Product Details
Place of Origin: CHINA
Brand Name: FSKG / KBE / FAG / NTN / NSK / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: NA4924
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement
Delivery Time: 3 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
NA4924 |
NA4924 Bearing Size: |
120 X 165 X 45 Mm |
NA4924 Bearing Kg: |
2.86kg |
Inner Ring: |
Inner Ring |
Row: |
Single Row |
Same Bearing: |
NA4924 Bearing/ NA4924-XL Bearing / 4544924 Bearing |
Model No.: |
NA4924 |
NA4924 Bearing Size: |
120 X 165 X 45 Mm |
NA4924 Bearing Kg: |
2.86kg |
Inner Ring: |
Inner Ring |
Row: |
Single Row |
Same Bearing: |
NA4924 Bearing/ NA4924-XL Bearing / 4544924 Bearing |
with Inner Ring NA4924 , 4544924 Needle Roller Bearing Stamped Outer Race
NA4924 Bearing Specification :
|
Model Number |
NA4924 |
| Alternative Bearing | 4544924 (Old Number) NA4924-XL (INA) |
|
Part Name |
Needle Roller Bearing |
| Row | Single Row |
|
Brand |
FSKG / KBE / FAG / NTN / NSK / KOYO / OEM |
|
Precision Rating |
ABEC-5 / ABEC-7 |
| Material | Gcr15 Chrome Steel |
|
Dimensions(mm)(d*D*b) |
120 x 165 x 45 mm |
|
Weight / Mass ( KG ) |
2.86kg |
|
HS Code |
8482800000 |
| Original Country Show | CHINA |
FSK Bearing Other NA, RNA , RNAV , NAV Series Bearings
| NO. | NO. | SIZE (MM) | BASIC LOAD RATING (KN) | LIMITING SPEED | |||||
| with inner | without inner | d | Fw | D | C | rs/min | C | C0 | r/min |
| NA495 | RNA495 | 5 | 7 | 13 | 10 | 0.15 | 2.24 | 2.02 | 27200 |
| NA496 | RNA496 | 6 | 8 | 15 | 10 | 0.15 | 3.14 | 2.62 | 25600 |
| NA497 | RNA497 | 7 | 9 | 17 | 10 | 0.15 | 2.44 | 2.77 | 24000 |
| NA498 | RNA498 | 8 | 10 | 19 | 11 | 0.2 | 4.71 | 3.82 | 22400 |
| NA499 | RNA499 | 9 | 12 | 20 | 11 | 0.3 | 5.02 | 4.79 | 20800 |
| NA4900 | RNA4900 | 10 | 14 | 22 | 13 | 0.3 | 8.5 | 9.2 | 25000 |
| NA4901 | RNA4901 | 12 | 16 | 24 | 13 | 0.3 | 9.4 | 10.9 | 24000 |
| NA4902 | RNA4902 | 15 | 20 | 28 | 13 | 0.3 | 10.6 | 13.6 | 22000 |
| NA4903 | RNA4903 | 17 | 22 | 30 | 13 | 0.3 | 11 | 14.6 | 21000 |
| NA4904 | RNA4904 | 20 | 25 | 37 | 17 | 0.3 | 21 | 25.5 | 17000 |
| NA49/22 | RNA49/22 | 22 | 28 | 39 | 17 | 0.3 | 22.8 | 29.5 | 16000 |
| NA4905 | RNA4905 | 25 | 30 | 42 | 17 | 0.3 | 23.6 | 31.5 | 15000 |
| NA49/28 | RNA49/28 | 28 | 32 | 45 | 17 | 0.3 | 24.4 | 33.5 | 13000 |
| NA4906 | RNA4906 | 30 | 35 | 47 | 17 | 0.3 | 25 | 35.5 | 13000 |
| NA49/32 | RNA49/32 | 32 | 40 | 52 | 20 | 0.6 | 30.5 | 47.5 | 12000 |
| NA4907 | RNA4907 | 35 | 42 | 55 | 20 | 0.6 | 31.5 | 50 | 11000 |
| NA4908 | RNA4908 | 40 | 48 | 62 | 22 | 0.6 | 43 | 67 | 9500 |
| NA4909 | RNA4909 | 45 | 52 | 68 | 22 | 0.6 | 45 | 73 | 8500 |
