Product Details
Place of Origin: CHINA
Brand Name: FAG / NTN / NSK / KOYO / ZWZ / FSK / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 22224-E1
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model No.: |
22224-E1 |
Size: |
120 × 215 × 58mm |
Weight: |
8.84kg |
Cage: |
Steel Cage |
Part Name: |
China Spherical Roller Bearing |
Character: |
DOUBLE ROW,SPECIAL RADIAL RUNOUT |
Model No.: |
22224-E1 |
Size: |
120 × 215 × 58mm |
Weight: |
8.84kg |
Cage: |
Steel Cage |
Part Name: |
China Spherical Roller Bearing |
Character: |
DOUBLE ROW,SPECIAL RADIAL RUNOUT |
Steel Cage 22224-E1 FAG Vibrating Screen Bearings Double Row
About Spherical roller bearings :
1 Ability to carry heavy loads
2 Less coefficient of friction
3 High limiting speed
4 Large size range: inner Diameter from 5mm- 750mm
5 Variations of structure: CC,CA,K,W33, N,NR, MB
20200; 20300; 20400; 22200; 22300; 21000; 23000; 23100; 24000; 24100 series
Spherical roller bearings are inherently self-aligning and very robust. They have two rows of rollers which make the bearings able to carry heavy loads. The present range of spherical roller bearings mainly includes CC, CA, MB and E type. Qifan Co can provide a wide range of sizes of several ISO Dimension Series and also includes special designs, for example, for vibrating screens and other applications. Special bearings can also be customized as required based on the standard bearings.
Spherical Roller Bearing Application:
Self aligning roller bearings apply to precise instrument, the electrical appliance of low noise, automobile,
motorbike and other machines. It is used the most widely in mechanical industry. We can also supply various types of bearings according to your sample and design.
Manufacturing high-grade products is our permanent goal.
Production Work Flow
Bearing Specification :
|
Model Number |
22224-E1 |
|
Part Name |
Spherical Roller Bearing |
|
Brand |
FAG / NTN / NSK / KOYO / ZWZ / FSK / OEM |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Material | Gcr15 Chrome Steel |
| Number of Row | Double Row |
| Cage | Steel Cage |
|
Dimensions(mm)(d*D*b) |
120 × 215 × 58mm |
|
Weight / Mass ( KG ) |
8.84kg |
|
HS Code |
8482300000 |
| Original Country Show | CHINA |
Bearing Drawing :
Bearings Detailed Pictures :
22000 Series Spherical Roller Bearings List:
| Bearing No. | Specification | ||
| d(mm) | D(mm) | B(mm) | |
| 22205 | 25 | 52 | 18 |
| 22206 | 30 | 62 | 20 |
| 22206W33 | 30 | 62 | 20 |
| 22207 | 35 | 72 | 23 |
| 22207W33 | 35 | 72 | 23 |
| 22208 | 40 | 80 | 23 |
| 22208W33 | 40 | 80 | 23 |
| 22209 | 45 | 85 | 23 |
| 22209W33 | 45 | 85 | 23 |
| 22210 | 50 | 90 | 23 |
| 22210W33 | 50 | 90 | 23 |
| 22210K | 50 | 90 | 23 |
| 22211 | 55 | 100 | 25 |
| 22211W33 | 55 | 100 | 25 |
| 22211K | 55 | 100 | 25 |
| 22212 | 60 | 110 | 28 |
| 22212W33 | 60 | 110 | 28 |
| 22212K | 60 | 110 | 28 |
| 22213 | 65 | 120 | 31 |
| 22213W33 | 65 | 120 | 31 |
| 22213K | 65 | 120 | 31 |
| 22214 | 70 | 125 | 31 |
| 22214W33 | 70 | 125 | 31 |
| 22214K | 70 | 125 | 31 |
| 22215 | 75 | 130 | 31 |
| 22215W33 | 75 | 130 | 31 |
| 22215K | 75 | 130 | 31 |
| 22216 | 80 | 140 | 33 |
| 22216W33 | 80 | 140 | 33 |
| 22216K | 80 | 140 | 33 |
| 22217 | 85 | 150 | 36 |
| 22217W33 | 85 | 150 | 36 |
| 22217K | 85 | 150 | 36 |
| 22218 | 90 | 160 | 40 |
| 22218W33 | 90 | 160 | 40 |
| 22218K | 90 | 160 | 40 |
| 22219 | 95 | 170 | 43 |
| 22219W33 | 95 | 170 | 43 |
| 22219K | 95 | 170 | 43 |
| 22220 | 100 | 180 | 46 |
| 22220W33 | 100 | 180 | 46 |
| 22220K | 100 | 180 | 46 |
| 22222 | 110 | 200 | 53 |
| 22222W33 | 110 | 200 | 53 |
| 22222K | 110 | 200 | 53 |
| 22224 | 120 | 215 | 58 |
| 22224W33 | 120 | 215 | 58 |
| 22224K | 120 | 215 | 58 |
| 22226 | 130 | 230 | 64 |
| 22226W33 | 130 | 230 | 64 |
| 22226K | 130 | 230 | 64 |
| 22228 | 140 | 250 | 68 |
| 22228W33 | 140 | 250 | 68 |
| 22228K | 140 | 250 | 68 |
| 22230 | 150 | 270 | 73 |
| 22230W33 | 150 | 270 | 73 |
| 22230K | 150 | 270 | 73 |
| 22232 | 160 | 290 | 80 |
| 22232W33 | 160 | 290 | 80 |
| 22232K | 160 | 290 | 80 |
| 22234 | 170 | 310 | 86 |
| 22234W33 | 170 | 310 | 86 |
| 22234K | 170 | 310 | 86 |
| 22236 | 180 | 320 | 86 |
| 22236W33 | 180 | 320 | 86 |
| 22236K | 180 | 320 | 86 |
| 22238 | 190 | 340 | 92 |
| 22238W33 | 190 | 340 | 92 |
| 22238K | 190 | 340 | 92 |
| 22240 | 200 | 360 | 98 |
| 22240W33 | 200 | 360 | 98 |
| 22240K | 200 | 360 | 98 |
| 22244 | 220 | 400 | 108 |
| 22244W33 | 220 | 400 | 108 |
| 22244K | 220 | 400 | 108 |
| 22248 | 240 | 440 | 120 |
| 22248W33 | 240 | 440 | 120 |
| 22248K | 240 | 440 | 120 |
| 22252 | 260 | 480 | 130 |
| 22252W33 | 260 | 480 | 130 |
| 22252K | 260 | 480 | 130 |
Our Bearing Production Range:
1.Tapered Roller Bearing
2. Deep Groove Ball Bearing
3. Truck Wheel Bearing
4. Automobile Wheel Bearing
5. Cement Mixer Bearing
6. Clutch Release Bearing
7. Self Aligning Ball Bearing
8. Cylindrical Roller Bearing
9. Needle Bearing
10. Angular Contact Bearing
11. Thrust Ball Bearing
12. Thrust Roller Bearing
13. Pillow Block Bearing
14. Spherical Roller Bearing
Why Choose FSK Bearing Company :
1. Enterprise group combines manufacture and international trade;
2. More than 10 years experience in bearing manufacturing and international trading;
3. Strict quality controll system with perfect facilities;
4. High technology enterprise with advanced production facilities;
5. Prompt delivery and all-around after-sales service;
6. OEM service and small order is accepted;
7. Customers' drawing or samples accepted.
