IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components

IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components

IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components
IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components
Basic Information
Place of Origin: CHINA
Brand Name: FSK / FAG / NSK / NTN / KOYO / TIMKE / OEM
Certification: ISO9001-2000 / CE / ROHS
Model Number: KT 253224
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement
Delivery Time: 3 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Contact Now
Model No.: KT 253224 KT 253224 Bearing Size: 25 X 32 X 24mm
KT 253224 Bearing Weight: 0.035kg Service: Customized
Row: Single Row Other Bearing Number: KT 253224 Bearing / KT253224 Bearing
Highlight:

Customized Needle Roller Bearing

,

253224 Needle Roller Bearing

,

25 x 32 x 24mm Needle Roller Bearing

IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components



Bearing Specification :

FSK BEARING Model Number

KT 253224

Part Name

Needle Roller Bearing

Brand

FSK / FAG / NSK / NTN / KOYO / TIMKE / OEM

Precision Rating

ABEC-1 to ABEC-9
Material Gcr15 Chrome Steel
Number of Row Single Row

Dimensions(mm)(d*D*b)

 25 x 32 x 24mm

Weight / Mass ( KG )

 0.035kg

HS Code

8482400000
Original Country Show CHINA



KT 253224 Bearing Drawing:

IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components 0



Photo of KT 253224

IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components 1IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components 2IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components 3IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components 4



 Same Series Needle Roller Bearing List :

