300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed

300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed

  • 300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed
  • 300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed
  • 300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed
  • 300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed
300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed
Product Details:
Place of Origin: CHINA
Brand Name: FSK / FAG / NTN / NSK / KOYO / ZWZ / HRB / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 61805-2RS1
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Model No.: 61805-2RS1 Size: 25 × 37 × 7mm
Weight: 0.022kg Cage: Steel Cage
Part Name: China Miniature Deep Groove Ball Bearings Character: Small Size
High Light:

deep groove bearing

,

double row deep groove ball bearing



300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed



About Deep Groove Ball Bearings

Deep Groove Ball Bearing Usage:
They are widely used of vehicles, motorcycles, home electrical appliances, electric tools and mineral machineries.
Deep groove ball bearings features :
Deep Groove ball bearings are the most popular of all the ball bearing types because they are available in a wide variety of seal, shield and snap-ring arrangements.The bearing ring grooves are circular arcs made slightly larger than the radius of the ball.The balls make point contact with the raceways (elliptical contact when loaded). The inner ring shoulders are of equal height (as the outer ring shoulders). Deep Groove ball bearings can sustain radial, axial, or composite loads and because of simple design, this bearing type can be produced to provide both high-running accuracy and high-speed operation. Standard ball retainers (cages) are made from pressed steel. Machined cages are used in bearing operation at very high speed or for large diameter bearings.Deep Groove ball bearings with seals or shields are standardized. They contain proper amount of grease in advance.
Deep groove ball bearings types:
1, single row deep groove ball bearings
2, single row deep groove ball bearings with dust cover
3, with a dust cover, a ring of single row deep groove ball bearings
4, the outer ring on the stopper groove and snap ring of single row deep groove ball bearings
5, deep groove ball bearings ball gap
6, double row deep groove ball bearings
In accordance with the sizes of deep groove ball bearings can be divided into:
(1) miniature bearings ---- nominal diameter size range of 26mm bearings;
(2) small bearing ---- nominal diameter size range of 28-55mm bearings;
(3) small and medium-sized bearings ---- nominal diameter size range of 60-115mm bearings;
(4) large bearing ---- nominal diameter size range of 120-190mm bearings
(5) large bearing ---- nominal diameter size range of 200-430mm bearings;
(6) ---- large bearing diameter size range of 440mm or more bearings.



Production Work Flow

300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed 0

Bearing Specification :

Model Number

61805-2RS1

Part Name

Deep Groove Ball Bearings

Brand

FSK / FAG / NTN / NSK / KOYO / ZWZ / HRB / OEM

Precision Rating

ABEC-1 to ABEC-9

Vibration and Noise Z0V0 / Z1V1 / Z2V2 / Z3V3
Material Gcr15 Chrome Steel
Number of Row Single Row
Cage Steel Cage

Dimensions(mm)(d*D*b)

25 × 37 × 7mm

Weight / Mass ( KG )

0.022kg

HS Code

8482102000

Original Country Show CHINA



Bearing Drawing :300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed 1

Bearings Detailed Pictures :

300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed 2



61000 Series Deep Groove Ball Bearings List:

TJ No. Dimensions Load Ratings Weight
Open ZZ 2RS d D B r Dynamic Static
61802 61802ZZ 61802-2RS 15 24 5 0.3 1.92 1.18 0.008
61803 61803ZZ 61803-2RS 17 26 5 0.3 2.18 1.28 0.008
61804 61804ZZ 61804-2RS 20 32 7 0.3 3.45 2.25 0.02
61805 61805ZZ 61805-2RS 25 37 7 0.3 3.7 2.65 0.022
61806 61806ZZ 61806-2RS 30 42 7 0.3 4 3.15 0.026
61807 61807ZZ 61807-2RS 35 47 7 0.3 4.12 3.45 0.03
61808 61808ZZ 61808-2RS 40 52 7 0.3 4.4 3.5 0.034
61809 61809ZZ 61809-2RS 45 58 7 0.3 4.65 4.32 0.04
61810 61810ZZ 61810-2RS 50 65 7 0.3 5.1 4.68 0.057
61811 61811ZZ 61811-2RS 55 72 9 0.3 6.72 6.5 0.083
61812 61812ZZ 61812-2RS 60 78 10 0.3 9.15 8.75 0.11
61813 61813ZZ 61813-2RS 65 85 10 0.6 10 9.32 0.114
61814 61814ZZ 61814-2RS 70 90 10 0.6 10.5 10.8 0.13
61815 61815ZZ 61815-2RS 75 95 10 0.6 10.6 11 0.15
61816 61816ZZ 61816-2RS 80 100 10 0.6 11 11.8 0.16
61903 61903ZZ 61903-2RS 17 30 7 0.3 4.3 2.32 0.02
61904 61904ZZ 61904-2RS 20 37 9 0.3 6.55 3.6 0.04
61905 61905ZZ 61905-2RS 25 42 9 0.3 7.36 4.55 0.05
61906 61906ZZ 61906-2RS 30 47 9 0.3 7.55 5.08 0.06
61907 61907ZZ 61907-2RS 35 55 10 0.6 9.55 6.85 0.086
61908 61908ZZ 61908-2RS 40 62 12 0.6 12 8.98 0.11
61909 61909ZZ 61909-2RS 45 68 12 0.6 12.3 9.72 0.14
61910 61910ZZ 61910-2RS 50 72 12 0.6 12.8 11.2 0.14
61911 61911ZZ 61911-2RS 55 80 13 1 13 13.5 0.19
61912 61912ZZ 61912-2RS 60 85 13 1 14 14.2 0.22
61913 61913ZZ 61913-2RS 65 90 13 1 14.5 17 0.23
61914 61914ZZ 61914-2RS 70 100 16 1 16.5 17.2 0.35
61915 61915ZZ 61915-2RS 75 105 16 1 18 17.5 0.42
61916 61916ZZ 61916-2RS 80 110 16 1 27.57 25.2

0.44



Our Bearing Production Range:

1.Tapered Roller Bearing
2. Deep Groove Ball Bearing

3. Truck Wheel Bearing

4. Automobile Wheel Bearing

5. Cement Mixer Bearing

6. Clutch Release Bearing

7. Self Aligning Ball Bearing
8. Cylindrical Roller Bearing
9. Needle Bearing
10. Angular Contact Bearing
11. Thrust Ball Bearing
12. Thrust Roller Bearing
13. Pillow Block Bearing
14. Spherical Roller Bearing



Why Choose FSK Bearing Company :
1. Enterprise group combines manufacture and international trade;
2. More than 10 years experience in bearing manufacturing and international trading;
3. Strict quality controll system with perfect facilities;
4. High technology enterprise with advanced production facilities;
5. Prompt delivery and all-around after-sales service;
6. OEM service and small order is accepted;
7. Customers' drawing or samples accepted.



300℃ High Temperature 61805-2RS1 Mini Ball Bearings Double Sealed​ , Get Cheap Price from China Roller Bearing Factory Now !
