Product Details
Place of Origin: AUSTRIA
Brand Name: FSK / NSK / FAG / NTN / KOYO / NACHI / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 7315 BECBM
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model No.: |
7315 BECBM |
Size: |
75 × 160 × 37mm |
Weight: |
3.15kg |
Cage: |
Brass Cage |
Lubrication: |
Oil Or Grease |
Character: |
Single Row , Brass Cage |
Model No.: |
7315 BECBM |
Size: |
75 × 160 × 37mm |
Weight: |
3.15kg |
Cage: |
Brass Cage |
Lubrication: |
Oil Or Grease |
Character: |
Single Row , Brass Cage |
Brass Cage 7315 BECBM Single Row Angular Contact Ball Bearing
Bearing Drawing :
Bearing Specification :
|
Model Number |
7315 BECBM |
|
Part Name |
Angular Contact Ball Bearing |
|
Brand |
FSK / NSK / FAG / NTN / KOYO / NACHI / OEM |
|
Precision Rating |
P4 / ABEC-7 |
| Material | Chrome Steel |
| Number of Row | Single Row |
| Cage | Brass Cage / Bronze Cage |
|
Dimensions(mm)(d*D*b) |
75 × 160 × 37mm |
|
Weight / Mass ( KG ) |
3.15kg |
|
HS Code |
8482103000 |
| Original Country Show | CHINA |
Bearings Detailed Pictures :
Angular Contact Ball Bearing List:
| Boundary Dimensions | Limiting Speed1) | Bearing | Mass | |||||
| (mm) | (rpm) | Designation2) | (kg) | |||||
| d | D | B | r | r1 | Grease | Oil | Approx | |
| (min.) | (min.) | |||||||
| 100 | 140 | 20 | 1.1 | 0.6 | 7000 | 9200 | 7920C | 0.773 |
| 140 | 20 | 1.1 | 0.6 | 7000 | 9200 | ACH920C | 0.869 | |
| 150 | 24 | 1.5 | 1 | 6700 | 8800 | ACH020C | 1.34 | |
| 150 | 24 | 1.5 | 1 | 4700 | 5900 | 7020 | 1.37 | |
| 150 | 24 | 1.5 | 1 | 3500 | 4700 | 7020B | 1.37 | |
| 150 | 24 | 1.5 | 1 | 6500 | 8600 | 7020C | 1.37 | |
| 180 | 34 | 2.1 | 1.1 | 4100 | 5200 | 7220 | 3.32 | |
| 180 | 34 | 2.1 | 1.1. | 3100 | 4200 | 7220B | 3.32 | |
| 180 | 34 | 2.1 | 1.1 | 5700 | 7600 | 7220C | 3.32 | |
| 215 | 47 | 3 | 1.1 | 3600 | 4600 | 7320 | 7.53 | |
| 215 | 47 | 3 | 1.1 | 2700 | 3600 | 7320B | 7.53 | |
| 215 | 47 | 3 | 1.1 | 5000 | 6700 | 7320C | 7.53 | |
| 105 | 145 | 20 | 1.1 | 0.6 | 6700 | 8800 | 7921C | 0.81 |
| 145 | 20 | 1.1 | 0.6 | 6700 | 8800 | ACH921C3 | 0.907 | |
| 160 | 26 | 2 | 1 | 6300 | 8300 | ACH021C | 1.7 | |
| 160 | 26 | 2 | 1 | 4400 | 5500 | 7021 | 1.73 | |
| 160 | 26 | 2 | 1 | 3300 | 4400 | 7021B | 1.73 | |
| 160 | 26 | 2 | 1 | 6000 | 8000 | 7021C | 1.73 | |
| 190 | 36 | 2.1 | 1.1 | 3900 | 4900 | 7221 | 3.95 | |
| 190 | 36 | 2.1 | 1.1 | 2900 | 3900 | 7221B | 3.95 | |
| 190 | 36 | 2.1 | 1.1 | 5400 | 7200 | 7221C | 3.95 | |
| 225 | 49 | 3 | 1.1 | 3500 | 4400 | 7321 | 8.62 | |
| 225 | 49 | 3 | 1.1 | 2600 | 3500 | 7321B | 8.62 | |
| 225 | 49 | 3 | 1.1 | 4800 | 6400 | 7321C | 8.62 | |
FSK Factory Workshop
Brass Cage 7315 BECBM Single Row Angular Contact Ball Bearing , Get Cheap Price from China Bearings Factory Now !
