| Place of Origin: | CHINA |
|---|---|
| Brand Name: | FSK / OEM / Any Brand You Want |
| Certification: | ISO9001-2000 / CE / ROHS / UL / SGS |
| Model Number: | SNT532 |
| Minimum Order Quantity: | 1 pcs |
| Price: | Talk in the letter |
| Packaging Details: | 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING |
| Delivery Time: | 5-7Days After Details Confirmed |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000pcs/month |
| Model No.: | SNT532 | Size: | 160mm × 175mm × 235mm × 550mm |
|---|---|---|---|
| Weight: | 55kg | Material: | Cast Steel / Iron Steel / Stainless Steel |
| Origin: | Wuxi Jiangsu | Other Name: | SNT532 Housing / SNT 532 Housing |
| Highlight: | abec-9 bearings,high speed ball bearings |
||
Heavy Load SNT532 SNT Series Cylindrical Bore Plummer
Block Housing Unit
SNT532 Housing Specification :
| Model Number | SNT532 |
| Application Bearing | 23232 |
| Seal | LO232 |
| Part Name | Bearing Housing |
| Dimensions(mm)(d*D*b) | 160mm × 175mm × 235mm × 550mm |
| Weight / Mass ( KG ) | 55kg |
| Precision Rating | ABEC-3 / ABEC-5 |
| Brand | FSK / OEM / Any Brand You Want |
| Original Country Show | CHINA ( FSK ) |
| HS Code | 8482800000 |
SNT532 Housing Detailed Pictures :
The SNZ Housings We Offer
| Bearing | Shaft | Abutment and fillet dimensions | Mass | Nominal | ||||||||||||||
| dia. | number | |||||||||||||||||
| mm | Self-aligning | |||||||||||||||||
| numbers | d | d2 | d 3 | D | H | J | N 1 | N | A | L | A1 | H 1 | H2 | g | t | kg | ball bearings | |
| SNZ206 | 30 | 25 | 35 | 62 | 50 | 150 | 15 | 20 | 77 | 185 | 52 | 22 | 90 | 30 | M 8 | 1.8 | 2206 | 22206 |
| SNZ207 | 35 | 30 | 45 | 72 | 50 | 150 | 15 | 20 | 82 | 185 | 52 | 22 | 95 | 33 | M10 | 2.2 | 2207 | 22207 |
| SNZ208 | 40 | 35 | 50 | 80 | 60 | 170 | 15 | 20 | 85 | 205 | 60 | 25 | 110 | 33 | M10 | 2.9 | 2208 | 22208 |
| SNZ209 | 45 | 40 | 55 | 85 | 60 | 170 | 15 | 20 | 85 | 205 | 60 | 25 | 112 | 31 | M10 | 3.2 | 2209 | 22209 |
| SNZ210 | 50 | 45 | 60 | 90 | 60 | 170 | 15 | 20 | 90 | 205 | 60 | 25 | 115 | 33 | M10 | 3.4 | 2210 | 22210 |
| SNZ211 | 55 | 50 | 65 | 100 | 70 | 210 | 18 | 23 | 95 | 255 | 70 | 28 | 130 | 33 | M12 | 4.5 | 2211 | 22211 |
| SNZ212 | 60 | 55 | 70 | 110 | 70 | 210 | 18 | 23 | 105 | 255 | 70 | 30 | 135 | 38 | M12 | 5.4 | 2212 | 22212 |
| SNZ213 | 65 | 60 | 75 | 120 | 80 | 230 | 18 | 23 | 110 | 275 | 80 | 30 | 150 | 43 | M12 | 6.2 | 2213 | 22213 |
| SNZ214 | 70 | 60 | 80 | 125 | 80 | 230 | 18 | 23 | 115 | 275 | 80 | 30 | 155 | 44 | M12 | 6.7 | 2213 | 22214 |
| SNZ215 | 75 | 65 | 85 | 130 | 80 | 230 | 18 | 23 | 115 | 280 | 80 | 30 | 155 | 41 | M12 | 7.6 | 2215 | 22215 |
| SNZ216 | 80 | 70 | 90 | 140 | 95 | 260 | 22 | 27 | 120 | 315 | 90 | 32 | 175 | 43 | M16 | 9.4 | 2216 | 22216 |
| SNZ217 | 85 | 75 | 95 | 150 | 95 | 260 | 22 | 27 | 125 | 320 | 90 | 32 | 185 | 46 | M16 | 10 | 2217 | 22217 |
| SNZ218 | 90 | 80 | 100 | 160 | 100 | 290 | 22 | 27 | 145 | 345 | 100 | 35 | 195 | 62.4 | M16 | 13 | 2218 | 22218 |
| SNZ219 | 95 | 85 | 110 | 170 | 112 | 290 | 22 | 27 | 140 | 345 | 100 | 35 | 210 | 53 | M16 | 16 | 2219 | 22219 |
| SNZ220 | 100 | 90 | 115 | 180 | 112 | 320 | 26 | 32 | 160 | 380 | 110 | 40 | 218 | 70.3 | M20 | 18 | 2220 | 22220 |
| SNZ222 | 110 | 100 | 125 | 200 | 125 | 350 | 26 | 32 | 175 | 410 | 120 | 45 | 240 | 80 | M20 | 23 | 2222 | 22222 |
| SNZ224 | 120 | 110 | 135 | 215 | 140 | 350 | 26 | 32 | 185 | 410 | 120 | 45 | 270 | 86 | M20 | 25 | − | 22224 |
| SNZ226 | 130 | 115 | 145 | 230 | 150 | 380 | 28 | 36 | 190 | 445 | 130 | 50 | 290 | 90 | M24 | 32 | − | 22226 |
| SNZ228 | 140 | 125 | 155 | 250 | 150 | 420 | 33 | 42 | 205 | 500 | 150 | 50 | 305 | 98 | M24 | 41 | − | 22228 |
| SNZ230 | 150 | 135 | 165 | 270 | 160 | 450 | 33 | 42 | 220 | 530 | 160 | 60 | 325 | 106 | M24 | 49 | − | 22230 |
| SNZ232 | 160 | 140 | 175 | 290 | 170 | 470 | 33 | 42 | 235 | 550 | 160 | 60 | 345 | 114 | M24 | 57 | − | 22232 |
FSK Bearing Company Advantages:
(1) We have first-class testing equipment to detect bearing various data parameters and control the quality of the bearing.
Whenever bearings must first detected whether the quality is qualified and the unqualified bearing will be eliminated directly.
So we can get the trust of a large number of customers, and supply them for several years.
(2) We have our own R & D capabilities, to help customers solve the problem of non-standard bearings.
We can also according to customer requirements change their own mark.
(3) Price, our manufacture ensure that our prices across China are quite competitive.
It is better for you to compare prices and quality among suppliers.
But everyone knows you can not buy the highest quality products with the lowest price,
but our product is the best quality if you use equal price.
