Product Details
Place of Origin: CHINA
Brand Name: FSK / FAG / NTN / NSK / KOYO / ZWZ / HRB / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 6213
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model No.: |
6213 |
Size: |
65 × 120 × 23mm |
Weight: |
0.99kg |
Seal: |
Withou Seal |
Part Name: |
China Deep Groove Ball Bearing |
Row: |
Single Row |
Model No.: |
6213 |
Size: |
65 × 120 × 23mm |
Weight: |
0.99kg |
Seal: |
Withou Seal |
Part Name: |
China Deep Groove Ball Bearing |
Row: |
Single Row |
Low Noise High Speed Pump Motor Bearings Single Row Chrome Steel
Bearing Specification :
Bearing Model No.
6213
Bearing Name:
Deep Groove Ball Bearing
Bearing Size:
65 × 120 × 23mm
Bearing Weight:
0.99kg
Seal:
Open
Bearing Drawing :
Bearings Detailed Pictures :
6200 Series Deep Groove Ball Bearing List:
Bearing No. | Specification |
Basic Dynamic Load Rating KN |
Limiting Speed | Weight | |||||
d | D | W | r | Kg/pc | |||||
mm inch | mm inch | mm inch | mm inch | Dynamic | Static | Grease | Oil | ||
C | C0 | (r/min) | (r/min) | ||||||
6200 | 10 .3937 | 30 1.1811 | 9 .3543 | 0.6 .024 | 5.1 | 2.39 | 19000 | 26000 | 0.032 |
6201 | 12 .4724 | 32 1.2598 | 10 .3937 | 0.6 .024 | 6.1 | 2.75 | 18000 | 24000 | 0.037 |
6202 | 15 .5906 | 35 1.3780 | 11 .4331 | 0.6 .024 | 7.75 | 3.6 | 17000 | 22000 | 0.045 |
6203 | 17 .6693 | 40 1.5748 | 12 .4724 | 0.6 .024 | 9.6 | 4.6 | 16000 | 20000 | 0.066 |
6204 | 20 .7874 | 47 1.8504 | 14 .5512 | 1.0 .039 | 12.8 | 6.65 | 14000 | 18000 | 0.106 |
6205 | 25 .9843 | 52 2.0470 | 15 .5906 | 1.0 .039 | 14 | 7.85 | 12000 | 16000 | 0.128 |
6206 | 30 1.1811 | 62 2.4409 | 16 .6299 | 1.0 .039 | 19.5 | 11.3 | 10000 | 13000 | 0.199 |
6207 | 35 1.3780 | 72 2.8346 | 17 .6693 | 1.1 .043 | 25.7 | 15.3 | 8800 | 10000 | 0.287 |
6208 | 40 1.5748 | 80 3.1496 | 18 .7087 | 1.1 .043 | 29.1 | 17.8 | 7700 | 9200 | 0.367 |
6209 | 45 1.7717 | 85 3.3465 | 19 .7480 | 1.1 .043 | 32.5 | 20.4 | 6800 | 8200 | 0.416 |
6210 | 50 1.9685 | 90 3.5433 | 20 .7874 | 1.1 .043 | 35 | 23.2 | 6100 | 7300 | 0.462 |
6211 | 55 2.1654 | 100 3.9370 | 21 .8268 | 1.5 .059 | 43.5 | 29.2 | 5500 | 6600 | 0.602 |
6212 | 60 2.3622 | 110 4.3307 | 22 .8661 | 1.5 .059 | 52.5 | 36 | 5000 | 6000 | 0.789 |
6213 | 65 2.5591 | 120 4.7244 | 23 .9055 | 1.5 .059 | 58.5 | 40.5 | 4800 | 5800 | 0.99 |
6214 | 70 2.7559 | 125 4.9213 | 24 .9449 | 1.5 .059 | 63.7 | 45 | 4600 | 5600 | 1.1 |
6215 | 75 2.9528 | 130 5.1181 | 25 .9843 | 1.5 .059 | 68.9 | 49 | 4400 | 5400 | 1.2 |
6216 | 80 3.1496 | 140 5.1181 | 26 1.0236 | 2.0 .078 | 72.5 | 53 | 4200 | 5300 | 1.4 |
Our Deep Groove Ball Bearings:
Deep groove ball bearings 6209
miniature thin-wall bearings,and different types of low noise,non-standard and special bearings.
(1) bearing bore diameter:3mm-50mm
(2) Bearing range:
60series bearing:606,607.608,6000,6001,6002,6003,6004,6005,6006,6007,6008,6009, 6010,6012,6013,6014,6015
62series bearing :626,627,628,629,6200,6201,6202,6203,6204,6205,6206,6207,6208,6209,6210,
6211,6212
63series bearing:6300,6301,6302,6303,6304,6305,6306,6307,6308,6309,6310,6311,6312 67series bearing:6705
68series bearing:686,687,688,689,6800,6801,6802,6803,6804,6805,6806,6807,6808,6809,6810 69series bearing:696,697,698,699,6900,6901,6902,6903,6904,6905,6906,6907,6908,6909,6910 16000series bearing:16001,16002,16003,16005,16007
(3) bearing Sealing form:OPEN,RS,2RS,Z,ZZ,RZ,2RZ,N,NR
(4) bearing Material:Gcr15
(5) Quality standard: ISO9001:2000
(6) Chief uses:automatic transmission mechanisms, home appliance motors, motorcycles, power tools, sports goods, office applianceal
Our Bearing Production Range:
1. Tapered Roller Bearing
2. Deep Groove Ball Bearing
3. Truck Wheel Bearing
4. Automobile Wheel Bearing
5. Cement Mixer Bearing
6. Clutch Release Bearing
7. Self Aligning Ball Bearing
8. Cylindrical Roller Bearing
9. Needle Bearing
10. Angular Contact Bearing
11. Thrust Ball Bearing
12. Thrust Roller Bearing
13. Pillow Block Bearing
14. Spherical Roller Bearing
Low Noise High Speed Pump Motor Bearings Single Row Chrome Steel , Get Cheap Price from China Deep Groove Ball Bearing Factory Now !
