Miniature Size 129 TN9 1200 ETN9 2200 E 2RS1TN9 Self Aligning Ball Bearings Double Row

Miniature Size 129 TN9 1200 ETN9 2200 E 2RS1TN9 Self Aligning Ball Bearings Double Row

129 TN9 Bearing Specification :

Bearings Drawing :

Bearings Detailed Pictures

Same Series Bearings We Do:

Principal dimension mm				Cons	Axle load cofeeicient			Cylindrical bore		Tapered bore		Basic load ratings KN		Abutment and fillet dimensions mm			Speed ratings rpm		Weight kg
				tant
d	D	B	r	e	Y1	Y2	Y0	Old Bearing Number	Currrent Bearing	Old Bearing Number	Currrent Bearing	dyc	stc	Ds(min)	dh(max)	R(max)	Grease	Oil	Cylindrical bore	Tapered bore
												Cr	Cor
30	62	16	1	0.25	2.5	3.87	2.62	1206	1206	111206	1206K	12	4.7	35	57	1	10000	13000	0.228	0.223
30	62	20	1	0.39	1.63	2.53	1.71	1506	2206	111506	2206K	11.7	4.56	35	57	1	9500	12000	0.26	0.254
30	62	20	1	0.39	1.63	2.53	1.71	1506A	2206TN1	111506A	2206KTN1	11.7	4.56	35	57	1	9500	12000	0.242
30	72	27	1.1	0.44	1.43	2.22	1.5	1606	2306	111606	2306K	24	8.68	36.5	65.5	1	8500	10000	0.515	0.515
30	72	27	1.1	0.44	1.43	2.22	1.5	1606A	2306TN1	111606A	2306KTN1	24	8.68	36.5	65.5	1	8500	10000	0.494
35	72	17	1.1	0.23	2.74	4.24	2.87	1207	1207	111207	1207K	12.1	5.12	41.5	65.5	1	9000	11000	0.318	0.312
35	72	17	1.1	0.23	2.74	4.24	2.87	1207A	1207TN1	111207A	1207KTN1	12.1	5.12	41.5	65.5	1	9000	11000	0.309	0.303
35	72	23	1.1	0.37	1.69	2.61	1.77	1507	2207	111507	2207K	16.5	6.66	41.5	65.5	1	8500	10000	0.604	0.544
35	72	23	1.1	0.37	1.69	2.61	1.77	1507A	2207TN1	111507A	2207KTN1	16.5	6.66	41.5	65.5	1	8500	10000	0.587
35	80	21	1.5	0.25	2.56	3.97	2.69	1307	1307	111307	1307K	19.6	7.94	43	72	1.5	7500	9000	0.507	0.48
35	80	21	1.5	0.25	2.56	3.97	2.69	111307	1307TN1	111307A	1307KTN1	18.7	7.38	43	72	1.5	7500	9000	0.486	0.475
35	80	31	1.5	0.46	1.36	2.11	1.43	1607	2307	111607	2307K	30	11.1	43	72	1.5	7000	8500	0.675	0.662
35	80	31	1.5	0.46	1.36	2.11	1.43	1607A	2307TN1	111607A	2307KTN1	30	11.1	43	72	1.5	7000	8500	0.659
40	80	18	1.1	0.22	2.87	4.45	3.01	1208	1208	111208	1208K	14.8	6.51	46.5	73.5	1	8500	10000	0.41	0.402
40	80	18	1.1	0.22	2.87	4.45	3.01	1208A	1208TN1	111208A	1208KTN1	14.8	6.51	46.5	73.5	1	8500	10000	0.402	0.391
40	80	23	1.1	0.33	1.9	2.94	1.99	1508	2208	111508	2208K	17.1	7.37	46.5	73.5	1	7500	9000	0.52	0.52
40	80	23	1.1	0.33	1.9	2.94	1.99	1508A	2208TN1	111508A	2208KTN1	16.4	6.91	46.5	73.5	1	7500	9000	0.476	0.475
40	90	23	1.5	0.24	2.62	4.05	2.74	1308	1308	111308	1308K	22.8	9.83	48	82	1.5	6700	8000	0.714	0.714
40	90	23	1.5	0.24	2.62	4.05	2.74	1308A	1308TN1	111308A	1308KTN1	21.8	9.18	48	82	1.5	6700	8000	0.688	0.688
40	90	33	1.5	0.43	1.45	2.25	1.52	1608	2308	111608	2308K	34.2	13.2	48	82	1.5	6300	7500	0.959	0.944
40	90	33	1.5	0.43	1.45	2.25	1.52	1608A	2308TN1	111608A	2308KTN1	32.3	12.1	48	82	1.5	6300	7500	0.901	0.901
45	85	19	1.1	0.21	2.94	4.55	3.08	1209	1209	111209	1209K	16.7	7.33	51.5	78.5	1	7500	9000	0.469	0.46
