Product Details
Place of Origin: GERMANY
Brand Name: INA / IKO / FAG / FSK / OEM
Certification: ISO9001-2000 / CE / ROHS / UL / SGS
Model Number: SP5670
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Low Price
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 7Days After Order Confirmed
Payment Terms: 30% Deposit , Balance After BL Copy
Supply Ability: 100000pcs/month
Model No.: |
SP5670 |
Size: |
6mm ×19mm × 16mm |
Weight: |
0.1kg |
Cage: |
Complement / No Cage |
Character: |
Single Row |
Structure: |
Needle Roller Bearing |
Model No.: |
SP5670 |
Size: |
6mm ×19mm × 16mm |
Weight: |
0.1kg |
Cage: |
Complement / No Cage |
Character: |
Single Row |
Structure: |
Needle Roller Bearing |
Eccentric SP5670 INA Bearing Printing Machine Accessories
Bearing Specification :
| FSK BEARING Model Number | SP5670 |
| Part Name | Needle Roller Bearing |
| Application | Printing Machine Bearing |
| Row | Single Row |
| Cage | Complement / No Cage |
| Dimensions(mm)(d*D*b) | 6mm ×19mm ×16mm |
| Weight / Mass ( KG ) | 0.1kg |
| Precision Rating | ABEC-3 / ABEC-5 |
| Brand | FSKG / KBE / OEM / Any Brand |
| Original Country Show | CHINA ( FSKG ) |
Other Printing Machine Bearing
| F-10-2987 | F-16882 | F-52408 | F-88143 |
| EPS670 | NA4904 | F-94474 | F-28866 |
| SP5670-ZZ | NATA5904 | EN50/3.4 | F-207782.1 |
| SG102213 | F-24303 | F-54293 | F-53125.2 |
| 608/9/H | F-83030 | F-54635 | F-351644 |
| 608/9/H | F-95485 | F-42446 | F-87592 |
| NATA5902 | F-27991.3 | F-89966 | KR12*26*59 |
| NATA5903 | F-211549.1 | KR26B D2 | KR10*25*42.5 |
| F-23303 | CS203 | KR22B | KR12*30*60/3A |
| 10-2126=NAFW223026 | F-23212 | F-214617 | KR14*32*47 |
| NART12UU | F-23212 10U-1867 | F-211687 | KR16*35*46.5 |
| NART12UU | 10-3409 | F-208089.2 | KR18*40*46.5 |
| F-213584 | 10-3409 10U-168 | F-217813.2 | KR18*40*51.5 |
| F-29260 | F-205317 | F-97013 | KR18*40*54.5 |
| NURT15R | 47*15*20 | F-28686.1 | KR18*40*69.5 |
| F-21788(=F-17288) | HNTD205WX4/UP | F-86212=110-1538 | F-C44 |
| F-21788A | F-726643NA | F-10-1538 | F-223449 |
| F-21788A | F-34097 | F-53272 | F-223446 |
| F-21788A | F-208822 | F-211086.1 | KR18*43*74.5 |
| KLF25*36*45 | CF8 | F-88144 | KR20*47*69K |
| SBX0437C3 | KR16*35*51.5 | F-207782.1 | 5905 |
| F-222190 |
| Type | Bearing No. | Specification (MM) | ||||
| ID d | ID FW | OD D | C | C1 | ||
| Ⅱ | 10-2987 | 8 | 17 | 11 | ||
| Ⅷ | 670 | 6 | 19 | 12 | 16 | |
| Ⅲ | NATA5902 | 15 | 28 | 18 | ||
| Ⅲ | NATA5903 | 17 | 30 | 18 | ||
| Ⅳ | F-23303 | 17 | 30 | 18 | ||
| Ⅱ | 10-2126 | 22 | 30 | 26 | ||
| NART12UU | 12 | 32 | 14 | 15.2 | ||
| Ⅵ | F-21788 | 17 | 36 | 20.1 | 22.5 | |
| Ⅷ | RLF25*36*45 | 25 | 36 | 45 | ||
| Ⅶ | F-16882 | 25 | 36 | 55 | ||
| Ⅰ | F-29260 | 25 | 33 | 26 | ||
| Ⅲ | NATA5904 | 20 | 37 | 23 | ||
| Ⅳ | F-24303 135904 | 20 | 37 | 23 | ||
| Ⅲ | F-83030 | 20 | 37 | 23 | 25.9 | |
| Ⅴ | F-95485 | 17 | 38 | 24.5 | 43.2 | |
| Ⅴ | F-211549.1 | 17 | 38 | 24.5 | 55 | |
| Ⅵ | F-27991.3 | 17 | 38 | 24.6 | 55.1 | |
| Ⅵ | F-232124/10U-1082 | 20 | 40 | 19.7 | 23 | |
| Ⅵ | 10-3409 | 20 | 40 | 27.5 | 30 | |
| Ⅰ | 47*15*20 | 15 | 47 | 20 | ||
| Ⅰ | HNTD 205 WX4/UP | 25 | 52 | 15 | 27 | |
| Ⅰ | F-72 6643 NA | 65 | 90 | 45 | ||
| Ⅰ | F-34097 | 100 | 130 | 40 | ||
| Type | Bearing No. | Specification (MM) | ||||||
| Shaft ID d1 | Thread G | OD D | Outer ring thicknessC | Bmax | Length B1 | |||
| Ⅰ | KR14*32*47 | 14 | M14 | 32 | 16 | 17.2 | 47 | |
| Ⅳ | F-207782.1 | 14 | M8 | 32 | 22.5 | 24 | 86 | |
| Ⅰ | F-53125.2 | 16 | 35 | 18 | 18.8 | 39 | ||
| Ⅱ | KRX16*35*46.5 | 16 | 35 | 18 | 19.6 | 46.5 | ||
| Ⅱ | KRX16*35*51.5 | 16 | 35 | 18 | 19.6 | 51.5 | ||
| Ⅲ | F-21788(C) | 16 | M10 | 36 | 22.5 | 44.5 | 104 | |
| Ⅲ | F-21788(B) | 16 | M10 | 36 | 22.5 | 44.5 | 124 | |
| Ⅲ | F-21788(A) | 16 | M10 | 36 | 22.5 | 44.5 | 134 | |
| Ⅲ | F-23212 10U-1867 | 16 | M10 | 40 | 22.2 | 53.5 | 140 | |
| Ⅲ | 10-3409 10U-168 | 16 | M10 | 40 | 30 | 47.5 | 134 | |
SP56INA Bearing Pictures
Eccentric SP5670 INA Bearing Printing Machine Accessories , Get Cheap Price from China Ball Bearing Factory Now !
