Product Details
Place of Origin: CHINA
Brand Name: FSKG / KBE / FAG / NTN / NSK / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 22220 EK/C3
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement
Delivery Time: 3 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
22220 EK/C3 |
Size: |
100 X 180 X 46mm |
Weight: |
4.8kg |
Material: |
Chrome Steel / Stainless Steel / Carbon Steel |
Advantage: |
Low Vocie,high Speed, Long Life |
Same Model: |
22220EK/C3 Bearing / 22220 EK C3 Bearing /22220 EK/C3 Bearing |
Model No.: |
22220 EK/C3 |
Size: |
100 X 180 X 46mm |
Weight: |
4.8kg |
Material: |
Chrome Steel / Stainless Steel / Carbon Steel |
Advantage: |
Low Vocie,high Speed, Long Life |
Same Model: |
22220EK/C3 Bearing / 22220 EK C3 Bearing /22220 EK/C3 Bearing |
Large Size 22220 EK/C3 Spherical Roller Bearing for Hydroelectric Generator
Bearing Specification :
|
FSK BEARING Model Number |
22220 EK/C3 |
|
Part Name |
Spherical Roller Bearing |
|
Brand |
FSKG / KBE / FAG / NTN / NSK / KOYO / OEM |
|
Precision Rating |
ABEC-3 to ABEC-5 |
| Material | Gcr15 Chrome Steel |
| Cage | Brass Cage / Steel Cage |
|
Dimensions(mm)(d*D*b) |
100 x 180 x 46mm |
|
Weight / Mass ( KG ) |
4.8kg |
|
HS Code |
8482800000 |
| Original Country Show | CHINA |
Bearings Drawing Pictures :
Bearings Detailed Pictures :
Same Series Bearing List
| Bearing Model | Specification(mm) | Dynamic Load | Static Load | Limied Speed(rpm) | Mass | |||||
| Round Hole | with Taper Hole | d | D | B | r | Cr(N) | Cor(N) | Grease | Oil | (kg) |
| (min) | ||||||||||
| 22218EX | 22218EXK | 90 | 160 | 40 | 2 | 294000 | 375000 | 1900 | 2600 | 3.5 |
| 22218AEX | 22218AEXK | 90 | 160 | 40 | 2 | 261000 | 310000 | 2700 | 3600 | 3.56 |
| 23218EX1 | 23218EX1K | 90 | 160 | 52 | 2 | 337000 | 482000 | 2100 | 2800 | 4.57 |
| 21318EX1 | 21318EX1K | 90 | 190 | 43 | 3 | 330000 | 410000 | 1900 | 2500 | 6.1 |
| 21318AX | 21318AXK | 90 | 190 | 43 | 3 | 330000 | 416000 | 2500 | 3000 | 6.45 |
| 22318EX | 22318EXK | 90 | 190 | 64 | 3 | 535000 | 660000 | 1800 | 2400 | 8.82 |
| 22318AEX | 22318AEXK | 90 | 190 | 64 | 3 | 495000 | 585000 | 2500 | 3200 | 8.91 |
| 22219EX | 22219EXK | 95 | 170 | 43 | 2.1 | 335000 | 420000 | 1900 | 2600 | 4.24 |
| 22219AEX | 22219AEXK | 95 | 170 | 43 | 2.1 | 295000 | 360000 | 2600 | 3400 | 4.35 |
| 23219E | 23219EK | 95 | 170 | 55 | 2.1 | 360000 | 510000 | 1900 | 2100 | 5.46 |
| 21319EX1 | 21319EX1K | 95 | 200 | 45 | 3 | 362000 | 461000 | 1800 | 2300 | 7.1 |
| 21319AX | 21319AXK | 95 | 200 | 45 | 3 | 355000 | 450000 | 2000 | 3000 | 7.44 |
| 22319EX | 22319EXK | 95 | 200 | 67 | 3 | 585000 | 725000 | 1700 | 2200 | 10.2 |
| 22319AEX | 22319AEXK | 95 | 200 | 67 | 3 | 545000 | 645000 | 2300 | 3000 | 10.3 |
| 23920E | 23920EK | 100 | 140 | 30 | 1.1 | 142000 | 233000 | 2300 | 3000 | 1.46 |
