Home > products > Cylindrical Roller Bearing > Heavy Load 81213M Cylindrical Needle Roller and Cage Thrust Assemblies

Heavy Load 81213M Cylindrical Needle Roller and Cage Thrust Assemblies

Product Details

Place of Origin: CHINA

Brand Name: FSK / FAG / NTN / NSK / KOYO / ZWZ / HRB / OEM

Certification: ISO9001-2000 / CE / ROHS / UL

Model Number: 81213M

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Let's Chat in Detail

Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING

Delivery Time: 7 Days After Details Confirmed

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 10000pcs/day

Get Best Price
Highlight:

full complement cylindrical roller bearing

,

cylindrical roller thrust bearing

Model No.:
81213M
Size:
65 × 100 × 27mm
Weight:
0.721kg
Cage:
Brass Cage
Part Name:
China Cheap Cylindrical Roller Bearings
Character:
Plane Thrust
Model No.:
81213M
Size:
65 × 100 × 27mm
Weight:
0.721kg
Cage:
Brass Cage
Part Name:
China Cheap Cylindrical Roller Bearings
Character:
Plane Thrust
Heavy Load 81213M Cylindrical Needle Roller and Cage Thrust Assemblies



Heavy Load 81213M Cylindrical Needle Roller and Cage Thrust Assemblies



Thrust Cylindrical Roller Bearings Description
1. The main components of cylindrical roller thrust bearing; the cylindrical roller and cage thrust assembies, the shaft washers, and the housing washers.
2. The cylindrical roller thrust bearings are simple in form and design. The bearings are produced in single row and double row designs.
3. The cylindrical roller thrust bearings are suitable for arrangements that have to support heavy axial loads.
4. And they are relatively insensitive to shock loads, are very stiff and requre little axial space. As standard they are available as single direction
bearings and can only accommodate axial loads acting in one direction.



Bearing Specification :

Model Number

81213M

Part Name

Thrust Cylindrical Roller Bearings

Brand

FSK / FAG / NTN / NSK / KOYO / ZWZ / HRB / OEM

Precision Rating

ABEC-1 to ABEC-9

Vibration and Noise Z0V0 / Z1V1 / Z2V2 / Z3V3
Material Gcr15 Chrome Steel
Number of Row Single Row
Cage Brass Cage

Dimensions(mm)(d*D*b)

65 × 100 × 27mm

Weight / Mass ( KG )

0.721kg

HS Code

8482500000

Original Country Show CHINA



Bearing Drawing :

81213M Cylindrical Roller Thrust Bearing,Brass Cage ,Metric,65mm Bore,100mm OD,27mm Width



Heavy Load 81213M Cylindrical Needle Roller and Cage Thrust Assemblies 0

Bearings Detailed Pictures :

Heavy Load 81213M Cylindrical Needle Roller and Cage Thrust Assemblies 1



Part of Thrust Cylindrical Roller Bearings List:

Size (mm) Load Rating(KN) Limit Speed(r/min) Weight(kg) Bearing No.
d D H Ca Coa
15 28 9 14.4 28.5 11000 0.024 81102
17 30 9 15.9 33.5 10000 0.027 81103
20 35 10 24.9 53 8500 0.037 81104
25 42 11 33.5 76 7000 0.053 81105
30 47 11 35.5 86 6000 0.057 81106
52 16 64 141 6000 0.123 81206
60 18 69 197 5000 0.24 89306
35 52 12 39 101 5500 0.073 81107
62 18 80 199 4900 0.195 81207
68 20 80 237 4600 0.34 89307
40 60 13 56 148 4800 0.105 81108
68 19 107 265 4400 0.249 81208
78 22 122 385 4000 0.484 89308
90 23 135 480 3600 0.747 87409
45 65 14 59 163 4400 0.13 81109
73 20 105 265 4000 0.287 81209
85 24 139 445 3600 0.615 89309
100 25 154 560 3200 1.054 87409
50 70 14 61 177 4000 0.14 81110
78 22 117 315 3700 0.356 81210
95 27 167 560 3200 0.887 89310
110 27 200 740 2900 1.316 87410
110 36 295 900 3000 1.316 89410
110 31 295 900 3000 1.125 89410X
55 78 16 90 300 3600 0.218 81111
90 25 154 405 3300 0.568 81211
105 30 184 600 2900 1.18 89311
120 29 222 870 2600 1.698 87411
60 85 17 103 315 3300 0.266 81112
95 26 172 480 3100 0.642 87212
110 30 196 670 2700 1.26 89312
130 32 260 1000 2500 2.26 87412
130 42 390 1220 2500 2.818 89412
65 90 18 107 340 3100 0.31 81113
100 27 177 500 2900 0.721 81213
115 30 194 670 2600 1.33 89313
140 45 445 1410 2300 3.52 89413




Our Bearing Production Range:

Roller Bearings Truck Wheel Bearing
Automotive Hub Bearing
Concret Mixer Bearing
Tapered Roller Bearings
Cylindrical Roller Bearings
Spherical Roller Bearings
Needle Roller Bearings
Thrust Roller Bearings
Ball Bearings Deep Groove Ball Bearings
Angular Contact Ball Bearings
Self-aligning Ball Bearings
Thrust Ball Bearings
Angular Contact Ball Bearings
Other Bearings Clutch Release Bearing
Pillow Block Bearing
Insert Bearings
Joint Bearings
Linear Bearings



FSK Bearing Packings

1. Industrial packing: plastic bag + kraft paper + carton+ plywood pallets
2. Commerical packing:1pc/plastic bag + box + carton + plywood pallets
3. As the customer's requirment



Heavy Load 81213M Cylindrical Needle Roller and Cage Thrust Assemblies ​, Get Cheap Price from China Roller Bearing Factory Now !
