Home ProductsNeedle Roller Bearings

12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty

12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty

    • 12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty
    • 12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty
    • 12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty
    • 12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty
    • 12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty
  • 12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty

    Product Details:

    Place of Origin: CHINA
    Brand Name: INA / IKO / FAG / NSK / NTN / FSK / OEM
    Certification: ISO9001-2000 / SGS / BV / CE
    Model Number: NKI 12/16

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs-10pcs
    Price: 0.1-20USD
    Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) PLASTIC TUBE PACKING / KRAFT PACKING
    Delivery Time: 3-7Days After Deposit
    Payment Terms: 30% Deposit , Balance After BL Copy
    Supply Ability: 100000pcs/month
    Contact Now
    Detailed Product Description
    Model No.: NKI 12/16 Size: 12mm × 24mm × 16mm
    Weight: 0.033kg Row: Single Row
    Inner Ring: With Inner Ring Feature: Small Size

    12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty



    Full Models of Standard Needle Roller bearing :

    Item No. Model No. Specification ranges
    1 BK BK0408~BK6032 4~60
    2 HK HK0408~HK6032 4~60
    3 BA BA55~BA1816 7.94~22.22
    4 SCE SCE108~SCE1616PP 15.88~25.4
    5 F F-0608~F-60*68*40 6~60
    6 HF HF0409~HF3530 4~35
    7 HF plus HF HFL RC RCB FC FCB
    8 K K5*8*8TN~K110*118*30 5~110
    9 KZK KZK8*12*8~KZK40*48*20 8~40
    10 KBK KBK8*11*10~KBK20*25*25 8~20
    11 NK NK5/10TN~NK60/25 5~60
    12 RNA RNA4900~RNA4928 14~160
    13 RNA RNA6900~RNA6919 14~110
    14 NKI NKI8~NKI100/30 8~100
    15 NA NA4900~NA4928 10~140
    16 NA NA6900~NA6919 10~95
    17 RNAV RNAV4002~RNAV4017 21.87~104.8
    18 NAV NAV4002~NAV4017 15~85
    19 AXK AXK0414TN~AXK160200 4~160
    20 NTA NTA-512~NTA-3244 7.92~50.80
    21 AXW AXW10~AXW50 10~50
    22 AS AS0414~AS160200 4~160
    23 WS WS81102~WS81132 15~160
    24 ZS ZS1127~ZS141199 15~160..



    Needle Roller Bearings List :

    Shaft Designation Mass Dimensions Basic Load Ratings Limiting
    Diameter   d F D B r Cr Cor Speed
                  Dynamic Static
    mm   g         min. kN kN rpm
    10 NKI 10/16 29 10 14 22 16 0.3 11 12.5 19000
      NKI 10/20 37 10 14 22 20 0.3 12.8 15.6 19000
    12 NKI 12/16 33 12 16 24 16 0.3 11.5 13.8 17000
      NKI 12/20 41 12 16 24 20 0.3 14.6 18.8 17000
    15 NKI 15/16 39 15 19 27 16 0.3 13.8 18.5 14000
      NKI 15/20 49 15 19 27 20 0.3 17.6 25.1 14000
    17 NKI 17/16 42 17 21 29 16 0.3 14.3 19.8 13000
      NKI 17/20 53 17 21 29 20 0.3 18.1 26.9 13000
    20 NKI 20/16 49 20 24 32 16 0.3 15.1 22.3 12000
      NKI 20/20 61 20 24 32 20 0.3 19.3 30.3 12000
    22 NKI 22/16 52 22 26 34 16 0.3 16.1 24.7 11000
      NKI 22/20 65 22 26 34 20 0.3 20.4 33.5 11000
    25 NKI 25/20 79 25 29 38 20 0.3 22.1 33.9 10000
      NKI 25/30 124 25 29 38 30 0.3 33.5 57.9 9500
    28 NKI 28/20 96 28 32 42 20 0.3 23.5 37.7 9000
      NKI 28/30 146 28 32 42 30 0.3 35.6 64.3 9000
    30 NKI 30/20 112 30 35 45 20 0.3 24.8 41.4 8500
      NKI 30/30 170 30 35 45 30 0.3 37.5 70.6 8000



    NA Series Needle Roller Bearings Drawing :

              12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty
    Bearing Specification :

    Model Number

    NKI 12/16

    Part Name

    Needle Roller Bearing

    Brand

    INA / IKO / FAG / NSK / NTN / FSK / OEM

    Precision Rating

    ABEC-3 / ABEC-5

    Material Chrome Steel / Stainless Steel
    Inner Ring with Inner Ring
    Row Single Row

    Dimensions(mm)(d*D*b)

    12mm × 24mm × 16mm

    Weight / Mass ( KG )

    0.033kg

    HS Code

    8482800000

    Original Country Show CHINA



    Bearings Detailed Pictures :

    12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty

    12mm Bore Micro Needle Roller Bearing NKI 12 / 16 Light Duty



    12mm Bore Micro Needle Roller Bearing NKI 12/16 Light Duty​​ ,  Get Cheap Price from China Bearing Factory Now !
