Model No.: |
4074116 |
Size: |
80mm X 125mm X 45mm |
Weight: |
2.47kg |
Cage: |
No Cage |
Advantage: |
Low Vocie,high Speed, Long Life |
Same Bearing: |
NAV4016 Bearing / NAV 4016 Bearing |
Model No.: |
4074116 |
Size: |
80mm X 125mm X 45mm |
Weight: |
2.47kg |
Cage: |
No Cage |
Advantage: |
Low Vocie,high Speed, Long Life |
Same Bearing: |
NAV4016 Bearing / NAV 4016 Bearing |
Full Complement 4074116 / NAV4016 Needle Roller Bearing With Entity Ferrule
4074116 Bearing Specification :
|
Model Number |
4074116 |
| Same Model | NAV4016 |
|
Part Name |
Needle Roller Bearing |
|
Brand |
FSKG / KBE / FAG / NTN / NSK / KOYO / OEM |
|
Precision Rating |
ABEC-5 / ABEC-7 |
| Material | Gcr15 Chrome Steel |
| Feature | Full Complement |
|
Dimensions(mm)(d*D*b) |
80mm X 125mm X 45mm |
|
Weight / Mass ( KG ) |
2.47kg |
|
HS Code |
8482800000 |
| Original Country Show | CHINA |
FSK Bearing Other RNAV , NAV Series Bearings
| ID | Bearing Model | Mass | Size | Basic Load | Limited Speed | ||||
| Fw | D | C | Dynamic | Static | Oil | ||||
| Needle Roller Bearing with Inner Ring | |||||||||
| Cr | Cor | ||||||||
| mm | Current Moel | Old Model | g | mm | N | rpm | |||
| 21.87 | RNAV4002 | 4084102 | 45 | 21.87 | 32 | 17 | 10800 | 29800 | 4500 |
| 24.3 | RNAV4003 | 4084103 | 62 | 24.3 | 35 | 18 | 17900 | 37900 | 4300 |
| 28.7 | RNAV4004 | 4084104 | 114 | 28.7 | 42 | 22 | 28150 | 60900 | 3900 |
| 33.5 | RNAV4005 | 4084105 | 129 | 33.5 | 47 | 22 | 33800 | 70800 | 3700 |
| 40.1 | RNAV4006 | 4084106 | 193 | 40.1 | 55 | 25 | 49900 | 96500 | 3500 |
| 45.9 | RNAV4007 | 4084107 | 259 | 45.9 | 62 | 27 | 47600 | 122800 | 3100 |
| 51.6 | RNAV4008 | 4084108 | 304 | 51.6 | 68 | 28 | 49900 | 137900 | 2700 |
| 57.4 | RNAV4009 | 4084109 | 390 | 57.4 | 75 | 30 | 52500 | 153500 | 2600 |
| 62.1 | RNAV4010 | 4084110 | 426 | 62.1 | 80 | 30 | 55700 | 166000 | 2500 |
| 69.8 | RNAV4011 | 4084111 | 645 | 69.8 | 90 | 35 | 68500 | 225800 | 2300 |
| 74.6 | RNAV4012 | 4084112 | 677 | 74.6 | 95 | 35 | 75400 | 239000 | 2100 |
| 80.3 | RNAV4013 | 4084113 | 692 | 80.3 | 100 | 35 | 79500 | 256900 | 1900 |
| 88 | RNAV4014 | 4084114 | 950 | 88 | 110 | 40 | 98800 | 354900 | 1700 |
| 92.7 | RNAV4015 | 4084115 | 1000 | 92.7 | 115 | 45 | 101800 | 372900 | 1600 |
| 100.3 | RNAV4016 | 4084116 | 1400 | 100.3 | 125 | 45 | 102900 | 373500 | 1500 |
| 104.8 | RNAV4017 | 4084117 | 1540 | 104.8 | 130 | 45 | 103800 | 374800 | 1400 |
| 44 | RNAV4206X2 | 74706 | 44 | 62 | 30 | 8800 | 11800 | 4300 | |
| 44 | RNAV4206X2/YA | 74706K | 44 | 62 | 30 | 8800 | 11800 | 7300 | |
| ID | Bearing Model | Mass | Size | Basic Load | Limited Speed | ||||
| Fw | D | C | Dynamic | Static | Oil | ||||
| Needle Roller Bearing without Inner Ring | |||||||||
| Cr | Cor | ||||||||
| mm | Current Moel | Old Model | g | mm | N | rpm | |||
| 30 | NAV4006 | 4074106 | 299 | 30 | 55 | 25 | 49900 | 96500 | 3500 |
| 35 | NAV4007 | 4074107 | 402 | 35 | 62 | 27 | 47600 | 122800 | 3100 |
| 40 | NAV4008 | 4074108 | 482 | 40 | 68 | 28 | 49900 | 137900 | 2700 |
| 45 | NAV4009 | 4074109 | 617 | 45 | 75 | 30 | 52500 | 153500 | 2600 |
| 50 | NAV4010 | 4074110 | 669 | 50 | 80 | 30 | 55700 | 166000 | 2500 |
| 55 | NAV4011 | 4074111 | 1030 | 55 | 90 | 35 | 68500 | 225800 | 2300 |
| 60 | NAV4012 | 4074112 | 1087 | 60 | 95 | 35 | 75400 | 239000 | 2100 |
| 65 | NAV4013 | 4074113 | 1156 | 65 | 100 | 35 | 79500 | 256900 | 1900 |
| 70 | NAV4014 | 4074114 | 1666 | 70 | 110 | 40 | 98800 | 354900 | 1700 |
| 75 | NAV4015 | 4074115 | 1762 | 75 | 115 | 45 | 101800 | 372900 | 1600 |
| 80 | NAV4016 | 4074116 | 2450 | 80 | 125 | 45 | 102900 | 373500 | 1500 |
| 85 | NAV4017 | 4074117 | 2500 | 85 | 130 | 45 | 103800 | 374800 | 1400 |
| 17 | AV4203X2 | 74703 | 126 | 17 | 35 | 24.5 | 8700 | 10800 | 4200 |
| 30 | AV4206X2 | 74706 | 30 | 62 | 30 | 8800 | 11800 | 4300 | |
| 30 | NAV4206X2/YA | 74706K | 30 | 62 | 30 | 8800 | 11800 | 7300 | |
| 15 | 74802 | 100 | 15 | 36 | 24.5 | 8900 | 11200 | 4400 | |
4074116 Bearings Detailed Pictures :
About FSK Bearing Company:
Advantage :
1. Low friction
2. Wear resistant
3. Easy replacement
4. Minimum lubrication
5. Requires little attention
6. Running in not required
7. Dimensions relatively small
8. No scraping required to fit shaft