| NA4910 | RNA4910 | 50 | 58 | 72 | 22 | 0.6 | 47 | 80 | 8000 |
| NA4911 | RNA4911 | 55 | 63 | 80 | 25 | 1 | 58 | 100 | 7500 |
| NA4912 | RNA4912 | 60 | 68 | 85 | 25 | 1 | 60 | 108 | 7000 |
| NA4913 | RNA4913 | 65 | 72 | 90 | 25 | 1 | 61 | 112 | 6500 |
| NA4914 | RNA4914 | 70 | 80 | 100 | 30 | 1 | 84 | 156 | 6000 |
| NA4915 | RNA4915 | 75 | 85 | 105 | 30 | 1 | 86 | 162 | 5500 |
| NA4916 | RNA4916 | 80 | 90 | 110 | 30 | 1 | 89 | 174 | 5000 |
| NA4917 | RNA4917 | 85 | 100 | 120 | 35 | 1.1 | 111 | 237 | 4800 |
| NA4918 | RNA4918 | 90 | 105 | 125 | 35 | 1.1 | 114 | 250 | 4300 |
| NA4919 | RNA4919 | 95 | 110 | 130 | 35 | 1.1 | 116 | 260 | 4400 |
| NA4920 | RNA4920 | 100 | 115 | 140 | 40 | 1.1 | 128 | 270 | 4100 |
| NA4922 | RNA4922 | 110 | 125 | 150 | 40 | 1.1 | 132 | 290 | 3800 |
| NA4924 | RNA4924 | 120 | 135 | 165 | 45 | 1.1 | 181 | 390 | 3400 |
| NA4926 | RNA4926 | 130 | 150 | 180 | 50 | 1.5 | 203 | 470 | 3200 |
| NA4928 | RNA4928 | 140 | 160 | 190 | 50 | 1.5 | 209 | 500 | 3000 |
| Bearing and Weight | Specification mm | Dynamic Load | Static Load | Limited Speed | |||||
| Model | mass g | d | F | D | B | C | CN | CON | rpm |
| NA4900-2RS | 24.5 | 10 | 14 | 22 | 14 | 13 | 7 700 | 6 900 | 13 000 |
| NA4901-2RS | 27.5 | 12 | 16 | 24 | 14 | 13 | 8 600 | 8 300 | 12 000 |
| NA4902-2RS | 37 | 15 | 20 | 28 | 14 | 13 | 9 700 | 10 300 | 10 000 |
| NA4903-2RS | 40 | 17 | 22 | 30 | 14 | 13 | 10 000 | 11 000 | 9 000 |
| NA4904-2RS | 80 | 20 | 25 | 37 | 18 | 17 | 19 500 | 19 900 | 7 500 |
| NA4905-2RS | 89.5 | 25 | 30 | 42 | 18 | 17 | 21 800 | 24 200 | 6 500 |
| NA4906-2RS | 104 | 30 | 35 | 47 | 18 | 17 | 23 900 | 28 500 | 5 500 |
| NA4907-2RS | 175 | 35 | 42 | 55 | 21 | 20 | 29 500 | 39 500 | 4 800 |
| NA4908-2RS | 252 | 40 | 48 | 62 | 23 | 22 | 41 000 | 53 000 | 4 200 |
| NA4909-2RS | 290 | 45 | 52 | 68 | 23 | 22 | 43 000 | 59 000 | 3 900 |
| NA4910-2RS | 295 | 20 | 58 | 72 | 23 | 22 | 45 000 | 64 000 | 3 500 |
| ID | Bearing Model | Mass | Size | Basic Load | Limited Speed | ||||
| Fw | D | C | Dynamic | Static | Oil | ||||
| Needle Roller Bearing with Inner Ring | |||||||||
| Cr | Cor | ||||||||
| mm | Current Moel | Old Model | g | mm | N | rpm | |||
| 21.87 | RNAV4002 | 4084102 | 45 | 21.87 | 32 | 17 | 10800 | 29800 | 4500 |
| 24.3 | RNAV4003 | 4084103 | 62 | 24.3 | 35 | 18 | 17900 | 37900 | 4300 |
| 28.7 | RNAV4004 | 4084104 | 114 | 28.7 | 42 | 22 | 28150 | 60900 | 3900 |
| 33.5 | RNAV4005 | 4084105 | 129 | 33.5 | 47 | 22 | 33800 | 70800 | 3700 |
| 40.1 | RNAV4006 | 4084106 | 193 | 40.1 | 55 | 25 | 49900 | 96500 | 3500 |
| 45.9 | RNAV4007 | 4084107 | 259 | 45.9 | 62 | 27 | 47600 | 122800 | 3100 |
