACKING
Delivery Time: 3-7Days After Deposit
Payment Terms: 30% Deposit , Balance After BL Copy
Supply Ability: 100000pcs/month
Model No.: |
UCT206 |
Size: |
30mm × 38.1mm × 118mm |
Weight: |
1.01kg |
Application: |
Conveyer Belt / Textile Machine / Agricultural Machinery |
Type: |
UCF / UCP / UCT / UCFL / UCFC Etc |
Hardness: |
59-62 |
Model No.: |
UCT206 |
Size: |
30mm × 38.1mm × 118mm |
Weight: |
1.01kg |
Application: |
Conveyer Belt / Textile Machine / Agricultural Machinery |
Type: |
UCF / UCP / UCT / UCFL / UCFC Etc |
Hardness: |
59-62 |
Cast Iron UCT206 / UCT207 Pillow Block Ball Bearing Agricultural Harvester Bearing
Bearing Specification :
| FSK BEARING Model Number | UCT206 |
| Part Name | Pillow Block Ball Bearing |
| Brand | FSK / TR / ASAHI / FYH / NSK / NTN / OEM |
| Precision Rating | P6 / P4 / P5 |
| Bearing Material | Chrome Steel / Stainless Steel |
| Housing Material | Cast Steel / Forging Steel / Zinc Alloy |
| Dimensions(mm)(d*D*b) | 30mm × 38.1mm × 118mm |
| Weight / Mass ( KG ) | 1.01kg |
| HS Code | 8482800000 |
| Original Country Show | CHINA |
FSK Pillow Block Bearings :
Pillow block bearing is a kind of bearing that looks like a small ball bearing that has a casting pedestal or a pressed steel plate and a double seal. If you will look closely inside it, you will see that the pillow block bearings is very much the same as the other kinds of bearing like the deep groove ball bearings. The only difference is that is you will look closely at the outer ring of the pillow block bearings, you can see that it has section balls which is best use with the concave part of the bearing pedestal.
Pillow blocks are usually mounted in cleaner environments & generally are meant for lesser loads of general industry. These differ from "plummer blocks" which are bearing housings supplied without any bearings & are usually meant for higher load ratings & corrosive industrial environments. However the terms pillow-block & plummer-block are used interchangeably in certain parts of the world
UCT Pillow Block Bearings Drawing :
Pillow Block Bearings with Housing List :
| Bearing Unit | Shaft Dia | Dimensions(mm) | Weight | |||||||
| No. | d | (kg) | ||||||||
| mm | o | g | s | p | q | b | k | e | ||
| UCT202 | 15 | 16 | 10 | 51 | 32 | 19 | 51 | 12 | 76 | 0.78 |
| UCT203 | 17 | 16 | 10 | 51 | 32 | 19 | 51 | 12 | 76 | 0.77 |
| UCT 204 | 20 | 16 | 10 | 51 | 32 | 19 | 51 | 12 | 76 | 0.81 |
| UCT205 | 25 | 16 | 10 | 51 | 32 | 19 | 51 | 12 | 76 | 0.92 |
| UCT206 | 30 | 16 | 10 | 56 | 37 | 22 | 57 | 12 | 89 | 1.01 |
| UCT207 | 35 | 16 | 13 | 64 | 37 | 22 | 64 | 12 | 89 | 1.7 |
| UCT208 | 40 | 19 | 16 | 83 | 49 | 29 | 83 | 16 | 102 | 2.43 |
| UCT209 | 45 | 19 | 16 | 83 | 49 | 29 | 83 | 16 | 102 | 2.58 |
| UCT210 | 50 | 19 | 16 | 83 | 49 | 29 | 86 | 16 | 102 | 2.78 |
| UCT211 | 55 | 25 | 19 | 102 | 64 | 35 | 95 | 22 | 130 | 4.17 |
| UCT212 | 60 | 32 | 19 | 102 | 64 | 35 | 102 | 22 | 130 | 4.9 |
| UCT213 | 65 | 32 | 21 | 111 | 70 | 41 | 121 | 26 | 151 | 7.3 |
| UCT214 | 70 | 32 | 21 | 111 | 70 | 41 | 121 | 26 | 151 | 7.36 |
| UCT215 | 75 | 32 | 21 | 111 | 70 | 41 | 121 | 26 | 151 | 7.99 |
| UCT216 | 80 | 32 | 21 | 111 | 70 | 41 | 121 | 26 | 165 | 8.92 |
| UCT217 | 85 | 38 | 29 | 124 | 73 | 48 | 157 | 30 | 173 | 11.46 |
| UCT218 | 90 | 40 | 30 | 130 | 80 | 48 | 140 | 30 | 190 | 14.76 |
Bearings Detailed Pictures :
FSK Payment and Shipping
| FSK Bearing Advantage |
| 1. Good raw material and promised working life 1 years or 30,000 kilometers |
| 2. 100% finished product check before shipment |
| 3. ISO9001/TS16949 quality control system |
| 4. 24 hours aftersale service |
| 5. Short production time and fast delivery |
| 6. More than 100 different items and small orders can be accepted |
| Material |
| Hydraulic clutch bearing use high quality bearing steel Gcr15 for rings and imported steel for balls. |
| Payment Terms |
|
We accept L/C,D/P,D/A,T/T,Westunion,Paypal all payment types if you have enough good credit. We have credit insurace company as partner. |
| Packing Information |
|
Plastic Bag +Single Box Packing + Paper Carton + Poly Wooden Pallet / Neutral packing / Customer's packing |
| Why choose FSK Bearing |
| We supply Hydraulic clutch bearing with low noise, long working life application and high quality. |
Cast Iron UCT206 / UCT207 Pillow Block Ball Bearing Agricultural Harvester Bearing, Get Cheap Price from China Bearing Factory Now !