| 23020E | 23020EK | 100 | 150 | 37 | 1.5 | 206000 | 325000 | 1800 | 2400 | 2.33 |
| 23020AX | 23020AXK | 100 | 150 | 37 | 1.5 | 192000 | 298000 | 2800 | 3600 | 2.4 |
| 23120E | 23120EK | 100 | 165 | 52 | 2 | 325000 | 500000 | 1700 | 2200 | 4.49 |
| 23120AX | 23120AXK | 100 | 165 | 52 | 2 | 325000 | 538000 | 2200 | 3000 | 4.7 |
| 22220EX | 22220EXK | 100 | 180 | 46 | 2.1 | 375000 | 480000 | 1800 | 2400 | 5.1 |
| 22220AEX | 22220AEXK | 100 | 180 | 46 | 2.1 | 335000 | 410000 | 2500 | 3200 | 5.24 |
| 23220EX1 | 23220EX1K | 100 | 180 | 60 | 2.1 | 427000 | 629000 | 1900 | 2500 | 6.76 |
| 23220AX | 23220AXK | 100 | 180 | 60 | 2.1 | 415000 | 599000 | 2100 | 2800 | 6.88 |
| 21320EX1 | 21320EX1K | 100 | 215 | 47 | 3 | 416000 | 524000 | 1600 | 2200 | 8.7 |
| 21320AX | 21320AXK | 100 | 215 | 47 | 3 | 393000 | 488000 | 2200 | 2800 | 9.06 |
| 22320EX | 22320EXK | 100 | 215 | 73 | 3 | 700000 | 875000 | 1700 | 2200 | 13.1 |
| 22320AEX | 22320AEXK | 100 | 215 | 73 | 3 | 640000 | 775000 | 2200 | 2800 | 13.2 |
| 23022E | 23022EK | 110 | 170 | 45 | 2 | 298000 | 475000 | 1800 | 2400 | 3.84 |
| 23022AX | 23022AXK | 110 | 170 | 45 | 2 | 298000 | 478000 | 2500 | 3200 | 3.9 |
| 23122EX1 | 23122EX1K | 110 | 180 | 56 | 2 | 390000 | 610000 | 1800 | 2400 | 5.7 |
| 23122AX | 23122AXK | 110 | 180 | 56 | 2 | 387000 | 605000 | 2000 | 2700 | 5.8 |
| 24122EX1 | 24122EX1K30 | 110 | 180 | 69 | 2 | 455000 | 743000 | 1800 | 2400 | 6.89 |
| 24122AX | 24122AXK30 | 110 | 180 | 69 | 2 | 415000 | 654000 | 1800 | 2400 | 6.85 |
| 22222EX | 22222EXK | 110 | 200 | 53 | 2.1 | 490000 | 640000 | 1700 | 2200 | 7.36 |
| 22222AEX | 22222AEXK | 110 | 200 | 53 | 2.1 | 435000 | 550000 | 2200 | 2900 | 7.53 |
| 23222EX1 | 23222EX1K | 110 | 200 | 69 | 2.1 | 538000 | 793000 | 1700 | 2200 | 9.6 |
| 23222AX | 23222AXK | 110 | 200 | 69 | 2.1 | 534000 | 801000 | 1900 | 2500 | 10 |
| 21322EX1 | 21322EX1K | 110 | 240 | 50 | 3 | 485000 | 635000 | 1400 | 1900 | 11.6 |
| 21322AX | 21322AXK | 110 | 240 | 50 | 3 | 473000 | 601000 | 2000 | 2500 | 12.2 |
| 22322EX | 22322EXK | 110 | 240 | 80 | 3 | 825000 | 1040000 | 1500 | 1900 | 18.1 |
| 22322AEX | 22322AEXK | 110 | 240 | 80 | 3 | 770000 | 940000 | 2000 | 2500 | 18.2 |
Our other Hot Sale Bearings
| Hot Sales in our company |
| 1. deep groove ball bearing 6000,6200,6300,6400,61800,61900,Z,RS,ZZ,2RS |
| 2. spherical roller bearing 22200,22300,23000,24000,23100,24100,CA,CC,E,W33 |
| 3. cylindrical roller bearingN,NU,NJ,NN,NUP,E,ECP,ECM,ECJ |
| 4. taper roller bearing 30200,30300,32200,32300,31300,32000 |
| 5. Aligning ball bearing 1200,1300,2200,2300, |
| 6. needle roller bearing NA,NAV,NK,NKI,RNA,NK,RNAV,ZKLF,ZKLN,ZARF,ZARN |
| 7. thrust ball bearing 51100,51200,51300,51400,E,M |
| 8. angular contact ball bearing7000,7100,7200,7300,AC,BECBM,C |
| 9. spherical plain bearing GE,GEG,GEEW,U,UC,UG,GX,GAC,SA,SABP |