| 51.6 | RNAV4008 | 4084108 | 304 | 51.6 | 68 | 28 | 49900 | 137900 | 2700 |
| 57.4 | RNAV4009 | 4084109 | 390 | 57.4 | 75 | 30 | 52500 | 153500 | 2600 |
| 62.1 | RNAV4010 | 4084110 | 426 | 62.1 | 80 | 30 | 55700 | 166000 | 2500 |
| 69.8 | RNAV4011 | 4084111 | 645 | 69.8 | 90 | 35 | 68500 | 225800 | 2300 |
| 74.6 | RNAV4012 | 4084112 | 677 | 74.6 | 95 | 35 | 75400 | 239000 | 2100 |
| 80.3 | RNAV4013 | 4084113 | 692 | 80.3 | 100 | 35 | 79500 | 256900 | 1900 |
| 88 | RNAV4014 | 4084114 | 950 | 88 | 110 | 40 | 98800 | 354900 | 1700 |
| 92.7 | RNAV4015 | 4084115 | 1000 | 92.7 | 115 | 45 | 101800 | 372900 | 1600 |
| 100.3 | RNAV4016 | 4084116 | 1400 | 100.3 | 125 | 45 | 102900 | 373500 | 1500 |
| 104.8 | RNAV4017 | 4084117 | 1540 | 104.8 | 130 | 45 | 103800 | 374800 | 1400 |
| 44 | RNAV4206X2 | 74706 | 44 | 62 | 30 | 8800 | 11800 | 4300 | |
| 44 | RNAV4206X2/YA | 74706K | 44 | 62 | 30 | 8800 | 11800 | 7300 | |
| ID | Bearing Model | Mass | Size | Basic Load | Limited Speed | ||||
| Fw | D | C | Dynamic | Static | Oil | ||||
| Needle Roller Bearing without Inner Ring | |||||||||
| Cr | Cor | ||||||||
| mm | Current Moel | Old Model | g | mm | N | rpm | |||
| 30 | NAV4006 | 4074106 | 299 | 30 | 55 | 25 | 49900 | 96500 | 3500 |
| 35 | NAV4007 | 4074107 | 402 | 35 | 62 | 27 | 47600 | 122800 | 3100 |
| 40 | NAV4008 | 4074108 | 482 | 40 | 68 | 28 | 49900 | 137900 | 2700 |
| 45 | NAV4009 | 4074109 | 617 | 45 | 75 | 30 | 52500 | 153500 | 2600 |
| 50 | NAV4010 | 4074110 | 669 | 50 | 80 | 30 | 55700 | 166000 | 2500 |
| 55 | NAV4011 | 4074111 | 1030 | 55 | 90 | 35 | 68500 | 225800 | 2300 |
| 60 | NAV4012 | 4074112 | 1087 | 60 | 95 | 35 | 75400 | 239000 | 2100 |
| 65 | NAV4013 | 4074113 | 1156 | 65 | 100 | 35 | 79500 | 256900 | 1900 |
| 70 | NAV4014 | 4074114 | 1666 | 70 | 110 | 40 | 98800 | 354900 | 1700 |
| 75 | NAV4015 | 4074115 | 1762 | 75 | 115 | 45 | 101800 | 372900 | 1600 |
| 80 | NAV4016 | 4074116 | 2450 | 80 | 125 | 45 | 102900 | 373500 | 1500 |
| 85 | NAV4017 | 4074117 | 2500 | 85 | 130 | 45 | 103800 | 374800 | 1400 |
| 17 | AV4203X2 | 74703 | 126 | 17 | 35 | 24.5 | 8700 | 10800 | 4200 |
| 30 | AV4206X2 | 74706 | 30 | 62 | 30 | 8800 | 11800 | 4300 | |
| 30 | NAV4206X2/YA | 74706K | 30 | 62 | 30 | 8800 | 11800 | 7300 | |
| 15 | 74802 | 100 | 15 | 36 | 24.5 | 8900 | 11200 | 4400 | |
NA4924 Bearings Drawing :
NA4924 Bearings Detailed Pictures :
About FSK Bearing Company:
Advantage :
1. Low friction
2. Wear resistant
3. Easy replacement
4. Minimum lubrication
5. Requires little attention
6. Running in not required
7. Dimensions relatively small
8. No scraping required to fit shaft
