Product Details
Place of Origin: CHINA
Brand Name: FSKG / KBE / FAG / NTN / NSK / KOYO / OEM
Certification: ISO9001-2000 / CE / ROHS / UL
Model Number: 61944MA/C3
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Let's Chat in Detail
Packaging Details: 1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement
Delivery Time: 3 Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/day
Model No.: |
61944MA/C3 |
Size: |
220 X 300 X 38mm |
Weight: |
8kg |
Cage: |
Brass Cage |
Advantage: |
Low Vocie,high Speed, Long Life |
Character: |
61944 MA/C3 Bearing / 61944 MA C3 Bearing / 61944MA/C3 Bearing |
Model No.: |
61944MA/C3 |
Size: |
220 X 300 X 38mm |
Weight: |
8kg |
Cage: |
Brass Cage |
Advantage: |
Low Vocie,high Speed, Long Life |
Character: |
61944 MA/C3 Bearing / 61944 MA C3 Bearing / 61944MA/C3 Bearing |
61944MA/C3 Bearing Specification :
|
Model Number |
61944MA/C3 |
|
Part Name |
Deep Groove Ball Bearing |
| Application | Textile Machine Bearing |
|
Brand |
FSKG / KBE / FAG / NTN / NSK / KOYO / OEM |
|
Precision Rating |
ABEC-5 / ABEC-7 |
| Material | Gcr15 Chrome Steel |
| Number of Row | Single Row |
|
Dimensions(mm)(d*D*b) |
220 X 300 X 38mm |
|
Weight / Mass ( KG ) |
8kg |
|
HS Code |
8482800000 |
| Original Country Show | CHINA |
61944MA/C3 Bearings Detailed Pictures :
The Other Bearing We Offer
| Designation | Principal dimensions | Basic load ratings | Fatigue load limit | Speed ratings | ||||
| d | D | B | dynamic | static | Pu | Reference speed | Limiting speed | |
| C | C0 | |||||||
| mm | KN | KN | r/min | |||||
| 61922 MA | 110 | 150 | 20 | 43.6 | 45 | 1.66 | 9000 | 7500 |
| 61924 MA | 120 | 165 | 22 | 55.3 | 57 | 2.04 | 8000 | 6700 |
| 6024 MA | 120 | 180 | 28 | 88.4 | 80 | 2.75 | 7500 | 6300 |
| 6228 MA | 140 | 250 | 42 | 165 | 150 | 4.55 | 5300 | 4800 |
| 61928 MA | 140 | 190 | 24 | 66.3 | 72 | 2.36 | 7000 | 5600 |
| 61830 MA | 150 | 190 | 20 | 48.8 | 61 | 1.96 | 6700 | 4300 |
| 61930 MA | 150 | 210 | 28 | 88.4 | 93 | 2.9 | 6300 | 5300 |
| 61932 MA | 160 | 220 | 28 | 92.3 | 98 | 3.05 | 6000 | 5000 |
| 61934 MA | 170 | 230 | 28 | 93.6 | 106 | 3.15 | 5600 | 4800 |
| 61936 MA | 180 | 250 | 33 | 119 | 134 | 3.9 | 5300 | 4300 |
| 61938 MA | 190 | 260 | 33 | 117 | 134 | 3.8 | 5000 | 4300 |
| 61940 MA | 200 | 280 | 38 | 148 | 166 | 4.55 | 4800 | 3800 |
| 61944 MA | 220 | 300 | 38 | 151 | 180 | 4.75 | 4300 | 3600 |
| 16048 MA | 240 | 360 | 37 | 203 | 255 | 6.3 | 3600 | 3000 |
| 61948 MA | 240 | 320 | 38 | 159 | 200 | 5.1 | 4000 | 3200 |
| 16052 MA | 260 | 400 | 44 | 238 | 310 | 7.2 | 3200 | 2800 |
