Product Details
Place of Origin: CHINA
Brand Name: FSKG / KBE / OEM / Any Brand
Certification: ISO9001-2000 / CE / ROHS / UL / SGS
Model Number: 80752305
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Talk in the letter
Packaging Details: 1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Delivery Time: 5-7Days After Details Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000pcs/month
Model No.: |
80752305 |
Size: |
25mm×68.2mm×42mm |
Weight: |
0.765kg |
Quality: |
ABEC-5 / ABEC-7 |
Origin: |
Wuxi Jiangsu |
Row: |
Double Row |
Model No.: |
80752305 |
Size: |
25mm×68.2mm×42mm |
Weight: |
0.765kg |
Quality: |
ABEC-5 / ABEC-7 |
Origin: |
Wuxi Jiangsu |
Row: |
Double Row |
Double Row 80752305 Overall Eccentric Bearing for Reducer Radial Load
80752305 Bearing Specification :
| FSK BEARING Model Number | 80752305 |
| Name | Eccentric Bearing |
| Structure | Cylindrical Roller Bearing |
| Row | Double Row |
| Dimensions(mm)(d*D*b) | 25mm×68.2mm×42mm |
| Weight / Mass ( KG ) | 0.765kg |
| Precision Rating | ABEC-3 / ABEC-5 |
| Brand | FSKG / KBE / OEM / Any Brand |
| Original Country Show | CHINA (FSKG) |
80752305 Bearing Photos :
FSK Bearing Other Eccentric Bearing:
| Bearing No. | Size(mm) | Basic Load | Limited Speed(rpm) | keyway | Mass | |||||||
| d | D | L | r | e | Static N | Dynamic N | Grease | Oil | b | t1 | kg | |
| 80752905Y1 | 24 | 61.8 | 34 | 1.1 | 0.75 | 71000 | 83000 | 7500 | 9500 | 8 | 3.3 | 0.5 |
| 100752905Y1 | 61.8 | 34 | 1.1 | 1 | 71000 | 83000 | 7500 | 9500 | 8 | 3.3 | 0.5 | |
| 130752905Y1 | 61.8 | 34 | 1.1 | 1.25 | 71000 | 83000 | 7500 | 9500 | 8 | 3.3 | 0.5 | |
| 150752905Y1 | 61.8 | 34 | 1.1 | 1.5 | 71000 | 83000 | 7500 | 9500 | 8 | 3.3 | 0.5 | |
| 200752905Y1 | 61.8 | 34 | 1.1 | 2 | 82300 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.5 | |
| 300752905Y1 | 61.8 | 34 | 1.1 | 3 | 82300 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.5 | |
| 80752905K | 24 | 70 | 36 | 1.1 | 0.75 | 82300 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.75 |
| 100752905K | 70 | 36 | 1.1 | 1 | 83000 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.75 | |
| 130752905K | 70 | 36 | 1.1 | 1.25 | 83000 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.75 | |
| 150752905K | 70 | 36 | 1.1 | 1.5 | 83000 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.75 | |
| 200752905K | 70 | 36 | 1.1 | 2 | 83000 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.75 | |
| 300752905K | 70 | 36 | 1.1 | 3 | 83000 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.75 | |
| 400752905K | 70 | 36 | 1.1 | 4 | 83000 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.75 | |
| 500752905K | 70 | 36 | 1.1 | 5 | 83000 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.75 | |
| 80752305 | 25 | 68.2 | 42 | 1.3 | 0.75 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 |
| 100752305 | 68.2 | 42 | 1.3 | 1 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 130752305 | 68.2 | 42 | 1.3 | 1.25 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 150752305 | 68.2 | 42 | 1.3 | 1.5 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 200752305 | 68.2 | 42 | 1.3 | 2 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 250752305 | 68.2 | 42 | 1.3 | 2.5 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 300752305 | 68.2 | 42 | 1.3 | 3 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 350752305 | 68.2 | 42 | 1.3 | 3.5 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 400752305 | 68.2 | 42 | 1.3 | 4 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 500752305 | 68.2 | 42 | 1.3 | 5 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 550752305 | 68.2 | 42 | 1.3 | 5.5 | 93800 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 80752906K1 | 28 | 68.2 | 42 | 1.3 | 0.75 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 |
| 100752906K1 | 68.2 | 42 | 1.3 | 1 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 130752906K1 | 68.2 | 42 | 1.3 | 1.25 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 150752906K1 | 68.2 | 42 | 1.3 | 1.5 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 200752906K1 | 68.2 | 42 | 1.3 | 2 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 250752906K1 | 68.2 | 42 | 1.3 | 2.5 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 300752906K1 | 68.2 | 42 | 1.3 | 3 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 350752906K1 | 68.2 | 42 | 1.3 | 3.5 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 400752906K1 | 68.2 | 42 | 1.3 | 4 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 500752906K1 | 68.2 | 42 | 1.3 | 5 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 550752906K1 | 68.2 | 42 | 1.3 | 5.5 | 92900 | 115000 | 7000 | 9000 | 8 | 3.3 | 0.76 | |
| 300752906 | 28 | 70 | 36 | 1.3 | 3 | 82300 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.73 |
| 400752906 | 70 | 36 | 1.3 | 4 | 82300 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.73 | |
| 500752906 | 70 | 36 | 1.3 | 5 | 82300 | 98300 | 7000 | 9000 | 8 | 3.3 | 0.73 | |
| 80752906K | 95 | 54 | 1.3 | 0.75 | 162000 | 207000 | 5300 | 6700 | 8 | 3.3 | 2.1 | |
| 100752906K | 95 | 54 | 1.3 | 1 | 162000 | 207000 | 5300 | 6700 | 8 | 3.3 | 2.1 | |
| 150752906K | 95 | 54 | 1.3 | 1.5 | 162000 | 207000 | 5300 | 6700 | 8 | 3.3 | 2.1 | |
| 200752906K | 95 | 54 | 1.3 | 2 | 162000 | 207000 | 5300 | 6700 | 8 | 3.3 | 2.1 | |
| 300752906K | 95 | 54 | 1.3 | 3 | 162000 | 207000 | 5300 | 6700 | 8 | 3.3 | 2.1 | |
| 350752906K | 95 | 54 | 1.3 | 3.5 | 162000 | 207000 | 5300 | 6700 | 8 | 3.3 | 2.1 | |
| 400752906K | 95 | 54 | 1.3 | 4 | 162000 | 207000 | 5300 | 6700 | 8 | 3.3 | 2.1 | |
| 500752906K | 95 | 54 | 1.3 | 5 | 162000 | 207000 | 5300 | 6700 | 8 | 3.3 |
2.1 |
|
The Other Bearings We Do
| Ball Bearing | Deep Groove Ball Bearing | 60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **, |
| 160 **(70001 ) | ||
| Thrust Ball Bearing | 511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series | |
| Angular Contact Ball bearing | SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series | |
| Roller Bearing | Spherical Roller bearing | 239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on |
| Taper Roller Bearing | 329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings suchas 938/932 single and double row i.e M255410CD etc. | |
| Thrust Roller Bearing | 292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series. | |
| Cylindrical Roller Bearing | NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used in Steel Industry. |
