Product Details
Place of Origin: CHINA
Brand Name: ASAHI / FYH / NSK / NTN / FSK / OEM
Certification: ISO9001-2000 / SGS / UL / CE / IAF
Model Number: UCT213
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs-5pcs
Price: 0.01-20USD
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) PLASTIC TUBE PACKING / KRAFT PACKING
Delivery Time: 3-7Days After Deposit
Payment Terms: 30% Deposit , Balance After BL Copy
Supply Ability: 100000pcs/month
Model No.: |
UCT213 |
Size: |
65mm × 167mm × 224mm |
Weight: |
7.3kg |
Hardness: |
58-62HRC |
Service: |
OEM Is Acceptable |
Use Feature: |
High Temperature/tough Environment |
Model No.: |
UCT213 |
Size: |
65mm × 167mm × 224mm |
Weight: |
7.3kg |
Hardness: |
58-62HRC |
Service: |
OEM Is Acceptable |
Use Feature: |
High Temperature/tough Environment |
Uct213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
Bearing Specification :
| Model Number | UCT213 |
| Part Name | Pillow Block Ball Bearing |
| Brand | ASAHI / FYH / NSK / NTN / FSK / OEM |
| Precision Rating | P6 / P4 / P5 |
| Material | Bearing: Chrome Steel , Housing: Casting / Forging |
| Cage | Steel Cage |
| Dimensions(mm)(d*D*b) | 65mm × 167mm × 224mm |
| Weight / Mass ( KG ) | 7.3kg |
| HS Code | 8482800000 |
| Original Country Show | CHINA |
FSK Pillow Block Bearings :
| Types: |
UC, UEL, UK, SA, SB, SER, UCP, UCF, UCFL, UCT, UCFC, UCPH, UCPA, UCHA, UCFB, UCFA, UCC, UCLP, UCLF, UCFD, UCPP, UCPF, UCPFL, UCPFT, UCBLF, UCTH, UCTL, UCTU ETC.. |
|
| Material: | Chrome Steel, Carbon Steel, Stainless Steel, Plastic, Ceramic | |
| Precision: | ABEC-1, ABEC-2, ABEC-3, ABEC-5, ABEC-7, ABEC-9, ABEC-11. | |
| Application: | Conveyors, Mining applications, Pulp and paper mills, Rolling mills ETC. | |
| Service: | 1. We can change the color according to your actual requirements. | |
| 2. Customized the marks based on your requirements. | ||
| 3. Choose the different package to your needs. | ||
UCT Pillow Block Bearings Drawing :
Pillow Bloack Bearings with Housing List :
| Bearing Unit | Shaft Dia | Dimensions(mm) | Weight | |||||||
| No. | d | (kg) | ||||||||
| mm | o | g | s | p | q | b | k | e | ||
| UCT202 | 15 | 16 | 10 | 51 | 32 | 19 | 51 | 12 | 76 | 0.78 |
| UCT203 | 17 | 16 | 10 | 51 | 32 | 19 | 51 | 12 | 76 | 0.77 |
| UCT 204 | 20 | 16 | 10 | 51 | 32 | 19 | 51 | 12 | 76 | 0.81 |
| UCT205 | 25 | 16 | 10 | 51 | 32 | 19 | 51 | 12 | 76 | 0.92 |
| UCT206 | 30 | 16 | 10 | 56 | 37 | 22 | 57 | 12 | 89 | 1.01 |
| UCT207 | 35 | 16 | 13 | 64 | 37 | 22 | 64 | 12 | 89 | 1.7 |
| UCT208 | 40 | 19 | 16 | 83 | 49 | 29 | 83 | 16 | 102 | 2.43 |
| UCT209 | 45 | 19 | 16 | 83 | 49 | 29 | 83 | 16 | 102 | 2.58 |
| UCT210 | 50 | 19 | 16 | 83 | 49 | 29 | 86 | 16 | 102 | 2.78 |
| UCT211 | 55 | 25 | 19 | 102 | 64 | 35 | 95 | 22 | 130 | 4.17 |
| UCT212 | 60 | 32 | 19 | 102 | 64 | 35 | 102 | 22 | 130 | 4.9 |
| UCT213 | 65 | 32 | 21 | 111 | 70 | 41 | 121 | 26 | 151 | 7.3 |
| UCT214 | 70 | 32 | 21 | 111 | 70 | 41 | 121 | 26 | 151 | 7.36 |
| UCT215 | 75 | 32 | 21 | 111 | 70 | 41 | 121 | 26 | 151 | 7.99 |
| UCT216 | 80 | 32 | 21 | 111 | 70 | 41 | 121 | 26 | 165 | 8.92 |
| UCT217 | 85 | 38 | 29 | 124 | 73 | 48 | 157 | 30 | 173 | 11.46 |
| UCT218 | 90 | 40 | 30 | 130 | 80 | 48 | 140 | 30 | 190 | 14.76 |
Bearings Detailed Pictures :
FSK Bearing Advantage and Service
Pre-sales:
1. OEM &ODM service
2. We promise to reply your inquiry in 24 hours.
3. Complete product information will be offered
4. Free sample will be sent if you need .
5. Any other reasonable requirements as per requested
During production ,we provide:
1. Schedule of production
2 .Mass production picture will offered
3. Any other reasonable requirements as per requested
Finish production:
1. Courier tracking number
2. Documents you need
3. Customer satisfy survey
4. Any other resasonable requirements as per requested
Uct213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing, Get Cheap Price from China Bearing Factory Now !
