Product Details
Place of Origin: CHINA
Brand Name: IKO / INA / FAG / NSK / NTN / FSK / OEM
Certification: ISO9001-2000 / SGS / BV / CE
Model Number: RNA 4908
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs-10pcs
Price: Competitive Low Price
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) PLASTIC TUBE PACKING / KRAFT PACKING
Delivery Time: 3-7Days After Deposit
Payment Terms: 30% Deposit , Balance After BL Copy
Supply Ability: 100000pcs/month
Model No.: |
RNA 4908 |
Size: |
48mm × 62mm × 22mm |
Weight: |
0.14kg |
Inner Ring: |
Without Inner Ring |
Vibration: |
V4, V3, V2, V1 |
Material: |
GCr15, GCr15SiMn, G20Cr2Ni4A |
Model No.: |
RNA 4908 |
Size: |
48mm × 62mm × 22mm |
Weight: |
0.14kg |
Inner Ring: |
Without Inner Ring |
Vibration: |
V4, V3, V2, V1 |
Material: |
GCr15, GCr15SiMn, G20Cr2Ni4A |
X - Life Rna 4908 Needle Roller Bearings No Inner Ring Single Row
Description of Needle Roller Bearings :
Needle bearings have a large surface area that is in contact with the bearing outer surfaces. Additionally there is less added clearance so they are much more compact. The typical structure consists of a needle cage which orients and contains the needle rollers, the needle rollers themselves, and an outer race and sometimes housing itself. Radial needle bearings are cylindrical and use rollers parallel to the axis of the shaft. Thrust needle bearings are flat and use a radial pattern of needles. Full compliment bearings have solid inner and outer rings and rib-guided cylindrical rollers.
Full Models of Standard Needle Roller bearing :
Light series needle roller bearings (NK,NKI,NKS,NKIS)
Heavy series needle roller bearings (NA,RNA,RNA-RS,RNA-2RS)
Curve needle rollers (KR,CF,CR,CNBH)
Strut needle rollers (NART,NUTR,CCYR,STO,RSTO,NAST-ZZ)
Not obstructs side needle roller bearings(NAO,RNAO)
Needle roller-thrust ball bearings (NX,NX-Z,NKX,NKX-Z)
Needle roller-thrust cylindrical bearings (NKXR,NKXR-Z)
Radial needle roller-thrust cylindrical needle roller bearings (ZARN)
Thrust-cylindrical needle roller bearings (811,812,WS,GS)
Needle rollers and cages (K,KR,KS,KBK,KZK)
Drawn cup needle roller clutches and assemblies (HF,HFL)
NA Series Needle Roller Bearings Drawing :
Needle Roller Bearings List :
| code | internal | outer | width |
| mm | mm | mm | |
| needle roller bearing RNA 4822 | 120 | 140 | 30 |
| needle roller bearing RNA 4824 | 130 | 150 | 30 |
| needle roller bearing RNA 4826 | 145 | 165 | 35 |
| needle roller bearing RNA 4828 | 155 | 175 | 35 |
| needle roller bearing RNA 4830 | 165 | 190 | 40 |
| needle roller bearing RNA 4832 | 175 | 200 | 40 |
| needle roller bearing RNA 4834 | 185 | 215 | 45 |
| needle roller bearing RNA 4836 | 195 | 225 | 45 |
| needle roller bearing RNA 4838 | 210 | 240 | 50 |
| needle roller bearing RNA 4840 | 220 | 250 | 50 |
| needle roller bearing RNA 4844 | 240 | 270 | 50 |
| needle roller bearing RNA 4848 | 265 | 300 | 60 |
| needle roller bearing RNA 4852 | 285 | 320 | 60 |
| needle roller bearing RNA 4856 | 305 | 350 | 69 |
| needle roller bearing RNA 4860 | 330 | 380 | 80 |
| needle roller bearing RNA 4864 | 350 | 400 | 80 |
| needle roller bearing RNA 4868 | 370 | 420 | 80 |
| needle roller bearing RNA 4872 | 390 | 440 | 80 |
| needle roller bearing RNA 4876 | 415 | 480 | 100 |
Bearing Specification :
|
Model Number |
RNA 4908 |
|
Part Name |
Needle Roller Bearing |
|
Brand |
IKO / INA / FAG / NSK / NTN / FSK / OEM |
|
Precision Rating |
ABEC-3 / ABEC-5 |
| Material | Chrome Steel / Stainless Steel |
| Inner Ring | without Inner Ring |
| Row | Single Row |
|
Dimensions(mm)(d*D*b) |
48mm × 62mm × 22mm |
|
Weight / Mass ( KG ) |
0.14kg |
|
HS Code |
8482800000 |
| Original Country Show | CHINA |
Bearings Detailed Pictures :
X-Life RNA 4908 Needle Roller Bearings No Inner Ring Single Row , Get Cheap Price from China Bearing Factory Now !
