High Performance Cylindrical Roller Thrust Bearing Double Way , P4

High Performance Cylindrical Roller Thrust Bearing Double Way , P4

    • High Performance Cylindrical Roller Thrust Bearing Double Way , P4
    • High Performance Cylindrical Roller Thrust Bearing Double Way , P4
    • High Performance Cylindrical Roller Thrust Bearing Double Way , P4
    • High Performance Cylindrical Roller Thrust Bearing Double Way , P4
    • High Performance Cylindrical Roller Thrust Bearing Double Way , P4
  • High Performance Cylindrical Roller Thrust Bearing Double Way , P4

    Product Details:

    Place of Origin: GERMANY
    Brand Name: INA / FAG / TIMKE / NTN / NSK / KOYO / OEM
    Certification: ISO9001-2000 / CE / ROHS / UL
    Model Number: ZARF50115

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Price: Let's Chat in Detail
    Packaging Details: 1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement
    Delivery Time: 3 Days After Details Confirmed
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 10000pcs/day
    Contact Now
    Detailed Product Description
    Model No.: ZARF50115 Size: 50 × 115 × 60mm
    Weight: 2.1kg Cage: Brass Cage / Steel Cage
    Advantage: Low Vocie,high Speed, Long Life Character: Combined



    High Performance Cylindrical Roller Thrust Bearing Double Way , P4



    Bearing Specification :

    Model Number

    ZARF50115

    Part Name

    Cylindrical Roller Bearings

    Brand

    INA / FAG / TIMKE / NTN / NSK / KOYO / OEM

    Precision Rating

    ABEC-1 to ABEC-9

    Vibration and Noise Z0V0 / Z1V1 / Z2V2 / Z3V3
    Material Gcr15 Chrome Steel
    Number of Row Single Row
    Cage Brass Cage / Steel Cage

    Dimensions(mm)(d*D*b)

    50 × 115 × 60mm

    Weight / Mass ( KG )

    2.1kg

    HS Code

    8482800000

    Original Country Show CHINA



    High Performance Cylindrical Roller Thrust Bearing Double Way , P4High Performance Cylindrical Roller Thrust Bearing Double Way , P4High Performance Cylindrical Roller Thrust Bearing Double Way , P4High Performance Cylindrical Roller Thrust Bearing Double Way , P4High Performance Cylindrical Roller Thrust Bearing Double Way , P4



    d 50 mm
    D 115 mm
    H 60 mm
    B 11,5 mm
    C 22,5 mm
    C1 12,5 mm
    D1 78 mm
    Da max 79 mm
    d1 6 mm
    da min 67 mm
    H1 40 mm
    J 94 mm
    r1 min 0,6 mm
    rmin 0,3 mm
    m 2,1 kg
    Ca 90000 N
    C0a 300000 N
    Cr 40000 N
    C0r 82000 N
    nG Öl 3600 1/min
    nG Fett 1200 1/min
    MRL 2,2 Nm
    caL 4800 N/µm
    ckL 2470 Nm/mrad
    Mm 8,42 kg x cm^2
      1 µm
      12 x M8
      ZMA50/75, AM50
    MA 85 Nm
      18410 N



    Bearings Detailed Pictures :

    High Performance Cylindrical Roller Thrust Bearing Double Way , P4



    The ZARF Series Cylindrical Roller Bearing List

    Bearing Model d D H Bearing Model d D H2
    mm mm mm mm mm mm
    ZARF1560 ZARF1560-TV 15 60 40 ZARF1560-L-TV 15 60 53
    ZARF1762 ZARF1762-TV 17 62 43 ZARF1762-L-TV 17 62 57
    ZARF2068 ZARF2068-TV 20 68 46 ZARF2068-L-TV 20 68 60
    ZARF2080 ZARF2080-TV 20 80 60 ZARF2080-L-TV 20 80 75
    ZARF2575 ZARF2575-TV 25 75 50 ZARF2575-L-TV 25 75 65
    ZARF2590 ZARF2590-TV 25 90 60 ZARF2590-L-TV 25 90 75
    ZARF3080 ZARF3080-TV 30 80 50 ZARF3080-L-TV 30 80 65
    ZARF30105 ZARF30105-TV 30 105 66 ZARF30105-L-TV 30 105 82
    ZARF3590 ZARF3590-TV 35 90 54 ZARF3590-L-TV 35 90 70
    ZARF35110 ZARF35110-TV 35 110 66 ZARF35110-L-TV 35 110 82
    ZARF40100 ZARF40100-TV 40 100 54 ZARF40100-L-TV 40 100 70
    ZARF40115 ZARF40115-TV 40 115 75 ZARF40115-L-TV 40 115 93
    ZARF45105 ZARF45105-TV 45 105 60 ZARF45105-L-TV 45 105 75
    ZARF45130 ZARF45130-TV 45 130 82 ZARF45130-L-TV 45 130 103
    ZARF50115 ZARF50115-TV 50 115 60 ZARF50115-L-TV 50 115 78
    ZARF50140 ZARF50140-TV 50 140 82 ZARF50140-L-TV 50 140 103
    ZARF55145 ZARF55145-TV 55 145 82 ZARF55145-L-TV 55 145 103
    ZARF60150 ZARF60150-TV 60 150 82 ZARF60150-L-TV 60 150 103
    ZARF65155 ZARF65155-TV 65 155 82 ZARF65155-L-TV 65 155 103
    ZARF70160 ZARF70160-TV 70 160 82 ZARF70160-L-TV 70 160 103
    ZARF75185 ZARF75185-TV 75 185 100 ZARF75185-L-TV 75 185 125
    ZARF90210 ZARF90210-TV 90 210 110 ZARF90210-L-TV 90 210 135



    ZARF50115 Thrust Cylindrical Roller Bearing Double Way , P4​​​ ​, Get Cheap Price from China Roller Bearing Factory Now !
