| Place of Origin: | CHINA |
|---|---|
| Brand Name: | NSK / NTN / KOYO / NACHI / FSK |
| Certification: | ISO9001-2000 / CE / ROHS / UL |
| Model Number: | LM10 UU |
| Minimum Order Quantity: | 1 pcs |
| Price: | Talk in the letter |
| Packaging Details: | 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING |
| Delivery Time: | 5-7Days After Details Confirmed |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000pcs/month |
| Material: | Gcr15 Chrome Steel | Dimension: | 10mm × 19mm × 29mm |
|---|---|---|---|
| Part Name: | Ball Bushing / Shaft Guiding | HS Code: | 8482990000 |
| Number Of Row: | Four | Precision Rating: | P0, P3, P4, P5 ,P6 |
| High Light: | linear motion bearing,linear motion ball bearing |
||
Lm10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
Bearing Specification :
|
Model Number |
LM10 UU |
|
Part Name |
Linear Motion Bearing |
| Structure | Linear Ball Bearings |
|
Brand |
NSK / NTN / KOYO / KBE / FSK |
|
Material |
Gcr15 Chrome Steel |
|
Precision Rating |
P0 P6 P5 P4 P2 |
| Cage | Steel Cage / Nylon Cage / Light Alloy Cage |
| Dimension | 10mm × 19mm × 29mm |
| HS Code | 8482990000 |
| Original Country Show | CHINA |
|
Contact Person |
Ms. Ellie Liao |
| Skype | fskbearing1 |
| fsk_bearing@yahoo.com |
Description:
LM linear bearing: LM3UU,LM4UU,LM5UU,LM6UU,LM8UU,LM8S,LM10UU,LM12UU,LM13UU,LM16UU,LM20UU,LM25UU,LM30UU,LM35UU,LM40UU,LM50UU,LM60UU, LM80UU,LM100UU
Other Models We Can Offer
| Model No. | Main dimensions | Basic load rating | ||||
| Inscribed bore diameter | Outer diameter | Length | Dynamic rating | Static rating | Mass | |
| dr | D | L | C | C0 | ||
| mm | mm | mm | N | N | G | |
| LM 3 | 3 | 7 | 10 | 88.2 | 108 | 1.4 |
| LM 4 | 4 | 8 | 12 | 88.2 | 127 | 1.9 |
| LM 5 | 5 | 10 | 15 | 167 | 206 | 4 |
| LM 6 | 6 | 12 | 19 | 206 | 265 | 8 |
| LM 8S | 8 | 15 | 17 | 176 | 225 | 11 |
| LM 8 | 8 | 15 | 24 | 265 | 402 | 16 |
| LM 10 | 10 | 19 | 29 | 373 | 549 | 30 |
| LM 12 | 12 | 21 | 30 | 412 | 598 | 31.5 |
| LM 13 | 13 | 23 | 32 | 510 | 775 | 43 |
| LM 16 | 16 | 28 | 37 | 775 | 1180 | 69 |
| LM 20 | 20 | 32 | 42 | 863 | 1370 | 87 |
| LM 25 | 25 | 40 | 59 | 980 | 1570 | 220 |
| LM 30 | 30 | 45 | 64 | 1570 | 2750 | 250 |
| LM 35 | 35 | 52 | 70 | 1670 | 3140 | 390 |
| LM 40 | 40 | 60 | 80 | 2160 | 4020 | 585 |
| LM 50 | 50 | 80 | 100 | 3820 | 7940 | 1580 |
Bearings Detailed Pictures :
LM10 UU Linear Motion Bearings 10mm × 19mm × 29mm Ball Bushing, Get Cheap Price from China Steering Bearing Factory Now !
