Product Details
Place of Origin: CHINA
Brand Name: FSK / NSK / FAG / NTN / KOYO / NACHI / OEM
Certification: ISO9001-2000 / CE / ROHS
Model Number: 2206TAM
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement
Delivery Time: 3 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
2206TAM |
Structure: |
Cylindrical Roller Bearing |
Clearance: |
C0,C1,C2,C3,C4,C5 |
Hardness: |
59-66 HRC |
Seal: |
No Seal |
Material: |
GCR15 |
Model No.: |
2206TAM |
Structure: |
Cylindrical Roller Bearing |
Clearance: |
C0,C1,C2,C3,C4,C5 |
Hardness: |
59-66 HRC |
Seal: |
No Seal |
Material: |
GCR15 |
RHP Brand 2206TAM Cylindrical Roller Bearing OEM Service Accept
Bearing Specification :
| Product Name: Printing Machine Bearing |
| Model: 2206TAM |
| Diameter: contact us |
| Weight: contact us |
| Delivery date: within 5-7 days |
| Structure: Cylindrical Roller Bearing |
| Type: roller bearing |
| Retainer material: nylon; steel; brass; bronze |
| Lubrication:oil ,grease |
| Certification:ISO9001:2000 |
| Material: chrome steel; carbon steel; stainless steel |
| Precision rating: PO,P6,P5,P4,P2 |
| Seal type:Open ,ZZ,2RS,2RZ |
|
Product Advantage: High speed,Low vibration, Low noise,Long life,utilization conveniency, |
| MOQ: 1 piece |
| Packaging: |
| 1.Industrial packaging:(1)plastic bag+kraft paper+carton+plywood pallets |
| (2)plastic tube+carton+plywood pallets |
| 2.Commercial packaging:plastic bag per pic+color box+carton+plywood pallets |
| 3.As clients' requirement |
| Payment Terms: |
| A. L/C ,T/T ,Western Union |
| B.Other payment depend on our discussion |
| Sample can be provided for inspection! |
| Specail product according to customer's requirements! |
|
Application: Home appliances, low noise and high speed electric motors, |
Bearings Detailed Pictures :
Same Series Printing Machine Bearing List :
| Bearing No. | Boundary Dimension(mm) | Basic Load Ratings(KN) | Limited Speed(rpm) | Mass(mm) | |||||
| d | D | B | rmin | Cr | Cor | Grease | Oil | Approx | |
| 2200 | 10 | 30 | 14 | 0.6 | 0.042 | 6.57 | 1.53 | 18000 | 22000 |
| 2201 | 12 | 32 | 14 | 0.6 | 0.048 | 6.84 | 1.66 | 16000 | 19000 |
| 2202 | 15 | 35 | 14 | 0.6 | 0.055 | 6.93 | 1.78 | 14000 | 17000 |
| 2203 | 17 | 40 | 16 | 0.6 | 0.085 | 8.82 | 2.31 | 12000 | 15000 |
| 2204 | 20 | 47 | 18 | 1 | 0.133 | 11.34 | 3.17 | 11000 | 13000 |
| 2204 K | 20 | 47 | 18 | 1 | 0.133 | 11.34 | 3.17 | 11000 | 13000 |
| 2205 | 25 | 52 | 18 | 1 | 0.15 | 11.07 | 3.31 | 10000 | 11000 |
| 2205 K | 25 | 52 | 18 | 1 | 0.15 | 11.07 | 3.31 | 10000 | 11000 |
| 2206 | 30 | 62 | 20 | 1 | 0.249 | 13.68 | 4.32 | 8200 | 10000 |
| 2206 K | 30 | 62 | 20 | 1 | 0.249 | 13.68 | 4.32 | 8200 | 10000 |
| 2207 | 35 | 72 | 23 | 1.1 | 0.378 | 19.35 | 6.34 | 7100 | 8400 |
| 2207 K | 35 | 72 | 23 | 1.1 | 0.378 | 19.35 | 6.34 | 7100 | 8400 |
| 2208 | 40 | 80 | 23 | 1.1 | 0.477 | 20.07 | 7.06 | 6400 | 7500 |
| 2208 K | 40 | 80 | 23 | 1.1 | 0.477 | 20.07 | 7.06 | 6400 | 7500 |
| 2209 | 45 | 85 | 23 | 1.1 | 0.522 | 20.88 | 7.82 | 5700 | 6700 |
| 2209 K | 45 | 85 | 23 | 1.1 | 0.522 | 20.88 | 7.82 | 5700 | 6700 |
| 2210 | 50 | 90 | 23 | 1.1 | 0.564 | 20.88 | 8.11 | 5200 | 6100 |
| 2210 K | 50 | 90 | 23 | 1.1 | 0.564 | 20.88 | 8.11 | 5200 | 6100 |
| 2211 | 55 | 100 | 25 | 1.5 | 0.746 | 23.85 | 9.5 | 4800 | 5500 |
| 2211 K | 55 | 100 | 25 | 1.5 | 0.746 | 23.85 | 9.5 | 4800 | 5500 |
| 2212 | 60 | 110 | 28 | 1.5 | 1.03 | 30.6 | 12.1 | 4400 | 5100 |
| 2212 K | 60 | 110 | 28 | 1.5 | 1.03 | 30.6 | 12.1 | 4400 | 5100 |
| 2213 | 65 | 120 | 31 | 1.5 | 1.4 | 39.15 | 15.74 | 4000 | 4800 |
| 2213 K | 65 | 120 | 31 | 1.5 | 1.4 | 39.15 | 15.74 | 4000 | 4800 |
| 2214 | 70 | 125 | 31 | 1.5 | 1.52 | 39.6 | 16.42 | 3700 | 4400 |