Bearing Number d D H  Weight
K3×5×7-TV 3 mm 5 mm 7 mm 0.3 g
K3×5×9-TV 3 mm 5 mm 9 mm 0.4 g
K3×6×7-TV 3 mm 6 mm 7 mm 0.4 g
K4×7×7-TV 4 mm 7 mm 7 mm 0.5 g
K4×7×10-TV 4 mm 7 mm 10 mm 0.7 g
K5×8×8-TV 5 mm 8 mm 8 mm 0.7 g
K5×8×10-TV 5 mm 8 mm 10 mm 0.9 g
KT 587N 5 mm 8 mm 7 mm 0.53 g
K6×9×8-TV 6 mm 9 mm 8 mm 0.8 g
K6×9×10-TV 6 mm 9 mm 10 mm 1.1 g
KT 697N 6 mm 9 mm 7 mm 0.63 g
K6×10×13-TV 6 mm 10 mm 13 mm 1.9 g
K7×9×7-TV 7 mm 9 mm 7 mm 0.6 g
K7×10×8-TV 7 mm 10 mm 8 mm 0.9 g
K7×10×10-TV 7 mm 10 mm 10 mm 1 g
K8×11×8-TV 8 mm 11 mm 8 mm 1 g
K8×11×10-TV 8 mm 11 mm 10 mm 1.2 g
K8×11×13-TV 8 mm 11 mm 13 mm 1.7 g
K8×12×10-TV 8 mm 12 mm 10 mm 2 g
KT 8128 8 mm 12 mm 8 mm 2.1 g
K15×19×10 15 mm 19 mm 10 mm 5 g
K15×19×13 15 mm 19 mm 13 mm 7 g
K15×19×17 15 mm 19 mm 17 mm 9.5 g
KT 15199 15 mm 19 mm 9 mm 4.4 g
KT 151911 15 mm 19 mm 11 mm 5.5 g
KT 151918 15 mm 19 mm 18 mm 8.7 g
K15×20×13 15 mm 20 mm 13 mm 7 g
KT 152010 15 mm 20 mm 10 mm 6.3 g
K15×21×15 15 mm 21 mm 15 mm 11 g
K15×21×21 15 mm 21 mm 21 mm 17 g
K16×20×10 16 mm 20 mm 10 mm 5.5 g
K16×20×13 16 mm 20 mm 13 mm 7.5 g
K16×20×17 16 mm 20 mm 17 mm 10 g
KT 162016 16 mm 20 mm 16 mm 8.3 g
KT 162118 16 mm 21 mm 18 mm 12 g
KT 162120 16 mm 21 mm 20 mm 13.6 g
KT 162125 16 mm 21 mm 25 mm 16.6 g
K16×22×12 16 mm 22 mm 12 mm 10 g
K16×22×16 16 mm 22 mm 16 mm 12 g
K16×22×20 16 mm 22 mm 20 mm 17 g
KT 162214 16 mm 22 mm 14 mm 11.5 g
KT 162217 16 mm 22 mm 17 mm 13.8 g
K16×24×20 16 mm 24 mm 20 mm 22 g
K17×21×10 17 mm 21 mm 10 mm 5.5 g
K17×21×13 17 mm 21 mm 13 mm 6.5 g
K17×21×17 17 mm 21 mm 17 mm 9.5 g
KT 172115 17 mm 21 mm 15 mm 8.2 g
KT 172220 17 mm 22 mm 20 mm 14 g
KT 172311 17 mm 23 mm 11 mm 9.6 g
KT 172315 17 mm 23 mm 15 mm 13.1 g
KT 172418 17 mm 24 mm 18 mm 18.6 g
K18×22×10 18 mm 22 mm 10 mm 6 g
K18×22×13 18 mm 22 mm 13 mm 8 g
K18×22×17 18 mm 22 mm 17 mm 11 g
KT 18228 18 mm 22 mm 8 mm 4.7 g
KT 182216 18 mm 22 mm 16 mm 9.2 g
K18×24×12 18 mm 24 mm 12 mm 12 g
K18×24×13 18 mm 24 mm 13 mm 13 g
K18×24×20 18 mm 24 mm 20 mm 18 g
KT 182416 18 mm 24 mm 16 mm 14.8 g
K20×28×20 20 mm 28 mm 20 mm 27 g
K20×28×25 20 mm 28 mm 25 mm 32 g
KT 202814 20 mm 28 mm 14 mm 20 g
K20×30×30 20 mm 30 mm 30 mm 49 g
KT 203225 20 mm 32 mm 25 mm 49.5 g
K21×25×13 21 mm 25 mm 13 mm 9 g
KT 212610 21 mm 26 mm 10 mm 8.5 g
KT 212611 21 mm 26 mm 10 mm 9.6 g
K22×26×10 22 mm 26 mm 10 mm 7.5 g
K22×26×13 22 mm 26 mm 13 mm 9.5 g
K22×26×17 22 mm 26 mm 17 mm 12 g
KT 222720 22 mm 27 mm 20 mm 17.9 g
KT 222726 22 mm 27 mm 26 mm 22.5 g
K22×28×17 22 mm 28 mm 17 mm 18 g
KT 222918 22 mm 29 mm 18 mm 23.5 g
K22×29×16 22 mm 29 mm 16 mm 16 g
KT 222912 22 mm 29 mm 12 mm 16.1 g
KT 222917 22 mm 29 mm 17 mm 22.5 g
K22×30×15-TV 22 mm 30 mm 15 mm 18 g
KT 223230 22 mm 32 mm 30 mm 52.5 g
KT 223232 22 mm 32 mm 32 mm 56 g
K22×32×24 22 mm 32 mm 24 mm 43 g
KT 232824 23 mm 28 mm 24 mm 22 g
KT 232913 23 mm 29 mm 13 mm 15.1 g
KT 233015 23 mm 30 mm 15 mm 21 g
KT 233016 23 mm 30 mm 16 mm 22 g
K23×35×16-TV 23 mm 35 mm 16 mm 29 g
K24×28×10 24 mm 28 mm 10 mm 8.5 g
K24×28×13 24 mm 28 mm 13 mm 10 g
K24×28×17 24 mm 28 mm 17 mm 13 g
KT 242816 24 mm 28 mm 16 mm 12 g
KT 242834 24 mm 28 mm 34 mm 27 g
KT 242913 24 mm 29 mm 13 mm 12.8 g
K24×30×17 24 mm 30 mm 17 mm 19 g
KT 243020 24 mm 30 mm 20 mm 23.5 g
K25×29×10 25 mm 29 mm 10 mm 8.5 g
K25×29×13 25 mm 29 mm 13 mm 11 g
K25×29×17 25 mm 29 mm 17 mm 14 g
KT 252910 25 mm 29 mm 10 mm 7.9 g
K25×30×17 25 mm 30 mm 17 mm 16 g



The Other Bearings We Do

Ball Bearing Deep Groove Ball Bearing 60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **,
160 **(70001 )
Thrust Ball Bearing 511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series
Angular Contact Ball bearing SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series
Roller Bearing Spherical Roller bearing 239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on
Taper Roller Bearing 329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings suchas 938/932 single and double row i.e M255410CD etc.
Thrust Roller Bearing 292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series.
Cylindrical Roller Bearing NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used in Steel Industry.


FSK Bearing Company Advantages:
(1) We have first-class testing equipment to detect bearing various data parameters and control the quality of the bearing.
Whenever bearings must first detected whether the quality is qualified and the unqualified bearing will be eliminated directly.
So we can get the trust of a large number of customers, and supply them for several years.
(2) We have our own R & D capabilities, to help customers solve the problem of non-standard bearings.
We can also according to customer requirements change their own mark.
(3) Price, our manufacture ensure that our prices across China are quite competitive.
It is better for you to compare prices and quality among suppliers.
But everyone knows you can not buy the highest quality products with the lowest price,
but our product is the best quality if you use equal price.



About FSK Bearing Company:
IKO JAPAN KT 253224 Needle Roller Bearing Dimensions Chart Assembled Components 5
