Stainless Steel CF18 B Track Runner Bearings for Medical Equipment

Basic Information
Place of Origin: CHINA
Brand Name: IKO / INA / KOYO / NSK / FAG / NTN / FSK / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: CF18 B
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model No.: CF18 B Size: 18mm × 40mm × 20mm
Weight: 0.25Kg Part Name: China Tapered Roller Bearing
Seals Type: Sealed Row: Single Row
Highlight:

ntn needle roller bearing

,

double row cylindrical roller bearing



Stainless Steel CF18 B Cylindrical Roller Bearings for Medical Equipment



Bearing Specification :

FSK BEARING Model Number CF18 B
Part Name Truck Roller Bearing
Brand FSK / TR / ASAHI / FYH / NSK / NTN / OEM
Cage Steel, Brass, Nylon
Bearing Material Chrome Steel / Stainless Steel
Precision Grade ABEC-1 to ABEC-9 ; P0 to P6
Dimensions(mm)(d*D*b) 18mm × 40mm × 20mm
Weight / Mass ( KG ) 0.25kg
HS Code 8482800000
Original Country Show CHINA


Track Roller Bearing List:

Model No. Main dimensions With cage Full-roller type Mass
Outer diameter
D
Threaded
G
Outer ring width
C
B Overall length
B1
Dynamic rating
C
Static rating
C0
Dynamic rating
C
Static rating
C0
With cage Full-roller type
  mm mm mm mm mm kN kN kN kN g g
CF 3-A 10 M3x0.5 7 8 17 1.47 1.18 - - 4.5 -
CF 4-A 12 M4x0.7 8 9 20 2.06 2.05 - - 7.5 -
CF 5-A 13 M5x0.8 9 10 23 3.14 2.77 - - 10.5 -
CF 6-A 16 M6x1 11 12 28 3.59 3.58 6.94 8.5 18.5 19
CF 8-A 19 M8x1.25 11 12 32 4.17 4.65 8.13 11.2 28.5 29
CF 10-A 22 M10x1.25 12 13 36 5.33 6.78 9.42 14.3 45 46
CF 10-1-A 26 M10x1.25 12 13 36 5.33 6.78 9.42 14.3 60 61
CF 12-A 30 M12x1.5 14 15 40 7.87 9.79 13.4 19.8 95 97
CF 12-1-A 32 M12x1.5 14 15 40 7.87 9.79 13.4 19.8 105 107
CF 16-A 35 M16x1.5 18 19.5 52 12 18.3 20.6 37.6 170 173
CF 18-A 40 M18x1.5 20 21.5 58 14.7 25.2 25.2 51.3 250 255
CF 20-A 52 M20x1.5 24 25.5 66 20.7 34.8 33.2 64.8 460 465
CF 20-1-A 47 M20x1.5 24 25.5 66 20.7 34.8 33.2 64.8 385 390
CF 24-A 62 M24x1.5 29 30.5 80 30.6 53.2 46.7 92.9 815 820
CF 24-1-A 72 M24x1.5 29 30.5 80 30.6 53.2 46.7 92.9 1140 1140
CF 30-A 80 M30x1.5 35 37 100 45.4 87.6 67.9 145 1870 1870
CF 30-1-A 85 M30x1.5 35 37 100 45.4 87.6 67.9 145 2030 2030
CF 30-2-A 90 M30x1.5 35 37 100 45.4 87.6 67.9 145 2220 2220


Bearings Detailed Pictures :

Stainless Steel CF18 B Track Runner Bearings for Medical Equipment 0Stainless Steel CF18 B Track Runner Bearings for Medical Equipment 1



Features:

CF Camrol series steel stud-type cam follower bearing with lip seals and a hexagonal hole supports high static and dynamic loads in cam- and track-type applications. This precision cam follower has a thick-walled outer ring that helps minimize deformation under heavy radial and shock loads. It has a threaded stud-type design for through-hole or threaded mounting, and a hexagonal hole on the flange end that provides greater holding power during mounting than a screwdriver slot.



Our Servie:

1. OEM: Accept processing customization, we have professional engineers, can according to drawings for roduction .
2.  PACKING: In accordance with the relevant provisions of the packing, or according to your request
3.  SHIPING TIME: The delivery date according to the date of the contract .
4.  QUALITY: We provide the material test report .
5.  MODEL: All the models .
6.  SHELF LIFE: Standard fixed number of year .
7.  SAMPLE: We can provide samples, sample fee and freight shall be borne by the buyers .



Stainless Steel CF18 B Cylindrical Roller Bearings for Medical Equipment, Get Cheap Price from China Tapered Roller Bearing Factory Now !