| 2214 K | 70 | 125 | 31 | 1.5 | 1.52 | 39.6 | 16.42 | 3700 | 4400 |
| 2215 | 75 | 130 | 31 | 1.5 | 1.6 | 40.05 | 17.09 | 3500 | 4100 |
| 2215 K | 75 | 130 | 31 | 1.5 | 1.6 | 40.05 | 17.09 | 3500 | 4100 |
| 2216 | 80 | 140 | 33 | 2 | 1.97 | 43.65 | 19.1 | 3200 | 3800 |
| 2216 K | 80 | 140 | 33 | 2 | 1.97 | 43.65 | 19.1 | 3200 | 3800 |
| 2217 | 85 | 150 | 36 | 2 | 2.48 | 52.5 | 22.66 | 3000 | 3600 |
| 2217 K | 85 | 150 | 36 | 2 | 2.48 | 52.5 | 22.66 | 3000 | 3600 |
| 2218 | 90 | 160 | 40 | 2 | 3.13 | 63 | 27.55 | 2900 | 3400 |
| 2218 K | 90 | 160 | 40 | 2 | 3.13 | 63 | 27.55 | 2900 | 3400 |
| 2220 | 100 | 180 | 46 | 2.1 | 4.53 | 94.5 | 38.5 | 2700 | 3200 |
| 2220 K | 100 | 180 | 46 | 2.1 | 4.53 | 94.5 | 38.5 | 2700 | 3200 |
| 2221 | 105 | 190 | 50 | 2.1 | 6.07 | 109 | 45 | 2600 | 3100 |
| 2222 | 110 | 200 | 53 | 2.1 | 7.1 | 124 | 51.5 | 2500 | 2900 |
| 2222 K | 110 | 200 | 53 | 2.1 | 7.1 | 124 | 51.5 | 2500 | 2900 |
Our other Hot Sale Bearings
| Hot Sales in our company |
| 1. deep groove ball bearing 6000,6200,6300,6400,61800,61900,Z,RS,ZZ,2RS |
| 2. spherical roller bearing 22200,22300,23000,24000,23100,24100,CA,CC,E,W33 |
| 3. cylindrical roller bearingN,NU,NJ,NN,NUP,E,ECP,ECM,ECJ |
| 4. taper roller bearing 30200,30300,32200,32300,31300,32000 |
| 5. Aligning ball bearing 1200,1300,2200,2300, |
| 6. needle roller bearing NA,NAV,NK,NKI,RNA,NK,RNAV,ZKLF,ZKLN,ZARF,ZARN |
| 7. thrust ball bearing 51100,51200,51300,51400,E,M |
| 8. angular contact ball bearing7000,7100,7200,7300,AC,BECBM,C |
| 9. spherical plain bearing GE,GEG,GEEW,U,UC,UG,GX,GAC,SA,SABP |
Why choose us :
1.Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.
2.Delivery fast -----Goods be sent out within 3 to 7 days based on order quantity.
3.Professional-----We are special in source and sells, as development, methods, conjugations, and handling.
4.Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
About Us:
1.Direct China factory/Manufactur with strong Capability
We are direct bearing factory on Jiangsu, China for more than 10 years.300 bearing types,15 million sets items ar produced yearly and the output value more than 15 million US dollars last year.
We could complete all ordere items excellently with over one hundred of advanced equipments running in 6 plants in China.
2.Large ready stock&Fast Delivery Time
Rich in stock throughout the year for general bearing types,sush as Deep groove ball bearing,Tapered Roller Bearing,Thrust Ball Bearing,etc.
Based on above advantages,we delivery goods timely&fastly as your requests.Warehouse items would deliveried within 1-2 days.
By courier/air or by cargo/sea
3.Competitive price
Large stock and strong Capability enables us to offer more reasonable price all over the world. Customers could receive good quality bearings with attrative price at the same time from us.
4.Non-standard Customized Service
We could customize many non-standard bearings and workpiece as your drawing requests and offer in-house test report by professional engineers.All customized goods are made to order as requests.
5.Perfect Quality Control System
We have perfect quality control systems and testing equipments and experienced engineers for more than 10 years.We test bearings one by one assuring all bearings with high proformance.
6.Best After-sale service
Experienced different after-sale workers are online for more than 12hours a day, 7 days a week offering you different bearing solutions for you.
We are glad to receive any comments from all the world by email,by call/message or by Skype/wechat/whatsapp/Viber/QQ..etc.
7 Multi-language communications
RHP Brand 2206TAM Cylindrical Roller Bearing OEM Service Accept, Get Cheap Price from China Roller Bearing Factory Now !
Contact With Us Freely
