81111 / 81211 / 81112 Thrust Cylindrical Roller Bearing Single Row

81111 / 81211 / 81112 Thrust Cylindrical Roller Bearing Single Row

  • 81111 / 81211 / 81112 Thrust Cylindrical Roller Bearing Single Row
  • 81111 / 81211 / 81112 Thrust Cylindrical Roller Bearing Single Row
  • 81111 / 81211 / 81112 Thrust Cylindrical Roller Bearing Single Row
  • 81111 / 81211 / 81112 Thrust Cylindrical Roller Bearing Single Row
81111 / 81211 / 81112 Thrust Cylindrical Roller Bearing Single Row
Product Details:
Place of Origin: CHINA
Brand Name: FSK / FAG / NTN / NSK / KOYO / ZWZ / HRB / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 81111
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 7 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Contact Now
Detailed Product Description
Model No.: 81111 Size: 55 × 78 × 16mm
Weight: 0.218kg Cage: Brass Cage / Steel Cage / Nylon Cage
Part Name: China Cylindrical Roller Bearings Character: Plane Thrust
High Light:

full complement cylindrical roller bearing

,

cylindrical roller thrust bearing

81111 / 81211 / 81112 Thrust Cylindrical Roller Bearing Single Row



Thrust Cylindrical Roller Bearings Description
1. The main components of cylindrical roller thrust bearing; the cylindrical roller and cage thrust assembies, the shaft washers, and the housing washers.
2. The cylindrical roller thrust bearings are simple in form and design. The bearings are produced in single row and double row designs.
3. The cylindrical roller thrust bearings are suitable for arrangements that have to support heavy axial loads.
4. And they are relatively insensitive to shock loads, are very stiff and requre little axial space. As standard they are available as single direction
bearings and can only accommodate axial loads acting in one direction.



Bearing Specification :

Model Number

81111

Part Name

Thrust Cylindrical Roller Bearings

Brand

FSK / FAG / NTN / NSK / KOYO / ZWZ / HRB / OEM

Precision Rating

ABEC-1 to ABEC-9

Vibration and Noise Z0V0 / Z1V1 / Z2V2 / Z3V3
Material Gcr15 Chrome Steel
Number of Row Single Row
Cage Brass Cage / Steel Cage / Nylon Cage

Dimensions(mm)(d*D*b)

55 × 78 × 16mm

Weight / Mass ( KG )

0.218kg

HS Code

8482500000

Original Country Show CHINA



Bearing Drawing :

81111 Cylindrical Roller Thrust Bearing,Brass Cage / Steel cage / Nylon Cage ,Metric,55mm Bore,78mm OD,16mm Width



81111 / 81211 / 81112 Thrust Cylindrical Roller Bearing Single Row 0

Bearings Detailed Pictures :

81111 / 81211 / 81112 Thrust Cylindrical Roller Bearing Single Row 1



Part of Thrust Cylindrical Roller Bearings List:

Size (mm) Load Rating(KN) Limit Speed(r/min) Weight(kg) Bearing No.
d D H Ca Coa
15 28 9 14.4 28.5 11000 0.024 81102
17 30 9 15.9 33.5 10000 0.027 81103
20 35 10 24.9 53 8500 0.037 81104
25 42 11 33.5 76 7000 0.053 81105
30 47 11 35.5 86 6000 0.057 81106
52 16 64 141 6000 0.123 81206
60 18 69 197 5000 0.24 89306
35 52 12 39 101 5500 0.073 81107
62 18 80 199 4900 0.195 81207
68 20 80 237 4600 0.34 89307
40 60 13 56 148 4800 0.105 81108
68 19 107 265 4400 0.249 81208
78 22 122 385 4000 0.484 89308
90 23 135 480 3600 0.747 87409
45 65 14 59 163 4400 0.13 81109
73 20 105 265 4000 0.287 81209
85 24 139 445 3600 0.615 89309
100 25 154 560 3200 1.054 87409
50 70 14 61 177 4000 0.14 81110
78 22 117 315 3700 0.356 81210
95 27 167 560 3200 0.887 89310
110 27 200 740 2900 1.316 87410
110 36 295 900 3000 1.316 89410
110 31 295 900 3000 1.125 89410X
55 78 16 90 300 3600 0.218 81111
90 25 154 405 3300 0.568 81211
105 30 184 600 2900 1.18 89311
120 29 222 870 2600 1.698 87411
60 85 17 103 315 3300 0.266 81112
95 26 172 480 3100 0.642 87212
110 30 196 670 2700 1.26 89312
130 32 260 1000 2500 2.26 87412
130 42 390 1220 2500 2.818 89412
65 90 18 107 340 3100 0.31 81113
100 27 177 500 2900 0.721 81213
115 30 194 670 2600 1.33 89313
140 45 445 1410 2300 3.52 89413




Application of Thrust Cylindrical Roller Bearings:

1)Agriculture,
2)Light textile,
3)Mining,
4)Food &beverage,
5)Pharmaceutical,
6)Chemical processing,
7)Printing,
8)Dyeing,
9)Airport,
10)Air-conditioning,
11)Various kinds of conveying and rolling devices.



FSK Bearing Packings

1. Industrial packing: plastic bag + kraft paper + carton+ plywood pallets
2. Commerical packing:1pc/plastic bag + box + carton + plywood pallets
3. As the customer's requirment



81111 , 81211 , 81112 Thrust Cylindrical Roller Bearings Single Row , Get Cheap Price from China Roller Bearing Factory Now !
