Product Details
Place of Origin: CHINA
Brand Name: FSK / FAG / TIMKE / NTN / NSK / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: RMS-12-1/2 2RS
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model No.: |
RMS-12-1/2 2RS |
Material: |
GCr15 Chrome Steel |
Number Of Row: |
Single Row |
Seals Type: |
ZZ/rs |
Part Name: |
China Deep Groove Ball Bearings |
Clearance: |
C0,C1,C2,C3,C4,C5 |
Model No.: |
RMS-12-1/2 2RS |
Material: |
GCr15 Chrome Steel |
Number Of Row: |
Single Row |
Seals Type: |
ZZ/rs |
Part Name: |
China Deep Groove Ball Bearings |
Clearance: |
C0,C1,C2,C3,C4,C5 |
RMS-12-1/2 2RS Inched Deep Groove Ball Bearings RMS Series
Bearing Specification :
|
Model Number |
RMS-12-1/2 2RS |
|
Part Name |
Deep Groove Ball Bearings |
|
Brand |
FSK / FAG / TIMKE / NTN / NSK / KOYO / OEM |
|
Precision Rating |
ABEC-1 to ABEC-9 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Material | Gcr15 Chrome Steel |
| Number of Row | Single Row |
|
Dimensions(mm)(d*D*b) |
38.1mm × 95.25mm × 23.812mm |
|
Weight / Mass ( KG ) |
0.77kg |
|
HS Code |
8482102000 |
| Original Country Show | CHINA |
Bearings Detailed Pictures :
Deep Groove Ball Bearings List:
| Basic Bearing No. | Main Dimension | maximum speed | Weight | ||||
| d mm | D mm | B mm | Grease r/min | Oil r/min | approximate | ||
| KG | |||||||
| LJ1/2 | RLS4 | 1/2 | 1 5/16 | 3/8 | 21000 | 28500 | 0.037 |
| LJ5/8 | RLS5 | 5/8 | 1 13/16 | 7/16 | 18000 | 24000 | 0.059 |
| LJ3/4 | RLS6 | 3/4 | 1 7/8 | 9/16 | 15500 | 21000 | 0.109 |
| LJ7/8 | RLS7 | 7/8 | 2 | 9/16 | 14300 | 19500 | 0.116 |
| LJ1 | RLS8 | 1 | 2 1/4 | 5/8 | 12700 | 17000 | 0.169 |
| LJ1 1/8 | RLS9 | 1 1/8 | 2 1/2 | 5/8 | 11700 | 15500 | 0.219 |
| LJ1 1/4 | RLS10 | 1 1/4 | 2 3/4 | 11/16 | 10600 | 14400 | 0.276 |
| LJ1 3/8 | RLS11 | 1 3/8 | 3 | 11/16 | 9800 | 13200 | 0.333 |
| LJ1 1/2 | RLS12 | 1 1/2 | 3 1/4 | 3/4 | 9000 | 12200 | 0.418 |
| LJ1 5/8 | RLS13 | 1 5/8 | 3 1/2 | 3/4 | 8400 | 11300 | 0.481 |
| LJ1 3/4 | RLS14 | 1 3/4 | 3 3/4 | 13/16 | 10600 | 5500 | 0.594 |
| LJ1 7/8 | RLS15 | 1 7/8 | 4 | 13/16 | 7200 | 9800 | 0.708 |
| LJ2 | RLS16 | 2 | 4 | 13/16 | 7200 | 9800 | 0.667 |
| LJ2 1/4 | RLS18 | 2 1/4 | 4 1/2 | 7/8 | 6400 | 8600 | 0.885 |
| LJ2 1/2 | RLS20 | 2 1/2 | 5 | 15/16 | 5700 | 7700 | 1.22 |
| LJ2 3/4 | RLS22 | 2 3/4 | 5 1/4 | 15/16 | 5300 | 7200 | 1.33 |
| LJ3 | RLS24 | 3 | 5 3/4 | 11/16 | 4800 | 6500 | 1.81 |
| LJ3 1/4 | RLS26 | 3 1/4 | 6 | 11/16 | 4500 | 6100 | 1.87 |
| LJ3 3/8 | RLS27 | 3 3/8 | 7 1/2 | 1 9/16 | 3800 | 5100 | 4.9 |
| LJ3 1/2 | RLS28 | 3 1/2 | 6 1/2 | 1 1/8 | 4200 | 5600 | 2.33 |
| LJ3 3/4 | RLS30 | 3 3/4 | 6 3/4 | 1 1/8 | 3900 | 5300 | 2.47 |
| LJ4E | RLS32 | 4 | 7 1/4 | 1 1/4 | 3800 | 5100 | 3.18 |
| LJ4 1/4 | RLS34 | 4 1/4 | 7 1/2 | 1 1/4 | 3500 | 4700 | 3.86 |
| LJ4 1/2 | RLS36 | 4 1/2 | 8 | 15/16 | 3300 | 4400 | 4.67 |
| LJ4 3/4 | RLS38 | 4 3/4 | 8 1/4 | 15/16 | 3100 | 4200 | 4.9 |
| LJ5E | RLS40 | 5 | 9 | 1 3/8 | 2700 | 3700 | 6.35 |
| LJ5 1/2 | RLS44 | 5 1/2 | 9 1/2 | 1 3/8 | 2500 | 3400 | 6.85 |
| LJ6E | RLS48 | 6 | 10 1/2 | 1 9/16 | 2300 | 3100 | 9.48 |
| LJ6 1/2 | RLS52 | 6 1/2 | 11 | 1 9/16 | 2100 | 2900 | 10.2 |
| LJ7E | RLS56 | 7 | 12 | 1 3/4 | 1900 | 2600 | 14.1 |
| LJ7 1/2 | RLS60 | 7 1/2 | 12 1/2 | 1 3/4 | 1800 | 2400 | 14.5 |
| LJ8E | RLS64 | 8 | 13 | 1 3/4 | 1700 | 2300 | 15.6 |
| LJ8 1/2 | RLS68 | 8 1/2 | 14 | 2 | 1500 | 2100 | 21.1 |
| LJ9E | RLS72 | 9 | 14 1/2 | 2 | 1500 | 2000 | 22 |
| LJ9 1/2 | RLS76 | 9 1/2 | 15 1/8 | 2 | 1400 | 1800 | 22.7 |
| LJ10E | RLS80 | 10 | 15 3/4 | 2 | 1300 | 1700 | 25.5 |
| LJ10 1/2 | RLS84 | 10 1/2 | 16 5/8 | 2 1/4 | 1200 | 1600 | 32.5 |
| LJ11E | RLS88 | 11 | 17 1/2 | 2 1/2 | 1200 | 1600 | 36.1 |
| LJ11 1/2 | RLS92 | 11 1/2 | 18 | 2 3/8 | 1100 | 1400 | 38.5 |
| LJ12E | RLS96 | 12 | 18 1/2 | 2 5/8 | 1000 | 1400 | |
RMS-12-1/2 2RS Inched Deep Groove Ball Bearings RMS Series,
