Home ProductsDeep Groove Ball Bearing

6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump

6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump

  • 6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump
  • 6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump
  • 6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump
6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump
Product Details:
Place of Origin: JAPAN
Brand Name: NTN / NSK / FAG / TIMKEN / KOYO / FSK / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 6206ZZ
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Model No.: 6206ZZ Size: 30 × 62 × 16mm
Weight: 0.199kg Cage: Steel Cage
Part Name: China Cheap Ball Bearings Character: Steel Cage , Single Row , Double Shield
High Light:

deep groove bearing

,

double row deep groove ball bearing



6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump



About Deep Groove Ball Bearings

Deep Groove Ball Bearing Usage:
They are widely used of vehicles, motorcycles, home electrical appliances, electric tools and mineral machineries.
Deep groove ball bearings features :
Deep Groove ball bearings are the most popular of all the ball bearing types because they are available in a wide variety of seal, shield and snap-ring arrangements.The bearing ring grooves are circular arcs made slightly larger than the radius of the ball.The balls make point contact with the raceways (elliptical contact when loaded). The inner ring shoulders are of equal height (as the outer ring shoulders). Deep Groove ball bearings can sustain radial, axial, or composite loads and because of simple design, this bearing type can be produced to provide both high-running accuracy and high-speed operation. Standard ball retainers (cages) are made from pressed steel. Machined cages are used in bearing operation at very high speed or for large diameter bearings.Deep Groove ball bearings with seals or shields are standardized. They contain proper amount of grease in advance.
Deep groove ball bearings types:
1, single row deep groove ball bearings
2, single row deep groove ball bearings with dust cover
3, with a dust cover, a ring of single row deep groove ball bearings
4, the outer ring on the stopper groove and snap ring of single row deep groove ball bearings
5, deep groove ball bearings ball gap
6, double row deep groove ball bearings
In accordance with the sizes of deep groove ball bearings can be divided into:
(1) miniature bearings ---- nominal diameter size range of 26mm bearings;
(2) small bearing ---- nominal diameter size range of 28-55mm bearings;
(3) small and medium-sized bearings ---- nominal diameter size range of 60-115mm bearings;
(4) large bearing ---- nominal diameter size range of 120-190mm bearings
(5) large bearing ---- nominal diameter size range of 200-430mm bearings;
(6) ---- large bearing diameter size range of 440mm or more bearings.



Production Work Flow

6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump 0



Bearing Specification :

Model Number

6206ZZ

Part Name

Deep Groove Ball Bearings

Brand

NTN / NSK / FAG / TIMKEN / KOYO / FSK / OEM

Precision Rating

ABEC-1 to ABEC-9

Vibration and Noise Z0V0 / Z1V1 / Z2V2 / Z3V3
Material Gcr15 Chrome Steel
Number of Row Single Row
Cage Steel Cage

Dimensions(mm)(d*D*b)

30 × 62 × 16mm

Weight / Mass ( KG )

0.199kg

HS Code

8482102000

Original Country Show JAPAN



Bearing Drawing :

6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump 1

Bearings Detailed Pictures :

6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump 2



6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump 3



6200 Series Deep Groove Ball Bearing List:

Bearing No. Specification

Basic Dynamic

 Load Rating KN

Limiting Speed Weight
d D W r Kg/pc
mm  inch mm  inch mm  inch mm  inch Dynamic Static Grease Oil
        C C0 (r/min) (r/min)
6200 10   .3937 30  1.1811 9    .3543 0.6   .024 5.1 2.39 19000 26000 0.032
6201 12   .4724 32  1.2598 10  .3937 0.6   .024 6.1 2.75 18000 24000 0.037
6202 15   .5906 35  1.3780 11  .4331 0.6   .024 7.75 3.6 17000 22000 0.045
6203 17   .6693 40  1.5748 12  .4724 0.6   .024 9.6 4.6 16000 20000 0.066
6204 20   .7874 47  1.8504 14  .5512 1.0   .039 12.8 6.65 14000 18000 0.106
6205 25   .9843 52  2.0470 15  .5906 1.0   .039 14 7.85 12000 16000 0.128
6206 30   1.1811 62  2.4409 16  .6299 1.0   .039 19.5 11.3 10000 13000 0.199
6207 35   1.3780 72  2.8346 17  .6693 1.1   .043 25.7 15.3 8800 10000 0.287
6208 40   1.5748 80  3.1496 18  .7087 1.1   .043 29.1 17.8 7700 9200 0.367
6209 45   1.7717 85  3.3465 19  .7480 1.1   .043 32.5 20.4 6800 8200 0.416
6210 50   1.9685 90  3.5433 20  .7874 1.1   .043 35 23.2 6100 7300 0.462
6211 55   2.1654 100 3.9370 21  .8268 1.5   .059 43.5 29.2 5500 6600 0.602
6212 60   2.3622 110 4.3307 22 .8661 1.5   .059 52.5 36 5000 6000 0.789
6213 65   2.5591 120 4.7244 23 .9055 1.5   .059 58.5 40.5 4800 5800 0.99
6214 70   2.7559 125 4.9213 24 .9449 1.5   .059 63.7 45 4600 5600 1.1
6215 75   2.9528 130 5.1181 25 .9843 1.5   .059 68.9 49 4400 5400 1.2
6216 80   3.1496 140 5.1181 26 1.0236 2.0   .078 72.5 53 4200 5300 1.4



Our Bearing Production Range:

1.Tapered Roller Bearing
2. Deep Groove Ball Bearing

3. Truck Wheel Bearing

4. Automobile Wheel Bearing

5. Cement Mixer Bearing

6. Clutch Release Bearing

7. Self Aligning Ball Bearing
8. Cylindrical Roller Bearing
9. Needle Bearing
10. Angular Contact Bearing
11. Thrust Ball Bearing
12. Thrust Roller Bearing
13. Pillow Block Bearing
14. Spherical Roller Bearing



Why Choose FSK Bearing Company :
1. Enterprise group combines manufacture and international trade;
2. More than 10 years experience in bearing manufacturing and international trading;
3. Strict quality controll system with perfect facilities;
4. High technology enterprise with advanced production facilities;
5. Prompt delivery and all-around after-sales service;
6. OEM service and small order is accepted;
7. Customers' drawing or samples accepted.



6206ZZ NTN Shielded Bearings Single Row Chrome Steel for Water Pump​ ​, Get Cheap Price from China Ball Bearing Factory Now !
