JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings

Product Details

Place of Origin: CHINA

Brand Name: TIMKEN / NSK / NTN / FSKG / KBE / OEM

Certification: ISO9001-2000 / SGS / BV / CE / IAF

Model Number: 53316 U316

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs-5pcs

Price: 0.1-200USD

Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) PLASTIC TUBE PACKING / KRAFT PACKING

Delivery Time: 3-7Days After Deposit

Payment Terms: 30% Deposit , Balance After BL Copy

Supply Ability: 100000pcs/month

Get Best Price
Highlight:

Single Direction Thrust Ball Bearings

,

53316 U316 Thrust Ball Bearings

,

53318 U316 Thrust Ball Bearings

Model No.:
53316 U316
53316 U316 BearingSize:
80*145*52 Mm
53316 U316 Bearing Kg:
2.75kg
Quality:
ABEC-5
Material:
Gcr15 Chrome Steel
Same Bearing:
53316U316 Bearing
Model No.:
53316 U316
53316 U316 BearingSize:
80*145*52 Mm
53316 U316 Bearing Kg:
2.75kg
Quality:
ABEC-5
Material:
Gcr15 Chrome Steel
Same Bearing:
53316U316 Bearing
JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings

JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single direction thrust ball bearings



53316 U316 Bearing Specification :

FSK BEARING Model Number 53316 U316
Part Name Thrust Ball Bearings
Material Gcr15 Chrome steel
Cage Steel Cage
Row Single Row
Brand TIMKEN / NSK / NTN / FSKG / KBE / OEM
Precision Rating ABEC-3 / ABEC-5
Dimensions(mm)(d*D*b) 80*145*52 mm
Weight / Mass ( KG ) 2.75kg
HS Code 8482800000

Bearings Drawing :

JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings 0

Bearings Detailed Pictures

JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings 1JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings 2JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings 3JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings 4

JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings 5JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings 6JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings 7

Same Series Bearings We Do:

Bearing Number d D H m
53305+U305 25 mm 55 mm 22 mm 0.2 KG
53306+U306 30 mm 62 mm 25 mm 0.3 KG
53307+U307 35 mm 72 mm 28 mm 0.44 KG
53308+U308 40 mm 82 mm 31 mm 0.56 KG
53309+U309 45 mm 90 mm 33 mm 0.78 KG
53310+U310 50 mm 100 mm 37 mm 0.97 KG
53311+U311 55 mm 110 mm 42 mm 1.38 KG
53312+U312 60 mm 115 mm 42 mm 1.41 KG
53313+U313 65 mm 120 mm 43 mm 1.78 KG
53314+U314 70 mm 130 mm 48 mm 2.09 KG
53315+U315 75 mm 140 mm 52 mm 3.19 KG
53316+U316 80 mm 145 mm 52 mm 2.75 KG
53317+U317 85 mm 155 mm 58 mm 3.51 KG
53318+U318 90 mm 160 mm 59 mm 3.81 KG
53320+U320 100 mm 175 mm 64 mm 4.99 KG
53322-MP+U322 110 mm 195 mm 72 mm 7.85 KG
53324-MP+U324 120 mm 220 mm 80 mm 10.6 KG
53326XU 130 mm 235 mm 86 mm 15.8 KG
53328-MP+U328 140 mm 250 mm 92 mm 15.55 KG
53330-MP+U330 150 mm 260 mm 92 mm 12.8 KG
53332-MP+U332 160 mm 280 mm 100 mm 20.81 KG
53334-MP+U334 170 mm 290 mm 100 mm 21.58 KG
53336-MP+U336 180 mm 310 mm 109 mm 24.07 KG
53338-MP+U338 190 mm 330 mm 121 mm 36.48 KG
53340XU 200 mm 350 mm 130 mm 54.8 KG
JAPAN Quality 53316 U316 , 53317 U316 , 53318 U316 Single Direction Thrust Ball Bearings 8
Specification(mm) Bearing number Basic dynamic load Basic static load Limited speed(rpm) Mass
(kg)
d D T T3 T4 r Plate Type Self-aligning seat With self-aligning base ring Ca(N) Coa(N) Grease Oil Plate Type Self-aligning seat With self-aligning base ring
(min)
160 200 31 - - 1 51132 - - 112000 425000 1200 1800 2.27 - -
160 225 51 54.7 61 1.5 51232 53232 53232U 223000 720000 900 1300 6.64 6.5 8.29
160 270 87 91.7 100 3 51332 53332 53332U 410000 1340000 610 920 21 20.5 24.5
160 320 130 135.3 150 5 51432 53432 53432U 680000 2410000 440 670 51.2 49.7 58.9
170 215 34 - - 1.1 51134 - - 134000 510000 1100 1700 3.27 - -
170 240 55 58.7 65 1.5 51234 53234 53234U 261000 835000 840 1200 8.13 7.89 9.95
170 280 87 91.3 100 3 51334 53334 53334U 420000 1430000 600 900 22 21.3 25.7
170 340 135 141 156 5 51434 53434 53434U 755000 2730000 420 630 60.1 58.1 69.1
180 225 34 - - 1.1 51136 - - 135000 525000 1100 1600 3.37 - -
180 250 56 58.2 66 1.5 51236 53236 53236U 266000 875000 810 1200 8.69 8.26 10.5
180 300 95 99.3 109 3 51336 53336 53336U 485000 1700000 550 820 28.2 27 32
180 360 140 148.3 164 5 51436 53436 53436U 785000 2980000 400 600 69.5 68.8 81.5
190 240 37 - - 1.1 51138 - - 170000 655000 1000 1500 3.95 - -
190 270 62 65.7 73 2 51238 53238 53238U 310000 1060000 740 1100 11.7 11.5 14
190 320 105 111 121 4 51338 53338 53338U 570000 2100000 500 750 36.1 35.8 41.9
200 250 37 - - 1.1 51140 - - 172000 675000 1000 1500 4.14 - -
200 280 62 65.3 74 2 51240 53240 53240U 315000 1110000 720 1000 12.2 12 14.8
200 340 110 118.4 130 4 51340 53340 53340U 625000 2380000 470 710 43 43.1 51
220 270 37 - - 1.1 51144 - - 177000 740000 970 1400 4.51 - -
220 300 63 65.6 75 2 51244 53244 53244U 325000 1210000 690 1000 13.5 13 16.2
240 300 45 - - 1.5 51148 - - 228000 935000 830 1200 7.35 - -
240 340 78 81.6 92 2.1 51248 53248 53248U 430000 1730000 570 860 23.1 22.3 27.4
260 320 45 - - 1.5 51152 - - 232000 990000 800 1200 7.94 - -
260 360 79 82.8 93 2.1 51252 53252 53252U 445000 1880000 550 830 25 24 29.7
280 350 53 - - 1.5 51156 - - 315000 1350000 700 1000 12 - -
280 380 80 85 94 2.1 51256 53256 53256U 450000 1950000 530 800 27 26.2 32.3
300 380 62 - - 2 51160 - - 370000 1660000 610 920 17.1 - -
300 420 95 100.5 112 3 51260 53260 53260U 585000 2720000 450 680 42.3 41.7 49.9
320 400 63 - - 2 51164 - - 380000 1760000 590 880 18.5 - -
320 440 95 100.5 112 3 51264 53264 53264U 595000 2830000 440 660 44.7 43.8 52.7
340 420 64 - - 2 51168 - - 385000 1860000 570 850 19.9 - -
340 460 96 100.3 113 3 51268 53268 53268U 600000 2940000 430 640 47.6 46.4 56.2
360 440 65 - - 2 51172 - - 395000 1960000 550 820 20.4 - -
360 500 110 116.7 130 4 51272 53272 53272U 745000 3800000 380 570 69 67.7 81.5
