32911 32912 32913 Metallurgical Taper Roller Bearing For Mining Machinery , Thin Wall

Product Details

Place of Origin: CHINA

Brand Name: FSKG / KBE / FAG / NTN / NSK / KOYO / OEM

Certification: ISO9001-2000 / CE / ROHS / UL

Model Number: 32911

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Let's Chat in Detail

Packaging Details: 1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement

Delivery Time: 3 Days After Details Confirmed

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 10000pcs/day

Get Best Price
Product Details
High Light:

sealed tapered roller bearing

,

taper roller bearing

Model No.:
32911
Size:
55 × 80 × 17 Mm
Weight:
0.285 Kg
Material:
Gcr15 / SAE52100 / AISI E52100
Feature:
Metallurgical Bearing
Original:
China Jiangsu
Model No.:
32911
Size:
55 × 80 × 17 Mm
Weight:
0.285 Kg
Material:
Gcr15 / SAE52100 / AISI E52100
Feature:
Metallurgical Bearing
Original:
China Jiangsu
Product Description





Thin-wall Type 32911 Tapered Roller Bearing Metallurgical Bearing for Mining Machinery



32911 Bearing Specification :

Model Number

32911

Part Name

Tapered Roller Bearing

Application Metallurgical Bearing

Brand

FSKG / KBE / FAG / NTN / NSK / KOYO / OEM

Precision Rating

ABEC-5 / ABEC-7

Number of Row Single Row

Dimensions(mm)(d*D*b)

55 × 80 × 17 mm

Weight / Mass ( KG )

0.285 kg

HS Code

8482800000

Original Country Show CHINA


32911 Bearings Detailed Pictures :

32911 32912 32913 Metallurgical Taper Roller Bearing For Mining Machinery , Thin Wall 0



Other Related Bearing We Offer:

32911 32912 32913 Metallurgical Taper Roller Bearing For Mining Machinery , Thin Wall 1

Related model
Model Size(mm) Model Size(mm) Model Size(mm)
32910 50*72*15 32916 80*110*20 32922 110*150*25
32911 55*80*17 32917 85*120*23 32924 120*165*29
32912 60*85*17 32918 90*125*23 32926 130*180*32
32913 65*90*17 32919 95*130*23 32928 140*190*32
32914 70*100*20 32920 100*140*25 32930 150*210*38
32915 75*105*20 32921 105*145*25 32932 160*220*38



Model Size(mm) ISO355 Dynamic Load Static Load Limited Speed (rpm) Mass
d D T B C Cr(N) Cor(N) Grease Oil kg
No.
H-E32908J 40 62 15 15 12 2BC 33500 48500 5900 7800 0.164
H-E32008J 40 68 19 19 14.5 3CD 53500 71400 5600 7400 0.282
H-E33008J 40 68 22 22 18 2BE 60400 84600 5500 7400 0.326
H-E33108J 40 75 26 26 20.5 2CE 82200 108000 5200 6900 0.508
H-E30208J 40 80 19.75 18 16 3DB 62900 69200 5000 6700 0.434
H-E32208J 40 80 24.75 23 19 3DC 77700 90800 5000 6600 0.554
H-E33208J 40 80 32 32 25 2DE 108000 139000 5000 6700 0.758
H-E30308J 40 90 25.25 23 20 2FB 90600 101000 4500 6100 0.757
H-E30308DJ 40 90 25.25 23 17 7FB 80500 90200 3800 5300 0.757
H-E32308J 40 90 35.25 33 27 2FD 116000 139000 4600 6200 1.06
H-E32909J 45 68 15 15 12 2BC 34700 52400 5300 7100 0.19
H-E32009J 45 75 20 20 15.5 3CC 62800 86500 5000 6600 0.354
H-E33009J 45 75 24 24 19 2CE 69600 101000 5000 6700 0.416
E33109J 45 80 26 26 20.5 3CE 87500 120000 4800 6400 0.563
H-E30209J 45 85 20.75 19 16 3DB 67200 77400 4600 6100 0.502
H-E32209J 45 85 24.75 23 19 3DC 78300 94100 4600 6100 0.587
E33209J 45 85 32 32 25 3DE 112000 149000 4600 6200 0.803
E30309J 45 100 27.25 25 22 2FB 113000 128000 4100 5400 1.01
E30309DJ 45 100 27.25 25 18 7FB 95100 107000 3400 4700 0.973
E32309J 45 100 38.25 36 30 2FD 146000 180000 4100 5500 1.43
E32910J 50 72 15 15 12 2BC 35900 56300 4900 6600 0.195
H-E32010J 50 80 20 20 15.5 3CC 65700 94500 4600 6100 0.389
E33010J 50 80 24 24 19 2CE 73000 110000 4600 6100 0.451
E33110J 50 85 26 26 20 3CE 89400 127000 4400 5900 0.594
H-E30210J 50 90 21.75 20 17 3DB 76500 91700 4300 5700 0.566
H-E32210J 50 90 24.75 23 19 3DC 85000 105000 4300 5700 0.643
E30310J 50 110 29.25 27 23 2FB 137000 152000 3700 4900 1.32
E30310DJ 50 110 29.25 27 19 7FB 115000 133000 3100 4300 1.25
E32310J 50 110 42.25 40 33 2FD 176000 220000 3700 5000 1.89
E32911J 55 80 17 17 14 2BC 44600 73300 4400 5900 0.285
H-E32011J 55 90 23 23 17.5 3CC 84600 121000 4100 5500 0.569
E33011J 55 90 27 27 21 2CE 96500 149000 4100 5400 0.672
E33111J 55 95 30 30 23 3CE 116000 161000 4000 5300 0.868
E30211J 55 100 22.75 21 18 3DB 94600 113000 3900 5200 0.732
E32211J 55 100 26.75 25 21 3DC 107000 133000 3900 5200 0.863
E33211J 55 100 35 35 27 3DE 142000 189000 3900 5200 1.18
E30311J 55 120 31.5 29 25 2FB 149000 170000 3300 4500 1.65
E30311DJ 55 120 31.5 29 21 7FB 129000 148000 2900 4000 1.59
E32311J 55 120 45.5 43 35 2FD 200000 250000 3400 4500 2.38