| 61952 MA | 260 | 360 | 46 | 212 | 270 | 6.55 | 3600 | 3000 |
| 61856 MA | 280 | 350 | 33 | 138 | 200 | 4.75 | 3400 | 2800 |
| 61956 MA | 280 | 380 | 46 | 216 | 285 | 6.7 | 3200 | 2800 |
| 16056 MA | 280 | 420 | 44 | 242 | 335 | 7.5 | 3000 | 2600 |
| 16060 MA | 300 | 460 | 50 | 286 | 405 | 8.8 | 2800 | 1800 |
| 61860 MA | 300 | 380 | 38 | 172 | 245 | 5.6 | 3200 | 2600 |
| 61960 MA | 300 | 420 | 56 | 270 | 375 | 8.3 | 3000 | 2400 |
| 61864 MA | 320 | 400 | 38 | 172 | 255 | 5.7 | 3000 | 2400 |
| 60964 MA | 320 | 440 | 37 | 216 | 310 | 6.7 | 2800 | 2400 |
| 61964 MA | 320 | 440 | 56 | 276 | 400 | 8.65 | 2800 | 2400 |
| 16064 MA | 320 | 480 | 50 | 281 | 405 | 8.65 | 2600 | 2200 |
| 6264 MA | 320 | 580 | 92 | 527 | 800 | 16 | 2200 | 1900 |
| 6268 MA | 340 | 620 | 92 | 559 | 900 | 17.3 | 2000 | 1800 |
| 61968 MA | 340 | 460 | 56 | 281 | 425 | 9 | 2600 | 2200 |
| 16068 MA | 340 | 520 | 57 | 345 | 520 | 10.6 | 2400 | 2000 |
| 61868 MA | 340 | 420 | 38 | 178 | 275 | 6 | 2800 | 2400 |
| 61972 MA | 360 | 480 | 56 | 291 | 450 | 9.15 | 2600 | 2200 |
| 16072 MA | 360 | 540 | 57 | 351 | 550 | 11 | 1800 | 1400 |
| 60872 MA | 360 | 440 | 25 | 121 | 212 | 4.5 | 2600 | 2200 |
| 61872 MA | 360 | 440 | 38 | 182 | 285 | 6.1 | 2600 | 2200 |
| 61876 MA | 380 | 480 | 46 | 242 | 390 | 8 | 2400 | 2000 |
| 16076 MA | 380 | 560 | 57 | 377 | 620 | 12.2 | 2200 | 1400 |
| 61976 MA | 380 | 520 | 65 | 338 | 540 | 10.8 | 2400 | 1900 |
| 60880 MA | 400 | 500 | 31 | 163 | 280 | 5.6 | 2400 | 1900 |
| 61980 MA | 400 | 540 | 65 | 345 | 570 | 11.2 | 2200 | 1800 |
| 61880 MA | 400 | 500 | 46 | 247 | 405 | 8.15 | 2400 | 1900 |
| 61884 MA | 420 | 520 | 46 | 251 | 425 | 8.3 | 2200 | 1800 |
| 61984 MA | 420 | 560 | 65 | 351 | 600 | 11.4 | 2200 | 1800 |
| 61888 MA | 440 | 540 | 46 | 255 | 440 | 8.5 | 2200 | 1800 |
| 61988 MA | 440 | 600 | 74 | 410 | 720 | 13.2 | 2000 | 1600 |
Our Interntional Market:
Advantage :
1. Low friction
2. Wear resistant
3. Easy replacement
4. Minimum lubrication
5. Requires little attention
6. Running in not required
7. Dimensions relatively small
8. No scraping required tofit shaft
Our Service :
1. Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.
2. Delivery fast -----Goods be sent out within 3 to 7 days based on order quantity.
3. Professional-----We are special in source and sells, as development, methods, conjugations, and handling.
4. Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
Shipping and Delivery
Single Row 61944MA/C3 Deep Groove Ball Bearing Motor Bearing Electric Fishing Reel Bearing , Get Cheap Price from China Roller Bearing Factory Now !
