Product Details
Place of Origin: CHINA
Brand Name: FSK / FAG / / TIMKE / NTN / NSK / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: EE231401D/231975
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 7 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
EE291176D/291750 |
Size: |
355.6mm × 501.65mm × 127mm |
Weight: |
70.62kg |
Seals Type: |
Open |
Part Name: |
China Tapered Roller Bearings |
Row: |
Double Row |
Model No.: |
EE291176D/291750 |
Size: |
355.6mm × 501.65mm × 127mm |
Weight: |
70.62kg |
Seals Type: |
Open |
Part Name: |
China Tapered Roller Bearings |
Row: |
Double Row |
TDI Two Row Tapered Roller Bearings EE231401D / 231975 355.6 × 501.65 × 127mm
Double Row Tapered Roller Bearings Description
Double row or two-row tapered roller bearings feature double cups and two single cones. They are available in a variety of configurations for general industrial and automotive applications. These bearings are divided into the TDO type which has one double cup and two single-row cones, and the TDI type which has two single-row cups and one double cone. Both accommodate radial and axial loading in both directions. These two also carry moment loads, however, the TDO type is superior to the TDI type, because the distance between load centers is longer in the TDO type. The spacer of the TDO type, or the TDI type, pre-adjusts the internal clearance to provide proper operating clearance after mounting.
Bearing Specification :
|
Model Number |
EE231401D/231975 |
|
Part Name |
Tapered Roller Bearings |
|
Brand |
FSK / TIMKEN / FAG / KOYO / NSK / NTN / OEM |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Material | Gcr15 Chrome Steel |
| Number of Row | Double Row |
| Type | TDI |
|
Dimensions(mm)(d*D*b) |
355.6mm × 501.65mm × 127mm |
|
Weight / Mass ( KG ) |
70.62kg |
|
HS Code |
8482200000 |
| Original Country Show | CHINA |
Bearings Detailed Pictures :
Part of Thrust Cylindrical Roller Bearings List:
| Model | Old Model | Boundary dimensions (mm) | ||
| d | D | T | ||
| 598/592DC | 598/592DC | 92.075 | 152.4 | 82.55 |
| 90.81/90744K | 90.81/90744K | 96.938 | 188.912 | 107.59 |
| 687/672D | 687/672D | 101.6 | 168.275 | 92.075 |
| 861/854D | 861/854D | 101.6 | 190.5 | 127 |
| HM926749/HM926710D | HM926749/HM926710D | 127.792 | 228.6 | 115.888 |
| 31326X.K11.A160.200 | 31326X.K11.A160.200 | 130 | 280 | 144 |
| 442210 | 442210 | 140 | 2000 | 93.665 |
| 31328X.K11.A180.230 | 31328X.K11.A160.200 | 140 | 3000 | 154 |
| 99575/99102CD | 99575/99102CD | 146.05 | 254 | 149.255 |
| 31330X.K11.A180.230 | 31330X.K11.A180.230 | 150 | 320 | 164 |
| NA46790/SW/46720CD | NA46790-SW/46720CD | 165.1 | 225.425 | 95.25 |
| 173KH350+K | 173KH350+K | 173 | 350 | 155 |
| HM237546DW/HM237510 | 541398 | 177.8 | 288.925 | 123.825 |
| LM241149NW/LM241110D | 37941K | 203.2 | 276.255 | 95.25 |
| M541349/M541310D | M54139/M541310D | 203.2 | 292.1 | 109.538 |
| 220KBE30+L | 220KBE30+L | 220 | 340 | 90 |
| EE126098/126151CD | EE126098/126151CD | 249.25 | 381 | 171.45 |
| LM249747NW/LM249710D | 37951K | 253.975 | 347.662 | 101.6 |
| HH255149D/HH255110 | HH255149D/HH255110 | 279.4 | 457.2 | 244.475 |
| 45T564624T | 45T564624 | 279.4 | 457.2 | 244.48 |
| HH258249TD/HH258210 | HH258249TD/HH258210 | 303.212 | 495.3 | 263.255 |
| L357049NW/L357010CD | 37961K | 304.81 | 393.7 | 107.95 |
| 332169A | 332169A | 305.07 | 500 | 200 |
| LM961548/LM961511D | LM961548/LM961511D | 342.9 | 457.089 | 142.875 |
| L163149/L163110CD | L163149/L163110CD | 355.6 | 444.5 | 136.525 |
| NA231400/231976CD | NA231400/231976CD | 355.6 | 501.65 | 146.05 |
| HM265049/HM565010D | 97974 | 368.249 | 523.875 | 214.312 |
| HM265049TDS/HM265010S | HN265049TDS/HM265010S | 368.3 | 523.875 | 185.738 |
| M270749ADW/M270710 | M270749ADW/M270710 | 447.675 | 635 | 223.838 |
| EE243196/243251CD | EE243196/243251CD | 498.475 | 634.873 | 177.8 |
Our Bearing Production Range:
| Roller Bearings | Truck Wheel Bearing |
| Automotive Hub Bearing | |
| Concret Mixer Bearing | |
| Tapered Roller Bearings | |
| Cylindrical Roller Bearings | |
| Spherical Roller Bearings | |
| Needle Roller Bearings | |
| Thrust Roller Bearings | |
| Ball Bearings | Deep Groove Ball Bearings |
| Angular Contact Ball Bearings | |
| Self-aligning Ball Bearings | |
| Thrust Ball Bearings | |
| Angular Contact Ball Bearings | |
| Other Bearings | Clutch Release Bearing |
| Pillow Block Bearing | |
| Insert Bearings | |
| Joint Bearings | |
| Linear Bearings |
FSK Bearing Packings
1. Industrial packing: plastic bag + kraft paper + carton+ plywood pallets
2. Commerical packing:1pc/plastic bag + box + carton + plywood pallets
3. As the customer's requirment
Competitive Price EE231401D/231975 Two Row Tapered Roller Bearings 355.6×501.65×127mm, Get Cheap Price from China Roller Bearing Factory Now !