Our Interntional Market:

32911 32912 32913 Metallurgical Taper Roller Bearing For Mining Machinery , Thin Wall 2

Advantage :
1. Low friction
2. Wear resistant
3. Easy replacement
4. Minimum lubrication
5. Requires little attention
6. Running in not required
7. Dimensions relatively small
8. No scraping required tofit shaft

Our Service :
1. Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.
2. Delivery fast -----Goods be sent out within 3 to 7 days based on order quantity.
3. Professional-----We are special in source and sells, as development, methods, conjugations, and handling.
4. Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.



About Us:

1.Direct China factory/Manufactur with strong Capability
We are direct bearing factory on Jiangsu, China for more than 10 years.300 bearing types,15 million sets items ar produced yearly and the output value more than 15 million US dollars last year.
We could complete all ordere items excellently with over one hundred of advanced equipments running in 6 plants in China.


2.Large ready stock&Fast Delivery Time
Rich in stock throughout the year for general bearing types,sush as Deep groove ball bearing,Tapered Roller Bearing,Thrust Ball Bearing,etc.
Based on above advantages,we delivery goods timely&fastly as your requests.Warehouse items would deliveried within 1-2 days.
By courier/air or by cargo/sea


3.Competitive price
Large stock and strong Capability enables us to offer more reasonable price all over the world. Customers could receive good quality bearings with attrative price at the same time from us.


4.Non-standard Customized Service
We could customize many non-standard bearings and workpiece as your drawing requests and offer in-house test report by professional engineers.All customized goods are made to order as requests.


5.Perfect Quality Control System
We have perfect quality control systems and testing equipments and experienced engineers for more than 10 years.We test bearings one by one assuring all bearings with high proformance.


6.Best After-sale service
Experienced different after-sale workers are online for more than 12hours a day, 7 days a week offering you different bearing solutions for you.
We are glad to receive any comments from all the world by email,by call/message or by Skype/wechat/whatsapp/Viber/QQ..etc.


7. Multi-language communications



Below are some detailed Information for your reference
32911 32912 32913 Metallurgical Taper Roller Bearing For Mining Machinery , Thin Wall 3

Our Warehouse
32911 32912 32913 Metallurgical Taper Roller Bearing For Mining Machinery , Thin Wall 4



FAQ

32911 32912 32913 Metallurgical Taper Roller Bearing For Mining Machinery , Thin Wall 5
Q:Are you a trader or manufacturer?
A:We are factory specializing in all kind of bearings. We can give you the best price and better service.
Q:What is your delivery time?
A:Sample order: Immediate delivery , bulk order: usually 30 days.
Q:Can i request sample?
A:Of course , sample is ok and we can give you a sample by free.
Q:What's the shipping way?
A:According to YOUR demands.
Q:Can you accept OEM or ODM?
A:Yes, of course. logo is also acceptable.
Q:How is quality controlled?
A:Quality is the key !
Our QC team and engineer team works through all the process from an order placed to shipped.
Q: Can I come for a visit?
You are welcome to visit our factories , office and showroom ! Please contact our reception and we will help you to make a schedule.




Thin-wall Type 32911 Tapered Roller Bearing Metallurgical Bearing for Mining Machinery ​, Get Cheap Price from China Roller Bearing Factory Now !
