China Tapered Roller Bearings manufacturer
Wuxi FSK Transmission Bearing Co., Ltd

BEARING PROFESSIONAL SOLUTION !

Home ProductsNeedle Roller Bearings

NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar

NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar

    • NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar
    • NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar
    • NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar
    • NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar
  • NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar

    Product Details:

    Place of Origin: CHINA
    Brand Name: FSKG / KBE / OEM / Any Brand
    Certification: ISO9001-2000 / CE / ROHS / UL / SGS
    Model Number: NK16/16 ASI

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Price: Talk in the letter
    Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
    Delivery Time: 5-7Days After Details Confirmed
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 100000pcs/month
    Contact Now
    Detailed Product Description
    Model No.: NK16/16 ASI Size: 16 X 24 X 16mm
    Weight: 0.224kg Materila: GCR15
    Charater: NK 16/16 ASI Bearing / NK16/16 ASI Bearing Stock: 200pcs

    NK16/16 ASI Solid Collar Needle Roller Bearing Without Inner Ring , NK18/16 ASI



    NK16/16 ASI Bearing Specification :

    FSK BEARING Model Number NK16/16 ASI
    Part Name Needle Roller Bearing
    Row Single Row
    Dimensions(mm)(d*D*b) 16 X 24 X 16mm
    Weight / Mass ( KG ) 0.224kg
    Material GCR15
    Precision Rating ABEC-3 / ABEC-5
    Brand FSKG / KBE / OEM / Any Brand
    Original Country Show CHINA ( FSKG)



    Bearing Detailed Photos :

    NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar

    NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar



    FSK Bearing NK Series Bearings List

    Model No. Fw D C Model No. Fw D C
    mm mm mm mm mm mm
    NK5/10-TV-XL 5 10 10 NK35/20-TV-XL 35 45 20
    NK5/12-TV-XL 5 10 12 NK35/30-TV-XL 35 45 30
    NK6/10-TV-XL 6 12 10 NK37/20-XL 37 47 20
    NK6/12-TV-XL 6 12 12 NK37/30-XL 37 47 30
    NK7/10-TV-XL 7 14 10 NK38/20-XL 38 48 20
    NK7/12-TV-XL 7 14 12 NK38/30-XL 38 48 30
    NK8/12-TV-XL 8 15 12 NK40/20-TV-XL 40 50 20
    NK8/16-TV-XL 8 15 16 NK40/30-XL 40 50 30
    NK9/12-TV-XL 9 16 12 NK42/20-XL 42 52 20
    NK9/16-TV-XL 9 16 16 NK42/30-XL 42 52 30
    NK10/12-TV-XL 10 17 12 NK43/20-XL 43 53 20
    NK10/16-TV-XL 10 17 16 NK43/30-XL 43 53 30
    NK12/12-XL 12 19 12 NK45/20-TV-XL 45 55 20
    NK12/16-XL 12 19 16 NK45/30-TV-XL 45 55 30
    NK14/16-XL 14 22 16 NK47/20-XL 47 57 20
    NK14/20-XL 14 22 20 NK47/30-XL 47 57 30
    NK15/16-XL 15 23 16 NK50/25-TV-XL 50 62 25
    NK15/20-XL 15 23 20 NK50/35-TV-XL 50 62 35
    NK16/16-XL 16 24 16 NK55/25-XL 55 68 25
    NK16/20-XL 16 24 20 NK55/35-XL 55 68 35
    NK17/16-XL 17 25 16 NK60/25-TV-XL 60 72 25
    NK17/20-XL 17 25 20 NK60/35-XL 60 72 35
    NK18/16-XL 18 26 16 NK65/25-XL 65 78 25
    NK18/20-XL 18 26 20 NK65/35-XL 65 78 35
    NK19/16-XL 19 27 16 NK68/25-XL 68 82 25
    NK19/20-XL 19 27 20 NK68/35-XL 68 82 35
    NK20/16-XL 20 28 16 NK70/25-XL 70 85 25
    NK20/20-XL 20 28 20 NK70/35-XL 70 85 35
    NK21/16-XL 21 29 16 NK73/25-XL 73 90 25
    NK21/20-XL 21 29 20 NK73/35-XL 73 90 35
    NK22/16-XL 22 30 16 NK75/25-XL 75 92 25
    NK22/20-XL 22 30 20 NK75/35-XL 75 92 35
    NK24/16-XL 24 32 16 NK80/25-XL 80 95 25
    NK24/20-XL 24 32 20 NK80/35-XL 80 95 35
    NK25/16-XL 25 33 16 NK85/25-XL 85 105 25
    NK25/20-XL 25 33 20 NK85/35-XL 85 105 35
    NK26/16-XL 26 34 16 NK90/25-XL 90 110 25
    NK26/20-XL 26 34 20 NK90/35-XL 90 110 35
    NK28/20-XL 28 37 20 NK95/26-XL 95 115 26
    NK28/30-XL 28 37 30 NK95/36-XL 95 115 36
    NK29/20-TV-XL 29 38 20 NK100/26-XL 100 120 26
    NK29/30-XL 29 38 30 NK100/36-XL 100 120 36
    NK30/20-TV-XL 30 40 20 NK105/26-XL 105 125 26
    NK30/30-TV-XL 30 40 30 NK105/36-XL 105 125 36
    NK32/20-TV-XL 32 42 20 NK110/30-XL 110 130 30
    NK32/30-XL 32 42 30 NK110/40-XL 110 130 40





    The Other Bearings We Do

    Ball Bearing Deep Groove Ball Bearing 60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **,
    160 **(70001 )
    Thrust Ball Bearing 511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series
    Angular Contact Ball bearing SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series
    Roller Bearing Spherical Roller bearing 239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on
    Taper Roller Bearing 329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings suchas 938/932 single and double row i.e M255410CD etc.
    Thrust Roller Bearing 292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series.
    Cylindrical Roller Bearing NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used in Steel Industry.



    FSK Bearing Company Advantages:
    (1) We have first-class testing equipment to detect bearing various data parameters and control the quality of the bearing.
    Whenever bearings must first detected whether the quality is qualified and the unqualified bearing will be eliminated directly.
    So we can get the trust of a large number of customers, and supply them for several years.
    (2) We have our own R & D capabilities, to help customers solve the problem of non-standard bearings.
    We can also according to customer requirements change their own mark.
    (3) Price, our manufacture ensure that our prices across China are quite competitive.
    It is better for you to compare prices and quality among suppliers.
    But everyone knows you can not buy the highest quality products with the lowest price,
    but our product is the best quality if you use equal price.



    FSK Cooperation Details

    Delivery:
    For Small weight or ungent ,we send by express UPS,DHL,FEDEX, or EMS,china post with Thracking number
    For max production , we will ship by sea/air.
    Payment Item:
    TT, 30% deposit , 70% before shippment.
    L/C At Sight
    Paypal Or Western Union In advance
    Service:
    Trade Assurance
    Payment Protection
    Timely Delivery Guaranteed
    Product Qualtity Protection



    Our World Market:

    NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar

    Company information and Delivery:
    NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar


    Shipping and Delivery

    NK20 / 20 , NK30 / 20 , NK16/16 ASI Needle Roller Bearings Solid Collar



    NK16/16 ASI Solid Collar Needle Roller Bearing Without Inner Ring , NK18/16 ASI, Get Cheap Price from China Bearing Factory Now !