45	85	19	1.1	0.21	2.94	4.55	3.08	1209A	1209TN1	111209A	1209KTN1	16.7	7.33	51.5	78.5	1	7500	9000	0.458	0.446
45	85	23	1.1	0.31	2.04	3.15	2.13	1509	2209	111509	2209K	17.8	8.11	51.5	78.5	1	7000	8500	0.553	0.5
45	85	23	1.1	0.31	2.04	3.15	2.13	1509A	2209TN1	111509A	2209KTN1	16.5	7.21	51.5	78.5	1	7000	8500	0.553	0.5
45	100	25	1.5	0.25	2.53	3.92	2.66	1309	1309	111309	1309K	29.4	12.8	53	92	1.5	6300	7500	0.951	0.946
45	100	25	1.5	0.25	2.53	3.92	2.66	1309A	1309TN1	111309A	1309KTN1	28.1	12	53	92	1.5	6300	7500	0.92	0.915
45	100	36	1.5	0.42	1.51	2.33	1.58	1609	2309	111609	2309K	41.5	16.3	53	92	1.5	5600	6700	1.24	1.23
50	90	19	1.1	0.2	3.13	4.85	3.28	1210	1210	111210	1210K	17.4	8.09	56.5	83.5	1	7000	8500	0.547	0.543
50	90	20	1.1	0.2	3.13	4.85	3.28	1210A	1210TN1	111210A	1210KTN1	17.4	8.09	56.5	83.5	1	7000	8500	0.535	0.531
50	90	23	1.1	0.29	2.2	3.41	2.31	1510	2210	111510	2210K	17.2	8.02	56.5	83.5	1	6300	7500	0.618	0.539
50	90	23	1.1	0.29	2.2	3.41	2.31	1510A	2210TN1	111510A	2210KTN1	16.6	7.58	56.5	83.5	1	6300	7500	0.567	0.489
50	110	27	2	0.24	2.68	4.14	2.8	1310	1310	111310	1310K	33.5	14.1	59	101	2	5600	6700	1.21	1.19
50	110	40	2	0.42	1.49	2.3	1.56	1610	2310	111610	2310K	49.1	19.7	59	101	2	5300	6300	1.66	1.65
55	100	21	1.5	0.2	3.23	4.99	3.38	1211	1211	111211	1211K	20.6	10	63	95	1.5	6300	7500	0.708	0.708
55	100	21	1.5	0.2	3.23	4.99	3.38	1211A	1211TN1	111211A	1211KTN1	20.6	10.3	63	95	1.5	6300	7500	0.681	0.68
55	100	25	1.5	0.28	2.26	3.5	2.37	1511	2211	111511	2211K	19.7	9.42	63	95	1.5	6000	7000	0.824	0.812
55	120	29	2	0.23	2.7	4.18	2.83	1311	1311	111311	1311K	39.8	18.2	64	111	2	5000	6000	1.57	1.57
55	120	29	2	0.23	2.7	4.18	2.83	1311A	1311TN1	111311A	1311KTN1	38	16.9	64	111	2	5000	6000	1.51	1.52
55	120	43	2	0.41	1.53	2.36	1.6	1611	2311	111611	2311K	57.5	23.5	64	111	2	4800	5600	2.1	2.05
60	110	22	1.5	0.19	3.39	5.25	3.56	1212	1212	111212	1212K	23.3	11.6	68	102	1.5	5600	6700	0.892	0.877
60	110	22	1.5	0.19	3.39	5.25	3.56	1212A	1212TN1	111211A	1212KTN1	23.3	11.6	68	102	1.5	5600	6700	0.87	0.855
60	110	28	1.5	0.28	2.27	3.51	2.38	1512	2212	111512	2212K	27.1	13.2	68	102	1.5	5300	6300	1.16	1.14
60	110	28	1.5	0.28	2.27	3.51	2.38	1512A	2212TN1	111512A	2212KTN1	26.1	12.5	68	102	1.5	5300	6300	1.09	1.07
60	130	31	2.1	0.23	2.8	4.33	2.93	1312	1312	111312	1312K	44.8	21.1	71	119	2	4500	5300	1.98	1.98
60	130	31	2.1	0.23	2.8	4.33	2.93	1312A	1312TN1	111312A	1312KTN1	43	19.8	71	119	2	4500	5300	1.92	1.9
60	130	46	2.1	0.4	1.56	2.41	1.63	1612	2312	111612	2312K	66.4	27.6	71	119	2	4500	5300	2.61	2.6
60	150	35	2.1	0.22	2.81	4.35	2.95	1412	1412	111412	1412	59	28.4	71	139	2	3800	4500	3.26
60	150	35	2.1	0.22	2.81	4.35	2.95	1412H	1412M	111412H	1412KM	56.5	26.7	71	139	2	3800	4500	3.31
65	120	23	1.5	0.17	3.71	5.73	3.88	1213	1213	111213	1213K	24	12.3	73	112	1.5	5300	6300	0.915	0.915

Our other Hot Sale Bearings

Our Company Photo:

About Us:

1.Direct China factory/Manufactur with strong Capability
We are direct bearing factory on Jiangsu, China for more than 10 years.300 bearing types,15 million sets items ar produced yearly and the output value more than 15 million US dollars last year.
We could complete all ordere items excellently with over one hundred of advanced equipments running in 6 plants in China.
2.Large ready stock&Fast Delivery Time
Rich in stock throughout the year for general bearing types,sush as Deep groove ball bearing,Tapered Roller Bearing,Thrust Ball Bearing,etc.
Based on above advantages,we delivery goods timely&fastly as your requests.Warehouse items would deliveried within 1-2 days.
By courier/air or by cargo/sea
3.Competitive price
Large stock and strong Capability enables us to offer more reasonable price all over the world. Customers could receive good quality bearings with attrative price at the same time from us.
4.Non-standard Customized Service
We could customize many non-standard bearings and workpiece as your drawing requests and offer in-house test report by professional engineers.All customized goods are made to order as requests.
5.Perfect Quality Control System
We have perfect quality control systems and testing equipments and experienced engineers for more than 10 years.We test bearings one by one assuring all bearings with high proformance.
6.Best After-sale service
Experienced different after-sale workers are online for more than 12hours a day, 7 days a week offering you different bearing solutions for you.
We are glad to receive any comments from all the world by email,by call/message or by Skype/wechat/whatsapp/Viber/QQ..etc.
7. Multi-language communications

FAQ

	Q:Are you a trader or manufacturer?
	A:We are factory specializing in all kind of bearings. We can give you the best price and better service.
	Q:What is your delivery time?
	A:Sample order: Immediate delivery , bulk order: usually 30 days.
	Q:Can i request sample?
	A:Of course , sample is ok and we can give you a sample by free.
	Q:What's the shipping way?
	A:According to YOUR demands.
	Q:Can you accept OEM or ODM?
	A:Yes, of course. logo is also acceptable.
	Q:How is quality controlled?
	A:Quality is the key !
	Our QC team and engineer team works through all the process from an order placed to shipped.
	Q: Can I come for a visit?
	You are welcome to visit our factories , office and showroom ! Please contact our reception and we will help you to make a schedule.

Miniature Size 129 TN9 1200 ETN9 2200 E 2RS1TN9 Self Aligning Ball Bearings Double Row​, Get Cheap Price from China Bearing Factory Now !

Contact With Us Freely :
