Product Details
Place of Origin: CHINA
Brand Name: INA / FAG / NTN / NSK / KOYO / FSK / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: AXK140180
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 7 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
AXK140180 |
Size: |
140 × 180 × 5mm |
Weight: |
0.219kg |
Cage: |
Brass Cage |
Part Name: |
China Thrust Needle Roller Bearings |
Character: |
Plane Thrust |
Model No.: |
AXK140180 |
Size: |
140 × 180 × 5mm |
Weight: |
0.219kg |
Cage: |
Brass Cage |
Part Name: |
China Thrust Needle Roller Bearings |
Character: |
Plane Thrust |
AXK140180 Plane Thrust Needle Roller Bearings for Construction Machinery
Thrust Needle Roller Bearings Description
Thrust Needle Roller Bearing
1.NTA AXK K8 series
2.high precision,best price
3.large stock
Thrust needle roller bearing NTA AXK K8 series
high precision,long life,low noise,Copmpetitive price,Large stock,Meet international standards
Needle roller and cage thrust assemblies are complements of small diameter needle rollers arranged in a spoke-like configuration. Needle rollers are equally spaced by means of a cage whose web section separates the rollers and provides guidance to keep them tracking in an orbital path. The purpose of these assemblies is to transmit thrust loads between two relatively rotating objects while greatly reducing friction.
Bearing Specification :
|
FSK BEARING Model Number |
AXK140180 |
|
Part Name |
Thrust Needle Roller Bearings |
|
Brand |
INA / FAG / NTN / NSK / KOYO / FSK / OEM |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Material | Gcr15 Chrome Steel |
| Number of Row | Single Row |
| Cage | Brass Cage |
|
Dimensions(mm)(d*D*b) |
140 × 180 × 5mm |
|
Weight / Mass ( KG ) |
0.219kg |
|
HS Code |
8482800000 |
| Original Country Show | CHINA |
Bearing Drawing :
Bearings Detailed Pictures :
Part of Thrust Needle Roller Bearings List:
| Part No. | ID/mm | OD/mm | W/mm | Weight/g | Load Rating(KN) | Limited speed | |
| Cr/KN | Cor/KN | (r/min) | |||||
| AXK0414 | 4 | 14 | 2 | 0.7 | 4.4 | 8 | 21000 |
| AXK0515 | 5 | 15 | 2 | 0.8 | 4.75 | 9.2 | 21000 |
| AXK0619 | 6 | 19 | 2 | 1 | 6.8 | 15.5 | 19000 |
| AXK0821 | 8 | 21 | 2 | 2 | 7.8 | 19.4 | 18000 |
| AXK1024 | 10 | 24 | 2 | 3 | 9.2 | 25.5 | 17000 |
| AXK1226 | 12 | 26 | 2 | 3 | 9.9 | 29 | 15000 |
| AXK1528 | 15 | 28 | 2 | 4 | 11.3 | 36 | 13000 |
| AXK1730 | 17 | 30 | 2 | 4 | 11.9 | 39.5 | 12000 |
| AXK2035 | 20 | 35 | 2 | 5 | 13.1 | 46.5 | 10000 |
| AXK2542 | 25 | 42 | 2 | 7 | 14.7 | 58 | 8500 |
| AXK3047 | 30 | 47 | 2 | 8 | 16.3 | 70 | 7500 |
| AXK3552 | 35 | 52 | 2 | 10 | 17.8 | 81 | 6500 |
| AXK4060 | 40 | 60 | 3 | 16 | 28 | 114 | 6000 |
| AXK4565 | 45 | 65 | 3 | 18 | 30 | 128 | 5000 |
| AXK5070 | 50 | 70 | 3 | 20 | 32 | 143 | 4800 |
| AXK5578 | 55 | 78 | 3 | 28 | 38 | 186 | 4300 |
| AXK6085 | 60 | 85 | 3 | 33 | 44.5 | 234 | 4000 |
| AXK6590 | 65 | 90 | 3 | 35 | 46.5 | 255 | 3700 |
| AXK7095 | 70 | 95 | 4 | 60 | 54 | 255 | 3500 |
| AXK75100 | 75 | 100 | 4 | 61 | 55 | 265 | 3300 |
| AXK80105 | 80 | 105 | 4 | 63 | 56 | 280 | 3100 |
| AXK85110 | 85 | 110 | 4 | 67 | 28 | 290 | 3000 |
| AXK90120 | 90 | 120 | 4 | 86 | 73 | 405 | 2700 |
| AXK100135 | 100 | 135 | 4 | 104 | 91 | 560 | 2500 |
| AXK110145 | 110 | 145 | 4 | 122 | 97 | 620 | 2300 |
| AXK120155 | 120 | 155 | 4 | 131 | 102 | 680 | 2100 |
| AXK130170 | 130 | 170 | 5 | 205 | 133 | 840 | 1900 |
| AXK140180 | 140 | 180 | 5 | 219 | 138 | 900 | 1800 |
| AXK150190 | 150 | 190 | 5 | 232 | 143 | 960 | 1700 |
| AXK160200 | 160 | 200 | 5 | 246 | 148 | 1020 | 1600 |
Advantage of Thrust Needle Roller Bearings:
