Product Details
Place of Origin: CHINA
Brand Name: FSKG / KBE / OEM / Any Brand
Certification: ISO9001-2000 / CE / ROHS / UL / SGS
Model Number: UCFCX07 23
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model No.: |
UCFCX07 23 |
UCFCX07 23 BearingSize: |
36.513 X 133 X 37mm |
07 23 Weight Kg: |
1.9kg |
Feature: |
Pillow Block Bearing |
Application: |
Radial Load |
Same Model: |
UCFCX07 23 Bearing / UCFCX07-23 Housing / UCFC X07-23 J Bearing / UCFCX07 Housing |
Model No.: |
UCFCX07 23 |
UCFCX07 23 BearingSize: |
36.513 X 133 X 37mm |
07 23 Weight Kg: |
1.9kg |
Feature: |
Pillow Block Bearing |
Application: |
Radial Load |
Same Model: |
UCFCX07 23 Bearing / UCFCX07-23 Housing / UCFC X07-23 J Bearing / UCFCX07 Housing |
4 Bolt UCFCX07 23 Pillow Block Bearings Flanged Housing Units Cast lron Material
Bearing Specification :
| FSK BEARING Model Number | UCFCX07 23 |
| Part Name | Pillow Block Bearings |
| Dimensions(mm)(d*D*b) | 36.513 X 133 X 37mm |
| Weight / Mass ( KG ) | 1.9kg |
| Material | Cast Iron / Cast Steel |
| Precision Rating | ABEC-3 / ABEC-5 |
| Brand | FSKG / KBE / OEM / Any Brand |
| Original Country Show |
CHINA ( FSKG) |
Bearing Drawing:
Bearing Detailed Photo:
The Other UCFCX Housings We Do
|
||||||||||||||||||||
| Shaft ID | Housing Number | Specification (mm) | Bolt | with Cast Steel Cover | with Cast Iron Cover | |||||||||||||||
| (mm) | ||||||||||||||||||||
| L | A | J | J1 | N | A1 | A2 | A3 | H3 | A0 | B | S | A4 | A5 | A6 | A7 | |||||
| 12 | UCFC201 | 100 | 20.5 | 78 | 55.1 | 12 | 7 | 10 | 5 | 62 | 28.3 | 31 | 12.7 | 38 | 41 | 8 | 6 | M10 | UCFC201C(E) | CUCFC201C(CE) |
| 15 | UCFC202 | 100 | 20.5 | 78 | 55.1 | 12 | 7 | 10 | 5 | 62 | 28.3 | 31 | 12.7 | 38 | 41 | 8 | 6 | M10 | UCFC202C(E) | CUCFC202C(CE) |
| 17 | UCFC203 | 100 | 20.5 | 78 | 55.1 | 12 | 7 | 10 | 5 | 62 | 28.3 | 31 | 12.7 | 38 | 41 | 8 | 6 | M10 | UCFC203C(E) | CUCFC203C(CE) |
| 20 | UCFC204 | 100 | 20.5 | 78 | 55.1 | 12 | 7 | 10 | 5 | 62 | 28.3 | 31 | 12.7 | 38 | 41 | 8 | 6 | M10 | UCFC204C(E) | CUCFC204C(CE) |
| 25 | UCFC205 | 115 | 21 | 90 | 63.6 | 12 | 7 | 10 | 6 | 70 | 29.7 | 34.1 | 14.3 | 42 | 45 | 11 | 9 | M10 | UCFC205C(E) | CUCFC205C(CE) |
| 25 | UCFCX05 | 111 | 24 | 92 | 65 | 9.5 | 9.5 | 10 | 6 | 76 | 32.2 | 38.1 | 15.9 | 43 | -- | 9 | -- | M8 | UCFCX05C(E) | -- |
| 30 | UCFC206 | 125 | 23 | 100 | 70.7 | 12 | 8 | 10 | 8 | 80 | 32.2 | 38.1 | 15.9 | 43 | 47 | 9 | 8 | M10 | UCFC206C(E) | CUCFC206C(CE) |
| 30 | UCFCX06 | 127 | 22.5 | 105 | 74.2 | 12 | 9.5 | 8 | 9.5 | 85 | 33.4 | 42.9 | 17.5 | 43 | -- | 8 | -- | M10 | UCFCX06C(E) | -- |
| 35 | UCFC207 | 135 | 26 | 110 | 77.8 | 14 | 9 | 11 | 8 | 90 | 36.4 | 42.9 | 17.5 | 46 | 51 | 8 | 8 | M12 | UCFC207C(E) | CUCFC207C(CE) |
| 35 | UCFCX07 | 133 | 26 | 111 | 78.5 | 12 | 11 | 9 | 11 | 92 | 39.2 | 49.2 | 19 | 48 | -- | 7 | -- | M10 | UCFCX07C(E) | -- |
| 40 | UCFC208 | 145 | 26 | 120 | 84.8 | 14 | 9 | 11 | 10 | 100 | 41.2 | 49.2 | 19 | 52 | 56 | 10 | 8 | M12 | UCFC208C(E) | CUCFC208C(CE) |
| 40 | UCFCX08 | 133 | 26 | 111 | 78.5 | 12 | 11 | 9 | 11 | 92 | 39.2 | 49.2 | 19 | 50 | -- | 10 | -- | M10 | UCFCX08C(E) | -- |
| 45 | UCFC209 | 160 | 26 | 132 | 93.3 | 16 | 14 | 10 | 12 | 105 | 40.2 | 49.2 | 19 | 51 | 55 | 10 | 8 | M14 | UCFC209C(E) | CUCFC209C(CE) |
| 45 | UCFCX09 | 155 | 25 | 130 | 91.9 | 14 | 11 | 8 | 12 | 108 | 40.6 | 51.6 | 19 | 52 | -- | 10 | -- | M12 | UCFCX09C(E) | -- |
| 50 | UCFC210 | 165 | 28 | 138 | 97.6 | 16 | 14 | 10 | 12 | 110 | 42.6 | 51.6 | 19 | 54 | 59 | 9 | 10 | M14 | UCFC210C(E) | CUCFC210C(CE) |
| 50 | UCFCX10 | 162 | 25 | 136 | 96.2 | 14 | 11 | 7 | 16 | 118 | 40.4 | 55.6 | 22.2 | 51 | -- | 9 | -- | M12 | UCFCX10C(E) | -- |
| 55 | UCFC211 | 185 | 31 | 150 | 106 | 19 | 15 | 13 | 12 | 125 | 46.4 | 55.6 | 22.2 | 57 | 63 | 9 | 10 | M16 | UCFC211C(E) | CUCFC211C(CE) |
| 55 | UCFCX11 | 180 | 26 | 152 | 108 | 16 | 13 | 4 | 22 | 127 | 43.7 | 65.1 | 25.4 | 54 | -- | 9 | -- | M14 | UCFCX11C(E) | -- |
| 60 | UCFC212 | 195 | 36 | 160 | 113 | 19 | 15 | 17 | 12 | 135 | 56.7 | 65.1 | 25.4 | 68 | 74 | 10 | 11 | M16 | UCFC212C(E) | CUCFC212C(CE) |
| 60 | UCFCX12 | 194 | 33 | 165 | 117 | 16 | 14 | 11 | 20 | 140 | 50.7 | 65.1 | 25.4 | 63 | -- | 11 | -- | M14 | UCFCX12C(E) | -- |
| 65 | UCFC213 | 205 | 36 | 170 | 120 | 19 | 15 | 16 | 14 | 145 | 55.7 | 65.1 | 25.4 | 67 | 75 | 10 | 13 | M16 | UCFC213C(E) | CUCFC213C(CE) |
| 65 | UCFCX13 | 194 | 33 | 165 | 117 | 16 | 14 | 11 | 20 | 140 | 55.4 | 74.6 | 30.2 | -- | -- | -- | -- | M14 | -- | -- |
| 70 | UCFC214 | 215 | 40 | 177 | 125 | 19 | 18 | 17 | 14 | 150 | 61.4 | 74.6 | 30.2 | -- | 84 | -- | 16 | M16 | -- | CUCFC214C(CE) |
| 70 | UCFCX14 | 222 | 36 | 190 | 134 | 19 | 14 | 14 | 20 | 164 | 58.5 | 77.8 | 33.3 | -- | -- | -- | -- | M16 | -- | -- |
| 75 | UCFC215 | 220 | 40 | 184 | 130 | 19 | 18 | 18 | 16 | 160 | 62.5 | 77.8 | 33.3 | -- | 86 | -- | 17 | M16 | -- | CUCFC215C(CE) |
| 75 | UCFCX15 | 222 | 35 | 190 | 134 | 19 | 16 | 12 | 22 | 164 | 61.3 | 82.6 | 33.3 | -- | -- | -- | -- | M16 | -- | -- |
| 80 | UCFC216 | 240 | 42 | 200 | 141 | 23 | 18 | 18 | 16 | 170 | 67.3 | 82.6 | 33.3 | -- | 91 | -- | 15 | M20 | -- | CUCFC216C(CE) |
| 80 | UCFCX16 | 260 | 36 | 219 | 155 | 23 | 19 | 10 | 25 | 186 | 61.6 | 85.7 | 34.1 | -- | -- | -- | -- | M20 | -- | -- |
| 85 | UCFC217 | 250 | 45 | 208 | 147 | 23 | 20 | 18 | 18 | 180 | 69.6 | 85.7 | 34.1 | -- | 93 | -- | 15 | M20 | -- | CUCFC217C(CE) |
| 85 | UCFCX17 | 260 | 36 | 219 | 155 | 23 | 19 | 10 | 25 | 186 | 66.3 | 96 | 39.7 | -- | -- | -- | -- | M20 | -- | -- |
| 90 | UCFC218 | 265 | 50 | 220 | 156 | 23 | 20 | 22 | 18 | 190 | 78.3 | 96 | 39.7 | -- | 104 | -- | 17 | M20 | -- | CUCFC218C(CE) |
| 90 | UCFCX18 | 260 | 43 | 219 | 155 | 23 | 19 | 12 | 28 | 186 | 73.1 | 104 | 42.9 | -- | -- | -- | -- | M20 | -- | -- |
| 100 | UCFCX20 | 276 | 66 | 238 | 168 | 23 | 22 | 22 | 28 | 206 | 90.3 | 118 | 49.2 | -- | -- | -- | -- | M20 | -- | -- |
The Other Bearings We Do
| Ball Bearing | Deep Groove Ball Bearing | 60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **, |
| 160 **(70001 ) | ||
| Thrust Ball Bearing | 511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series | |
| Angular Contact Ball bearing | SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series | |
| Roller Bearing | Spherical Roller bearing | 239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on |
| Taper Roller Bearing | 329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings suchas 938/932 single and double row i.e M255410CD etc. | |
| Thrust Roller Bearing | 292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series. | |
| Cylindrical Roller Bearing | NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used in Steel Industry. |
